Summary of Contents for ASROCK 1012LW-C2750
-
Page 2: Copyright Notice
Version 1.0 Published December 2013 Copyright©2013 ASRockRack Inc. All rights reserved. Copyright Notice: No part of this documentation may be reproduced, transcribed, transmitted, or translated in any language, in any form or by any means, except duplication of documentation by the purchaser for backup purpose, without written consent of ASRockRack Inc. - Page 3 Setting up the Server in a Restricted Access Location • Access can only be gained by service persons or by users who have been instructed about the reasons for the restrictions applied to the location and about any precautions that shall be taken. • Access is through the use of a tool or lock and key, or other means of security, and is controlled by the authority responsible for the location.
-
Page 4: Important Safety Instructions
Important Safety Instructions Pay close attention to the following safety instructions before performing any of the operation. Basic safety precautions should be followed to protect yourself from harm and the product from damage: • Operation of the product should be carried out by suitably trained, qualified, and certified personnel only to avoid risk of injury from electrical shock or energy hazard. -
Page 5: Contact Information
Contact Information If you need to contact ASRockRack or want to know more about ASRockRack, you’re welcome to visit ASRockRack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRockRack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District, Taipei City 112, Taiwan (R.O.C.) -
Page 6: Table Of Contents
Contents Chapter 1 Introduction 1.1 Shipping Box Contents 1.2 Specifications Chapter 2 Server System Overview 2.1 System Components 2.2 Cable Connections 2.3 System Front Panel 2.4 System Rear Panel 2.5 Front Control Panel Buttons and LEDs Chapter 3 Hardware Installation and Maintenance 3.1 Server Top Cover 3.2 Hard Drive 3.3 Power Supply... -
Page 7: Chapter 1 Introduction
Chapter 1 Introduction Thank you for purchasing 1U12L Series, a reliable barebone system produced under ASRockRack’s consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRockRack’s commitment to quality and endurance. Because the hardware specifications might be updated, the content of this documentation will be subject to change without notice. -
Page 8: Specifications
1.2 Specifications 1U12L Series System Physical Status Form Factor 1U Rackmount Dimension 31.9" x 16.9" x 1.7" (810 X 430 X 43.5 mm) (D x W x H) Support MB Size Extend Mini ITX Front Panel Buttons • Power On/Standby button •... -
Page 9: Chapter 2 Server System Overview
Chapter 2 Server System Overview This chapter provides diagrams showing the location of important components of the server system. 2.1 System Components Top Cover Power Supply Unit 5 x System Fans 12 x 3.5” HDD Carriers 2 x 2.5” HDD Carriers Server Board Front Controls and Indicators... -
Page 10: Cable Connections
2.2 Cable Connections... - Page 11 From Cable* 2.5" HDD 1 SB / PSU Power supply cable 2.5" HDD 2 SB / PSU Power supply cable Server Board (SB) Power Supply Unit (PSU) SB / BP1~3 Power supply cables System Fan 5 Fan cable System Fan 4 Fan cable System Fan 3 Fan cable...
-
Page 12: System Front Panel
2.3 System Front Panel Description 2 x USB 2.0 Ports Control Panel Buttons and LEDs 2.4 System Rear Panel Description Power Supply Unit I/O Shield (depends on the specification of the server board) Rear Vent 1 x PCI Express Slot (for the riser card) -
Page 13: Front Control Panel Buttons And Leds
2.5 Front Control Panel Buttons and LEDs Front Control Panel Description NMI (Nonmaskable Interrupt) Button* System Reset Button LAN1, LAN2 Activity LED* HDD Status LED* UID Button and LED* Power Button and LED *Please be noted that the functions are supported depending on the type of the server board. NMI (Nonmaskable Interrupt) Button Press the NMI button with a paper clip or pin to generate a nonmaskable interrupt and to put the server in a halt state for examination. - Page 14 Status LED Definitions Power LED Status Description Green Power on Blinking Green Standby(Sleep) mode Power off UID LED Status Description Blue System identification is active. System identification is disabled. HDD Status LED Status Description Green HDD access HDD idle LAN1, LAN2 LED Status Description Green...
-
Page 15: Chapter 3 Hardware Installation And Maintenance
Chapter 3 Hardware Installation and Maintenance This chapter helps you assemble the chassis and install components. Before You Begin Before you work with the server, pay close attention to the “Important Safety Instructions” at the beginning of this manual. 1. Make sure the server is powered off. Power down the server if it is still running. -
Page 16: Server Top Cover
3.1 Server Top Cover Removing the Server Top Cover 1. Before removing the top cover, power off the server and unplug the power cord. 2. The system must be operated with the chassis top cover installed to ensure proper cooling. 1. - Page 17 Installing the Server Top Cover 1. Lower the top cover on the chassis, making sure the side latches align with the cutouts. 2. Slide the top cover toward the front. 3. Secure the top cover with the six screws.
-
Page 18: Hard Drive
3.2 Hard Drive 3.2.1 Installing a Hard Disk Drive into 3.5" Hard Drive Carrier This system allows the routing of cables behind the HDD base plate and carriers. Be sure to connect all required cables first before installing any of the 3.5” HDDs. Meanwhile, please well organize your cables and be careful with your cable routing. - Page 19 Installing a 3.5” Hard Drive to the Hard Drive Carrier 1. Place the 3.5" HDD into the carrier with the printed circuit board side facing down. Carefully align the mounting holes in the hard drive and the carrier. 2. Secure the hard drive using the four screws. 3.
- Page 20 Removing a Hard Disk Drive Base Plate from the Chassis Organize your cables and place them under the hard drive base plates before installing 3.5" HDDs. 1. Remove the screws that secure the hard drive base plate.
- Page 21 3.2.2 Installing a Hard Disk Drive into 2.5" Hard Drive Carrier Removing 2.5” Hard Drive Carriers from the Chassis 1. Remove the screws that secure the 2.5" hard drive carrier.
- Page 22 Installing a 2.5” Hard Drive to the Hard Drive Carrier 1. Place a 2.5" HDD into the carrier with the label facing up and the connector end toward the server board. Carefully align the mounting holes in the hard drive and the carrier. 2.
-
Page 23: Power Supply
3.3 Power Supply Installing and Removing the Power Supply Place the power supply unit in the chassis with the fan facing right. Align the mounting screw holes and secure the power supply unit with the six screws. Reverse the procedure to remove the power supply. Before replacing the power supply, power off the server, unplug the power cord, and discon- nect all wiring from the power supply. -
Page 24: Add-On Card
3.4 Add-on Card 1. You can install an add-on card to the chassis only when you have a riser card installed on the server board. 2. Before installing the add-on card, power off the server and unplug the power cord. Removing the Blanking Plate from the Chassis 1. -
Page 25: System Fan
3.5 System Fan Replacing the System Fan 1. Unplug the fan connecter and remove the failed fan. 2. Align the mounting holes on the fan bar with the fan mounts on the replacement fan corners. 3. Gently place the fan on the fan bar. Make sure the fan is well seated. 4. -
Page 26: Backplane
3.6 Backplane Each barebone system supports three 3.5-inch HDD backplanes. The miniSAS/ SATA backplanes serve as the interfaces between the server board and the HDDs. Before removing and installing the backplanes, power off the server and unplug the power cord and make sure all 3.5” HDDs have been removed. For the specification of the backplane, please refer to the Chapter 4. -
Page 27: Server Board
3.7 Server Board Follow the steps below to install the server board to the chassis. 1. Hold the server board only by the edges. 2. Gently place the server board into the chassis. Sit the server board on the server board tray. -
Page 28: Chassis Cables
3.8 Chassis Cables This section lists supported cables for your chassis system. Cable type and quantity vary depending on the server board that comes with your system. 1. MiniSAS to SATA Cable 1 (400mm) (Quantity: 1) Server Board Port 0-3 2. - Page 29 3. MiniSAS to SATA Cable 3 (600mm) (Quantity: 1) Server Board Port 8-11 MiniSAS to MiniSAS Cable 1 (120mm) (Quantity: 1) Server Board MiniSAS to MiniSAS Cable 2 (300mm) (Quantity: 1) Server Board MiniSAS to MiniSAS Cable 3 (480mm) (Quantity: 1) Server Board...
- Page 30 SATA Cable 1 (350mm) (Quantity: 1) SATA HDD Server Board SATA Cable 1 (500mm) (Quantity: 1) SATA HDD Server Board SMBus Cable (150/150/300mm) (Quantity: 1) Server Board Front Panel Cable (1000mm) (Quantity: 1)* PANEL1 AUX_PANEL1 NMI_BTN Server Board *The NMI function is not supported for the 1U12L Series.
- Page 31 Fan Cable (70mm) (Quantity: 1) Server Board USB Cable (1000mm) (Quantity: 1) Server Board 1. Remove all 3.5” HDDs carriers when you are going to connect various components with cables. 2. Conenctions and cable routing may differ depending on various server boards. Please refer to the Quick Installation Guide to know the exact headers or connectors to be con- nected on the server board you purchase.
-
Page 32: Chapter 4 Backplane Specifications
Chapter 4 Backplane Specifications Hard Drive Backplanes (BP) ( to connect 4x3 3.5" HDDs) 1U12LIW-BPB1 / 1U12LIW-BPB2 / 1U12LIW-BPB3 Top View Description I2C Address Settings (J2) SGPIO Code Programming Pin BMC SMBus Connector (BMC_SMB) Mini-SAS Connector DC Power Connector (DC-IN 1) DC Power Connector (DC-IN 2) SATA Hot-swap Connector 1 SATA Hot-swap Connector 2... - Page 33 Front Panel Board (FPB) 1U12LIW-FPB1 Top View 10 11 Description USB Header (USB_Header) Front and Auxiliary Panel Header (Front + AUX Panel) Front USB 2.0 Connector (Front_USB_1) Front USB 2.0 Connector (Front_USB_2) NMI Button (CON2) System Reset Button (CON1) LAN 1 Activity LED* (LED2) LAN 2 Activity LED* (LED3) HDD Activity LED* (LED1) ID Button and LED* (U2)
-
Page 34: Pin Definitions
Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins. - Page 35 SMB Connector The SMB (SubMiniature (5-pin BMC_SMB1) version B) connector provides (5-pin BMC_SMB2) a communication interface (5-pin BMC_SMB3) between the backplane and the (see p.26, No. 3) motherboard. USB_PWR USB 2.0 Header The header supports two USB 2.0 (9-pin USB_HEADER) ports on the front panel.
-
Page 36: Appendix A Installing The Server In A Rack
Appendix A Installing the Server in a Rack This section describes how to rackmount the 1U12L Series server with slide rail assemblies. The rails installation instructions in this manual are example only, your actual rail assembly procedure may differ slightly . The slide rail assembly consists of a chassis rail and a slide rail. - Page 37 To slide a chassis rail back into the slide rail assembly, push the blue release button toward the rear, and simultaneously slide the chassis rail into the slide rail assembly until it is locked and cannot be pushed further. Attaching the Chassis Rails to the Server Position a chassis rail along one side of the chassis, and align the keyhole openings on the chassis rail with the locating pins on the side of the chassis.
- Page 38 Attaching the Slide Rail Assemblies to the Rack Determine where to attach the slide rails. Make sure you have three holes of free space above the slide rail bracket. For the rack with square mounting holes, insert cage nuts in the holes that you will use on the rack.
- Page 39 Adjust the brackets to accommodate the depth of the rack. 1 1 U 1 1 U Align the holes on the brackets with the mounting holes you selected on the rack. Tighten the screws to secure the slide rails to the rack. Make sure the rear bracket meets the rear vertical rail of the rack.
- Page 40 Fully tighten the lock nuts on the rear bracket. 1 1 U Sliding the Server into the Rack Ensure that the slide rails are properly and securely attached to the rack. Fully extend the slide rails from the rack by pulling the inner rails out until they are locked and cannot be pulled out further.
- Page 41 Slide the server slowly and evenly all the way into the cabinet to ensure that the slide assemblies are working correctly. The server is heavy. For safe lifting, two or more persons are required to install the server into the rack. 11 U Secure the server to the rack with screws.
