AUSTRALIAN MONITOR AMIS480P Specifications

4 Chan. 80 Watt 70 Volt/ 8 Ohm AMP
The Australian Monitor Installation Series AMIS480P is a robust, highly
featured 4 channel power amplifier. Offering 4 independent channels,
each delivering 80 watts into 4 ohms or 70/100 volt line, the AMIS480P is
designed to operate in extreme conditions to give the contractor the most
reliable 4 channel amplifier available today.
Engineered with maximum attention to channel isolation, with individual
ground lift switches and level control for each channel, the AMIS480P will
operate as 4 individual amplifiers in a rack space friendly, 2RU chassis.
For ease of installation, each channel input can be routed to the next
channel via rear panel link switches, eliminating the need for daisy
chaining or Y-split cables. The AMIS480P also offers signal present and
clip LED indicators for each channel as well as a thermal protect
indicator.
The AMIS480P is a significant advance in 4 channel amp design offered
at a contractor friendly price.
AMIS 480P AMIS 480P
AMIS 480P
AMIS 480P AMIS 480P
SPECICIATIONS
Power Output
4 x 80W
Freq. Response (1W)
80Hz - 20kHz
DISTORTION
1% THD, all
channels driven
Power Bandwidth
85Hz - 20kHz
S/N Ratio
94dB (ref 100V)
Crosstalk
1kHz 80dB; 20Hz -
20kHz Better than
60dB
Input Sensitivity
0.775V RMS (0dBu)
Input Impedance
20K
Voltage Gain
(pot at max)
100V out 129
(42dB)
70V out 90
(39dB)
4ohm out 23
(27dB)
Output Regulation
95% (1kHz)
Dimensions (h x w x d)
4.36" x 19" x 17"
Weight
44lb
Shipping Weight
53lb
