Single Phase Metered PDU, 5/5.8kW 30A 208/240V,
2U Horizontal Rackmount, 16 C13 and 2 C19 outlets,
L6-30P input plug
MODEL NUMBER: PDUMH30HV
Description
Tripp Lite single phase Metered PDU / Power Distribution Units offer real-time local reporting of load level in
amps via built-in digital current metering. Enables visual monitoring of PDU output current to preserve proper
output balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected
UPS, generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting
accessories.
Features
30A single phase 208/240V Metered Power Distribution Unit / PDU (Agency derated to 24A continuous)
Set of two lighted meters report PDU output current in amps for each 9 outlet load bank
Attached NEMA L6-30P 30A 208/240V input plug and 12ft / 3.6m cord
2U horizontal rackmount format installs in two rack spaces
18 output receptacles (16 C13, 2 C19)
Outlets are arranged in two 9 outlet load banks, each with separate 20A breaker and current metering
Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats
Cord retention brackets keep vital equipment plugs connected
Grounding lug
TAA Compliant Version Available - Order Tripp Lite PDUMH30HVTAA
Specifications
OVERVIEW
PDU Type
Metered
1 / 4
Highlights
Metered single phase 30A
208/240V 2U horizontal
rackmount PDU
Two built-in meters report output
current in amps for each load
bank
Attached 12ft / 3.6m cord with
NEMA L6-30P input plug
18 total outlets (16 C13, 2 C19)
Reversible housing, 2U 208/240V
rackmount metered PDU
Applications
Ideal for network configurations
requiring a metered PDU
Package Includes
2U rack PDU
Mounting brackets
Plug retention plates
User manual
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Tripp Lite PDUMH30HV
Summary of Contents for Tripp Lite PDUMH30HV
-
Page 1: Specifications
Description Plug retention plates Tripp Lite single phase Metered PDU / Power Distribution Units offer real-time local reporting of load level in User manual amps via built-in digital current metering. Enables visual monitoring of PDU output current to preserve proper output balance and prevent circuit overloads as additional equipment is added. - Page 2 OUTPUT Output Capacity Details 5kW (208V input), 5.8kW (240V input), 4.8kW (200V input); 30A maximum (agency de-rated to 24A continuous) Frequency compatibility 50 / 60 Hz Output nominal voltage 200-240V nominal, single phase Overload protection Outlets are arranged in two 9 outlet load banks; each load bank is protected by a separate 20A circuit breaker Outlet quantity / type 16 C13 and 2 C19 outlets Outlet Type...
- Page 3 Relative Humidity 0-95% non-condensing CERTIFICATIONS TAA Compliant Option TAA Compliant Version Available - Order Tripp Lite PDUMH30HVTAA Certifications Tested to UL 60950-1 (USA, Canada), Class A (Emissions), NOM (Mexico), RoHS compliant WARRANTY Product Warranty Period (Worldwide) 2-year limited warranty Related Items...
- Page 4 © 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
