Specifications - Sanyo DC-X8CT Service Manual

Separate mini component system

Advertisement

Table of Contents

SPECIFICATIONS

TUNER/AMPLIFIER SECTION(JCX-X8/JCX-088)
Reception frequency ........ FM : 87.5 - 108 MHz
Output power ................... 30W x 2 (at 6 ohm,10%distortion)
Inputs ............................... VIDEO (AUDIO) : 500 mV/50k ohms
Outputs ............................. SPEAKERS : 6 ohms
Power requirements ......... AC 230V, 50 Hz
Power comsumption ........ 80W
Dimensions ...................... 225 (W) x 89 (H) x 272 (D) mm
Weight .............................. 3.6kg
CD SECTION (CP-X8/CP-088, CD CHANGER)
Type ................................. Changer, 3-disc
Channels .......................... 2-channel stereo
Sampling frequency ......... 44.1 kHz
Pick-up ............................. Optical 3-beam semiconductor laser
Laser output ..................... 0.6 mW (Continuous wave max.)
Wave length ..................... 790 nm
Frequency response ........ 20 Hz to 20 kHz
Wow/flutter ....................... Below measurable limits
Output .............................. OPTICAL DIGITAL OUT : Optical
Power supply ................... Supplied from the Tuner/Amplifier
Dimensions ...................... 225 (W) x 89 (H) x 272 (D) mm
Weight .............................. 2.1 kg
TAPE DECK SECTION (RD-X8/RD-088)
Track system .................... 4-track, 2-channel stereo
Frequency response ........ 50 Hz to 16 kHz (CrO
Signal-to-noise ratio ......... 60dB (Dolby B NR ON)
Wow/flutter ....................... 0.12%(WRMS)
Fast forward/rewind time .. Approx.110 sec. (C-60)
Power supply ................... Supplied from the Tuner/Amplifier
Dimensions ...................... 225 (W) x 89(H) x 272 (D) mm
Weight .............................. 2.0 kg
AM : 522 - 1,611 kHz
MULTI MEDIA IN : 500 mV/50k ohms
PHONES : 8 - 32 ohms
SUB WOOFER OUT : 10k ohms
1.0W (Eco On standby mode)
15W (Eco Off standby mode)
tape)
2
50 Hz to 15 kHz (Normal tape)
MD DECK SECTION (MDG-X8/MDG-088)
Sampling frequency ......... 44.1 kHz
Pick-up ............................. Optical 3-beam semiconductor laser
Laser output ..................... 6.85 mW (Continuous wave max.)
Wave length ..................... 685 nm
Wow flutter ....................... Below measurable limits
Recording system ............ Magnetic moduration over write
Input ................................. OPTICAL DIGITAL IN : Optical
Power supply ................... Supplied from the Tuner/Amplifier
Dimensions ...................... 225 (W) x 89 (H) x 272 (D) mm
Weight .............................. 1.7kg
SPEAKER SYSTEM (SX-X8/SX-088)
Type ................................ 3 way bass reflex
Unit used ......................... Woofer : 15 cm cone type
Maximum power-handling
capacity .......................... 60W (peak)
Nominal impedance ........ 6 ohms
Dimensions ..................... 185 (W) x 358 (H) x 255 (D) mm
Specifications subject to change without notice.
- 2 -
Built-in magnetic stray field
compensation
Mid range : 8 cm cone type
Tweeter : 3.5 cm balance driver
