Camera System Adjustments; Lens Type Input; Hall Adjustment - Sony CCD-TR618 Service Manual

1-3.

CAMERA SYSTEM ADJUSTMENTS

Before perform the camera system adjustments, check that the
specified values of "VIDEO SYSTEM ADJUSTMENTS" are
satisfied.
Note: NTSC model: CCD-TR618/TR818/TRV49/TRV58/TRV68/TRV78/TRV88/TRV98
PAL model: CCD-TR618E/TR718E/TR728E/TRV49E/TRV58E/TRV59E/TRV78E/TRV98E

1. Lens Type Input

Distinguish the type of the lens being used for the camcorder, and
input data corresponding to the type.
Subject Not required
Measurement Point Display data of page 1 (Note)
Measuring Instrument Adjustment remote commander
Adjustment Page E
Adjustment Address 5C, 5D, 5E, 5F
Note: Displayed data of page 1 of the adjustment remote commander.
1 : XX : XX
Adjusting method:
Order Page Address Data
1 0 01 01
2 6 01 65
3 0 03 19
4 1
5 E 5C 21
6 E 5D 84
7 E 5E FC
8 E 5F F7
9 F 2C D6
10
11 E 5C 22
12 E 5D 51
13 E 5E FD
14 E 5F C4
15 F 2C D7
16 6 01 00
17 0 03 00
18 0 01 00
F
2C
Display data
Procedure
Set the data.
Set the data, and press PAUSE
button.
Set the data.
Check that the data.
When the data is "0000",
proceed to step 5.
(Glass lens type)
When the data is "0001",
proceed to step 11.
(Plastic lens type)
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Proceed to step 16.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data, and press PAUSE
button.
Set the data.
Set the data.

2. HALL Adjustment

For detecting the position of the lens iris, adjust AMP gain and
offset.
Subject
Measurement Point
Measuring Instrument
Adjustment Page
Adjustment Address
Specified Value 1
Specified Value 2
Note1: Displayed data of page 1 of the adjustment remote commander.
1 : 00 : XX
Adjusting method:
Order Page Address Data
1 0 01
2 6 94
3 6 95
4 6 01
5 6 02
6 6 01
Note2: The adjustment data will be automatically input to page: F,
address: 38, 39, 3A.
Checking method:
Order Page Address Data
1 0 03
2 6 01
3 1
4 6 01
5 1
Processing after Completing Adjustments:
Order Page Address Data
1 6 94
2 6 95
3 6 01
4 0 03
5 0 01
5-14
Not required
Display data of page 1 (Note1)
Adjustment remote commander
F
38, 39, 3A
86 to 8A
15 to 19
IRIS display data
Procedure
01 Set the data.
88 Set the data.
17 Set the data.
6D Set the data, and press PAUSE
button.
Check that the data changes to
"01". (Note2)
00 Set the data, and press PAUSE
button.
Procedure
03 Set the data.
01 Set the data, and press PAUSE
button.
Check that the IRIS display data
(Note1) satisfies the specified
value 1.
03 Set the data, and press PAUSE
button.
Check that the IRIS display data
(Note1) satisfies the specified
value.2.
Procedure
00 Set the data.
00 Set the data.
00 Set the data, and press PAUSE
button.
00 Set the data.
00 Set the data.
