3 . Remove the screws that secure the RAM module compartment cover and set
3 .
it aside in a safe place.
4 . Remove the compartment cover and then angling it up and out.
4 .
If you need to install a higher capacity module, gently push the edge clips on
5 .
5 .
both sides to release the module. Angle the card slightly upward and gently
slide it from its edge connector slot. Store the card in the anti-static bag that
contains your new module(s).
To install the new memory card, hold the card with its gold edge connector
6 6 . .
toward the edge connector slot of the compartment. To help you orient the
cards, the edge connector has been made with two unequal-length sections.
You will only be able to insert the card in one direction.
Insert the edge connector into the slot. The gold edge connector of the card
7 7 . .
should not be visible when the card is fully inserted.
Press the card downward where you should hear an audible click as the
8 8 . .
latches of the connector secure the card in place.
Once the module is properly seated, you can replace the cover on this
9 9 . .
compartment.
Replace and tighten the screw.
1 0 .
1 0 .
