Delta Elec. Inc.
EP7155i & EP1691i
ver.00
DATA PROJECTOR
EP7155i
& EP1691i
(DP-3515)
(DP-7615)
SERVICE MANUAL
(ver.00)
Company Confidential
Optoma_______________________
Delta____________
1
2008/12/24
