PARTS LIST

EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
! ! !
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
:
CAUTION
Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W Carbon type and Chip type resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type, Electrolytic type and Chip type.
N.S.P : Not supplied as service parts.
PACKING & ACCESSORIES
REF.NO.
PART NO.
614 318 0616 CARTON CASE,
614 318 0623 CARTON CASE,
614 317 8040 CARTON CASE,
614 319 0974 CARTON CASE,
614 318 0647 CUSHION,SPACE,ACCESSORY
614 317 8071 CUSHION,SPACE,ACCESSORY
614 317 7913 CARTON CASE,INNER SLEEVE
614 317 7937 CARTON CASE,INNER SLEEVE
614 319 0936 CARTON CASE,INNER SLEEVE
614 316 2766 CUSHION,FRONT
614 316 2773 CUSHION,BACK
614 317 8149 INSTRUCTION MANUAL
614 317 9177 INSTRUCTION MANUAL
614 317 9184 INSTRUCTION MANUAL GREEK
614 245 8587 NOTICE,AC CORD
645 047 3050 POLY SHEET-0650X0450*NC,SET
645 047 3067 POLY SHEET-0650X0450*NC,SET
614 316 7150 ASSY,BOX,SPEAKER
614 316 7730 ASSY,BOX,SPEAKER
614 316 7167 ASSY,GRILLE
614 319 2817 ASSY,GRILLE
645 005 1227 ASSY,ANTENA,LOOP
614 229 4635 ANT,FM ANT
or
614 308 5515 ANT,FM ANT
645 045 7425 REMOCON,RB-X8RD
645 040 9943 BATTERY COVER,SERVICE PART
645 047 1469 CABLE,SYSTEM 19P,SYSTEM CABLE
645 047 7058 ASSY,CABLE,SYSTEM,19P
645 043 9421 CABLE,OPTICAL (DC-X8CM/UK)
645 047 6594 ASSY,CABLE,SYSTEM,19P
645 048 5992 ASSY,CABLE,SYSTEM,19P
PRODUCT SAFETY NOTICE
DESCRIPTION
OUTER CARTON(DC-X8CT/UK)
OUTER CARTON(DC-X8CM/UK)
OUTER CARTON(DC-088C/XE)
OUTER CARTON(DC-088C/SP)
(DC-X8CT/UK & DC-X8CM/UK)
(DC-088C/XE & DC-088C/SP)
(DC-X8CT/UK & DC-X8CM/UK)
(DC-088C/XE)
(DC-088C/SP)
(DC-X8CT/UK & DC-X8CM/UK)
(DC-088C/XE& DC-088C/SP)
(DC-088C/XE)
(DC-X8CT/UK & DC-X8CM/UK)
(DC-X8CT/UK & DC-X8CM/UK
& DC-088C/SP)
(DC-088C/XE)
(DC-X8CT/UK & DC-X8CM/UK)
(DC-088C/XE& DC-088C/SP)
(DC-X8CT/UK & DC-X8CM/UK)
(DC-088C/XE& DC-088C/SP)
(DC-X8CT/UK)
(DC-X8CM/UK)
(DC-088C/XE)
(DC-088C/SP)
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
! ! !
CABINET & CHASSIS
REF.NO.
PART NO.
1
614 316 5378 ASSY,CABINET,FRONT
1
614 317 9153 ASSY,CABINET,FRONT
1
614 319 0578 ASSY,CABINET,FRONT
2
614 316 2490 KNOB,ROTARY,VOL,VOLUME
3
614 316 2506 KNOB,ROTARY,JOG,JOG
4
614 302 0530 DEC,WINDOW LED,STANDBY
5
614 316 2025 BUTTON,STANDBY(DC-X8CT/UK,
5
614 319 0646 BUTTON,STANDBY
6
614 316 2049 BUTTON,MEMORY,BAND
7
614 316 2032 BUTTON,BAND,BAND
8
614 316 2308 DEC,WINDOW,VOL,VOL LIGHTING
9
614 316 3350 REFLECTOR,LED,VOL LIGHTING
10
614 316 2056 BUTTON,JOG MODE(DC-X8CT/UK,
10
614 319 0653 BUTTON,JOG MODE(DC-X8CT/UK,
11
614 317 7401 ASSY,CABINET,BENDING,
12
614 316 2476 HOLDER,HEAT SINK,LEFT,HEATSINK
13
614 316 2483 HOLDER,HEAT SINK,RIGHT,HEATSINK
14
614 316 5439 ASSY,HEAT SINK,POWER IC, TR
15
614 291 6568 MOUNTING,PWB,FOR-REG
16
614 316 1264 ASSY,CABINET,BOTTOM
17
614 129 1901 FIXER,AC CORD
or
614 284 1884 FIXER,AC CORD
18
614 310 3837 MOUNTING,FAN
19
614 316 2537 PANEL,REAR
20
614 317 9160 REFLECTOR,SHEET,VOL LIGHTING
21
614 317 4721 SHIELD,FRONT
FIXING PARTS
REF.NO.
PART NO.
Y01
411 021 6405 SCR S-TPG BIN 3X8,
Y02
411 165 3803 SCR S-TPG BIN 2.3X10,
Y03
411 098 4205 SCR S-TPG BIN 3X8,CABINET
Y04
411 021 6405 SCR S-TPG BIN 3X8,
Y05
411 021 6405 SCR S-TPG BIN 3X8,
Y06
411 021 6405 SCR S-TPG BIN 3X8,
Y07
411 021 6405 SCR S-TPG BIN 3X8,TUNER PWB
Y08
411 021 6405 SCR S-TPG BIN 3X8,HOLDER HS-PWB
Y09
411 020 9506 SCR S-TPG BRZ+FLG 3X16,
- 11 -
DESCRIPTION
(DC-X8CT/UK & DC-X8CM/UK)
(DC-088C/XE)
(DC-088C/SP)
DC-X8CM/UK & DC-088C/XE)
(DC-088C/SP)
DC-X8CM/UK & DC-088C/XE)
(DC-088C/SP)
AFTER BENDING
DESCRIPTION
FRONT-BOTTOM FIX
FRONT PWB FIX
HOLDER HS-BOTTOM
HOLDER HS-HEATSINK
HEATSINK-POSISTOR
+MAIN PWB
HEATSINK-POWER IC
