AMIS26
2 INPUT, 6 OUTPUT DISTRIBUTION AMPLIFIER
INSTALLATION AND OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMIS26 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AUSTRALIAN MONITOR AMIS26

  • Page 1 AMIS26 2 INPUT, 6 OUTPUT DISTRIBUTION AMPLIFIER INSTALLATION AND OPERATION MANUAL...
  • Page 2: Important Safety Information

    7. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the Australian Monitor Inc is not responsible for damage to means of grounding of a piece of equipment is not defeated.
  • Page 3: Table Of Contents

    30dB of attenuation, so they can be run DIMENSIONS as any combination of line level or mic level outputs. Ample label space is provided for both inputs and outputs and the AMIS26 is powered via SPECIFICATIONS a supplied 20VAC power supply.
  • Page 4: Front Panel

    15dB. LEVEL METER These 4 segment LED meters show the strength of each of the AMIS26's input signals. LED segments are calibrated to the following level markings and show the following colours:...
  • Page 5: Rear Panel

    6). The dual RCA inputs are Line level inputs only and are internally summed to mono. OUTPUT CONNECTORS The AMIS26's outputs can be either balanced XLR or unbalanced dual RCA’s. Both these outputs can be switched between Mic level & Line level via internal DIP switches accessed through the lid (see internal adjustments section page 6).
  • Page 6: Internal Adjustment

    INTERNAL ADJUSTMENT NOTE: The following adjustments involve access to the inside of the AMIS26 and should only be attempted by a qualified technician. All internal adjustments are accessible through the lid of the AMIS26. Always turn off the AC power and remove the AC power cord before accessing the inside of the AMIS26.
  • Page 7: Block Diagram

    BLOCK DIAGRAM PAGE 7 AMIS26 INSTALLATION & OPERATION MANUAL...
  • Page 8: Dimensions

    DIMENSIONS PAGE 8 AMIS26 INSTALLATION & OPERATION MANUAL...
  • Page 9: Specifications

    SENSITIVITY (FOR 0dBu OUT) LINE (XLR) 775mV (0dB) All measurements referenced to 0dBu (0.775mV) MIC (XLR) 10mV (-37dB) All measurements done with levels set In/Out at 0dB 775mV (0dB) LINE (RCA) OUTPUT MIC/LINE GAIN SWITCH 30dB PAGE 9 AMIS26 INSTALLATION & OPERATION MANUAL...
