Summary of Contents for Horizon Fitness PERFORMANCE B600

  • Page 1 HORIZON PERFORMANCE FOR MODEL: B600 BIK E U SE R’ S G UIDE...

  • Page 3: Table Of Contents

    IN T RO DUC T I O N CONGRATULATIONS and THANK YOU for your purchase of this Horizon Performance bike! Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, a Horizon Performance bike can help you attain it – adding club-quality performance to your at-home workouts, with the ergonomics and innovative features you need to get stronger and healthier, faster.

  • Page 4: Important Precautions

    I M PO R TAN T P RECAUT I ON S SAVE THESE INSTRUCTIONS Read all instructions before using this bike. When using an electrical product, basic precautions should always be followed, including the following: Read all instructions before using this bike. It is the responsibility of the owner to ensure that all users of this bike are adequately informed of all warnings and precautions.

  • Page 5: Assembly

    AS S E M BLY IMPORTANT: READ THESE SAFETY INSTRUCTIONS BEFORE USE! There are several areas during the assembly process of a bike that special attention must be paid. It is very important to follow the assembly instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the bike could have frame parts that are not tightened and will seem loose and may cause irritating noises.
  • Page 6 CONSOLE UPPER HANDLEBAR WATER BOTTLE HOLDER CONSOLE MAST MAST BOOT REMOTE RESISTANCE TOGGLES SEAT BACK SEAT FRAME MAIN FRAME FRONT STABILIZER TUBE LOWER HANDLEBAR SEAT BASE FRONT END CAP SEAT GUIDE RAIL SEAT GUIDE RAIL CAP BASE FRAME PEDALS SEAT ADJUSTMENT LEVER REAR END CAP REAR STABILIZER TUBE TOOLS INCLUDED...
  • Page 7 AS S E M BLY S T E P 1 BASE FRAME REAR STABILIZER TUBE REAR END CAPS BOLT (A) SPRING WASHER (B) FLAT WASHER (C) BOLT (A) SPRING WASHER (B) FLAT WASHER (C) LEVELER ADJUSTER LEVELER FRONT STABILIZER TUBE FRONT STABILIZER TUBE MAIN FRAME BOLT (A)
  • Page 8 A SS EM B LY S T E P 2 MAIN FRAME BASE FRAME CONNECT WIRES WASHER (C) SPRING WASHER (B) BOLT (A) A) Open HARDWARE BAG FOR STEP 2. B) Connect wires from BASE FRAME to MAIN FRAME. C) Slide MAIN FRAME into BASE FRAME. D) Attach the BASE FRAME to the MAIN FRAME using 5 BOLTS (A), 5 SPRING WASHERS (B) and 5 WASHERS (C).
  • Page 9 A SS EM B LY S T EP  LEFT PEDAL LEFT CRANK ARM RIGHT PEDAL RIGHT CRANK ARM Note: There is no hardware bag for this step. Attach the RIGHT PEDAL onto the RIGHT CRANk ARM, tightening it CLOCkWISE with the provided 13mm/15mm FLAT WRENCH.
  • Page 10 A S SE MB LY ST E P  SEAT FRAME SEAT LEVER SEAT FRAME SEAT LEVER STEP B STEP D SEAT GUIDE RAIL SEAT GUIDE RAIL SEAT FRAME SEAT LEVER SEAT LEVER CLAMP SEAT BASE SEAT LEVER CLAMP SEAT GUIDE RAIL SEAT BASE SEAT FRAME SEAT FRAME...
  • Page 11 A S S E M BLY S T E P  A) Open HARDWARE BAG FOR STEP 5. B) Connect the SEAT FRAME WIRES to the PULSE GRIP WIRES as shown above. SEAT BACK C) Press COVERED WIRE into WIRE CLIP just before EXPOSED WIRES as shown above. Tuck EXPOSED WIRES under RECESS in LOWER HANDLEBAR.
  • Page 12 A SS E M B LY S T E P 6 A) Open HARDWARE BAG FOR STEP 6. B) Slide the TOP CAP through the MAST as shown. Tie the CONSOLE WIRES to the pre-attached routing wire. Carefully pull console wires through the CONSOLE MAST.

  • Page 13: Before You Begin

    B E F OR E Y OU B EG I N CONGRATULATIONS! on choosing your bike. You’ve taken an important step in developing and sustaining an exercise program! Your bike is a tremendously effective tool for achieving your personal fitness goals. Regular use of your bike can improve the quality of your life in so many ways. HERE ARE jUST A FEW OF THE HEALTH BENEFITS OF ExERCISE: •...

  • Page 14: Bike Operation

    B I K E O P E RAT ION POWER Your bike is powered by a power supply. The power must be plugged into the power jack, which is located in the front of the bike near the STABILIZER TUBE. Do not operate the bike if the power cord or plug is damaged.
  • Page 15 B 60 0 CO NS O L E DI S P L AY R E S I S T A N C E R E S I S T A N C E P R E S S T O S W I T C H TIME DISTANCE CLOCK...
  • Page 16 B6 00 C ON SOL E OP E R AT I O N D AT E & C L O CK S ET U P 1) Enter Setup Mode: Press and hold MANUAL and WEIGHT LOSS WORKOUTS program buttons for 3 seconds. 2) Once in setup mode, use the +/–...
  • Page 17 W O R K OUT PR O F I L E S MANUAL Allows you to adjust the resistance level to your preference, without a preset program. WEIGHT LOSS Promotes weight loss by raising and lowering the resistance level, while keeping you in your fat burning zone. CARDIO WORKOUTS Creates an intense cardio workout by raising and lowering resistance levels through-out your workout.
  • Page 18 WO R KO U T I NF OR M AT I O N W O R K O U T: M AN UAL Allows ‘On The Fly’ manual RESISTANCE changes. Time-based goal. Select USER 1, USER 2, or press ENTER to skip to STEP 2. Select MANUAL (P1) using the WORKOUT QUICK KEY and press ENTER.
  • Page 19 W ORKO UT: C AR DI O W O RK O U T S Motivates with different combinations of RESISTANCE. TIme-based goal. Select USER 1, USER 2, or press ENTER to skip to STEP 2. Select CARDIO WORKOUTS using the WORKOUT QUICK KEY and press ENTER. NOTE: CARDIO WORKOUTS key represents multiple programs: P, P6, and P.
  • Page 20 W O R KO UT: PO W E R W OR K OU T S Challenges with various combinations of RESISTANCE at specific INTERVALS. Time-based goal. Select USER 1, USER 2, or press ENTER to skip to STEP 2. Select POWER WORKOUTS using the WORKOUT QUICK KEY and press ENTER. NOTE: POWER WORKOUTS key represents multiple programs: P, P, and P10.
  • Page 21 W OR K OUT: E N ER GY Z ON E A unique program that allows you to vary your cadence or RPM and the resistance will adjust accordingly to your selected goal. The quicker you pedal the less resistance for the goal selected. Select USER 1, USER 2, or press ENTER to skip to STEP 2.
  • Page 22 W ORK O U T: T EM PO 1 & 2 Keeps you in the fat burning zone by informing you to pedal at high or low paces. Select USER 1, USER 2, or press ENTER to skip to STEP 2. Select TEMPO 1 OR 2 using the WORKOUT QUICK KEY and press ENTER.
  • Page 23 S E LE CTI NG M Y W OR K O UT 1 & 2 Select USER 1, USER 2, or press ENTER to skip to STEP 2. Select MY WORKOUT 1 or MY WORKOUT 2 using the WORKOUT QUICK KEYS and press ENTER. Set Time using the +/- KEYS and press ENTER.
  • Page 24 W O R K O UT I NF O R M AT I ON US I N G SPE A KE R / M P A U DI O F U NCT I ON Connect the included AUDIO ADAPTOR CABLE to the AUDIO IN JACK on the top of the CONSOLE and the HEADPHONE JACK on your CD / MP player.
  • Page 25 WO RK OU T IN FO R MAT I ON U S ING eT R A K™ PE R F O RM A NC E T RA CK E R INTRODUCTION Research shows that those who journal their fitness routines or workouts, on average, achieve greater success than those who do not.
  • Page 26 LAST WORKOUT: This option allows you to view your accumulated data from your last workout. The Current Workout becomes the Last Workout once a program has ended or the console has been reset. The following information will be shown in each display window: TIME - Total time of last workout.
  • Page 27 W EE K LY GO A L SE T UP Select USER. Press eTRAK™ button and scroll to WEEKLY GOAL. Enter the Setup Mode: Press ENTER. Use +/- KEYS to set a time goal. (Leave time at 00:00 if you want to set a distance goal).

  • Page 28: Conditioning Guidelines

    CO ND I T I O NI N G GUI DELINE S ALWAYS CONSULT YOUR PHYSICIAN BEFORE BEGINNING AN ExERCISE PROGRAM. HOW OFTEN? (Frequency of Workouts) The American Heart Association recommends that you exercise at least 3 to 4 days per week to maintain cardiovascular fitness.

  • Page 29: Perceived Exertion Level

    PERCEIVED ExERTION LEVEL A simple way to gauge your exercise intensity is to evaluate your perceived exertion level. While exercising, if you are too winded to maintain a conversation without gasping, you are working out too hard. A good rule of thumb is to work to the point of exhilaration, not exhaustion.
  • Page 30 STRETCHING TI P S STRETCH FIRST Before using your product, it is best to take a few minutes to do a few gentle stretching exercises. Stretching prior to exercise will improve flexibility and reduce chances of exercise related injury. Ease into each of these stretches with a slow gentle motion.
  • Page 31 T IP S THE IMPORTANCE OF A WARM-UP & COOL DOWN WARM UP The first 2 to 5 minutes of a workout should be devoted to warming up. The warm-up will limber your muscles and prepare them for more strenuous exercise. Make sure that you warm-up on your product at a slow pace.
  • Page 32 WE E K LY L O G S HEETS MO N TH LY L O G S HEETS...

  • Page 33: Troubleshooting & Maintenance

    • The outlet the machine is plugged into is functional. Double check that the breaker has not tripped. • The correct adapter is being used. Only use the adapter provided or authorized by Horizon Fitness. • The adapter is not pinched or damaged and is properly plugged into the outlet AND the machine.
  • Page 34 HEA RT R AT E T R OU BL ES H OO T I NG PROBLEM: There is no heart rate reading. SOLUTION: Remove the console and verify that the heart rate cables are attached properly, making sure that the cables are securely inserted into the console. Check your exercise environment for sources of interference such as high power lines, large motors, etc.
  • Page 35 C O MM ON P R O D U CT Q UE S T I O NS ARE THE SOUNDS MY BIKE MAKES NORMAL? Our bikes are some of the quietest available because they use belt drives and friction free magnetic resistance.
  • Page 36 Clean with soap and water cleaners only. Never use solvents on plastic parts. Cleanliness of your bike and its operating environment will keep maintenance problems and service calls to a minimum. For this reason, Horizon Fitness recommends that the following preventive maintenance schedule be followed.

  • Page 37: Limited Warranty

    • Any attempt to repair this equipment creates a risk of injury. Horizon Fitness is not responsible or liable for any damage, loss or liability arising from any personal injury incurred during the course of, or as a result of any repair or attempted repair of your fitness equipment by other than an authorized service technician.
  • Page 38 C o t t a g e G r o v e , W I 5 3 5 2 7 T e l : 1 . 8 6 6 . 9 9 . T E M P O B600 Rev. 1.6 | © 2007 Horizon Fitness Products | Designed & Engineered in the U.S.A. | Made in China...
