OPTION:
Single
This function will only show one single display whether it be on your Mobile PC or
external monitor.
OPTION: Mirror (Simultaneous Display)
This function supports two simultaneous display paths with the features of
LCD/CRT or CRT/TV).
Click on the "Control Panel" and double click on the "Display" icon. Click
1 1 . .
on the "Settings" tab to enter the "Display Properties" window. Click on
the "Advanced" button.
2 . From the "SiS 740 Properties" window, click on the "Display Modes" tab
2 .
Select the "VGA" or "LCD" or "TV" tab by clicking on the button to enable
3 3 . .
and connect the video display to the external CRT screen.
Click on the "Apply" tab and you will be ask to keep the new setting. The
4 .
4 .
Mobile PC and external monitor/TV screen will now simultaneously
display the same image.
OPTION:
Multi-Monitor
"Multi-Monitor" is only applicable when the function of "Dual View" is being access.
This function will only be available if an external monitor is connected to your
Mobile PC computer.
Use this to achieve a large desktop display on a small size screen. To do this:
Adjust the screen resolution by increasing the desktop area in the "Display
Area".
Use your touch pad or mouse cursor to point at any area of the screen to
move the window screen to a larger view.
To achieve the "Dual View" function, follow the procedures below:
1 Click on the "Control Panel" and double click on the "Display" icon. Click
