Clever Features, Contractor Friendly
AMIS604
4 x 60w Mixer Amplifier
Operating Manual
AMIS604, 4 x 60 Watt Mixer Amplifier
Product Description
The AMIS604 is a 4 x 60 watt mixer amplifier designed for commercial installations. It features 4
independent 60 watt mixer amplifiers within the one 2 rack unit chassis. Each amplifier features 3 balanced
microphone/line input channels and outputs for either low impedance (8 ohm) or 25v/70v line speaker
systems. A host of unique features including VOX muting, VCA master level control and optional tone
generator/VOX relay cards make the AMIS604 a very flexible amplifier. The unit can be mounted in a
standard 19" equipment rack (rack ears supplied) or it can be used on a shelf or table.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AUSTRALIAN MONITOR AMIS604
Summary of Contents for AUSTRALIAN MONITOR AMIS604
- Page 1 AMIS604, 4 x 60 Watt Mixer Amplifier Product Description The AMIS604 is a 4 x 60 watt mixer amplifier designed for commercial installations. It features 4 independent 60 watt mixer amplifiers within the one 2 rack unit chassis. Each amplifier features 3 balanced microphone/line input channels and outputs for either low impedance (8 ohm) or 25v/70v line speaker systems.
-
Page 2: Front Panel Features
Signal LED’s The four green “Signal” LED’s located next to the ‘On’ LED indicates that the AMIS604 is passing audio. One LED is provided per amplifier. The signal LED is a simple method to trouble-shoot installations especially in multi-amplifier projects. -
Page 3: Rear Panel Features
24 Volt DC Power Inlet The AMIS604 feature optional 24VDC power to run off a battery back-up if required. This is connected via the rear terminal strip. The front panel Power Switch will not switch DC power ‘on’ or ‘off’ in DC operation. - Page 4 4, 3, 2 and 1. In other words, the speaker output section is directly behind the relevant front panel controls. Each of the four amplifiers in the AMIS604 can work with 8 ohm and/or 25/70 volt line speakers systems. The various outputs are marked as follows: Common or “-”...
- Page 5 Important Safety Information 1. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit, use only the original factory packing. 2. Read all documentation before operating your equipment. Retain all documentation for future reference.
- Page 6 Australian Monitor Audio Inc is not responsible for damage to loudspeakers for any reason. 18. Do not ground any red (“hot”) terminal. Never connect a “hot” (red) output to ground or to another “hot”...
