Overview

The Kramer VP-411DS is a high performance 4x1 automatic switcher for UXGA
signals and stereo audio signals. It switches any one of four UXGA sources to the
UXGA output 15-pin HD computer graphics video connector, and any one of four
stereo audio sources to the stereo audio output on a 3.5mm mini connector. Both the
UXGA and audio IN 1 connectors are connected to output loop connectors.
The VP-411DS can be configured to operate in the automatic standby switching mode
or in the manual mode, via the DIP-switches. When in the automatic mode, the
VP-411DS will switch to the primary input when it is present. It will switch to the
second input in priority upon loss of the primary input
secondary input back to the primary input when the primary signal is reconnected.
When in the manual mode, the VP-411DS is controlled by the control panel.
In addition, the VP-411DS:
• With its video bandwidth exceeding 300MHz, ensures transparent operation at the
highest resolutions
• Includes the Kramer innovative integrated sync processing: KR - ISP™
technology, which lets you achieve a sharp, stable image when the sync level is too
low, by restoring the sync signal waveform
• Has PANEL LOCK and OFF buttons
• Automatically switches the stereo audio signal with the video signal (audio-follow-
video) when switching the active input to the output
• Includes PRIORITY DIP-switches for selecting the default UXGA master source
signal
• Comes with contact closure remote control for forced operation
• Is housed in a desktop-sized enclosure, and is +12V DC fed
The VP-411DS can be controlled via the:
• Front panel buttons
• Infrared remote control transmitter or external remote IR receiver extension cable
• RS-232 serial commands transmitted by a touch screen system, PC, or other serial
controller
• Remote control contact closure
1 And down to the input of the lowest priority
