  • Page 2 Preface  Copyright 2009  All Rights Reserved. The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of...

  • Page 3: Table Of Contents

    Table of Content   ................2 EFORE YOU TART ..........9   ET YOUR COMPUTER ACCLIMATE ITSELF ............ 9   UMIDITY LARE ..............10   UITABLE PLACE TO WORK   ..................12 NTRODUCTION ..................13   RONT ..................15   IEWS ..................
  • Page 4 ................57   ALIBRATE OLOR ..............57   DJUST ISPLAY ETTING ............... 58   ONNECT TO A ROJECTOR ..............58   DJUST LEAR   3G C .................. 60 ONNECTION   ................65 ROUBLESHOOTING ................ 66   O SPEAKER OUTPUT ............66  ...

  • Page 6: Before You Start

    Use this manual will help you get the most from your notebook computer. If you are an experienced user of computers and/or Microsoft’s Windows operating systems, you might find it useful to read the Quick Start Guide that comes along with your accessories. If you are a less experienced user, you should through the manual carefully before using your system.
  • Page 7 Make sure to use the right voltage for the power source when connecting the equipment to the power outlet. Place the power cord in such a way that people can not step on it. Do not place anything on top of the power cord. All cautions and warnings on the equipment should be noted.
  • Page 8 The minimum specifications for the flexible cord are  No. 18 AWG, (2) Type SPT-2, and (3) 2-conductor. For Japan: All components of the cord set must bear a “PSE”  mark and in accordance with the Japanese Dentori Law. The minimum specifications for the flexible cord ...
  • Page 9  Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.  Do not use the telephone to report a gas leak in the vicinity of the leak. ...
  • Page 10 Bitte lesen Sie diese Hinweis sorgfältig durch. Heben Sie dirse Anleitung für den späteren Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Versenden Sie Keine Flüssig- oder Aerosolreiniger. Am besten eignet sich ein angefeuchtetes Tuch zur Reinigung. Die Netzanschluβsteckdose soll nahe dem Gerät angebracht und leicht zugänglich sein.
  • Page 11 Servicepersonal geöffnet werden. Wenn folgende Situationen auftreten ist das Gerät vom Stromnetz zu trennen und von einer qualifizierten Servicestelle zu Überprüfung.: Netzlabel oder Netzstecker sind beschädigt. Flüssigkeit ist in das Gerät eingedrungen. Das Gerät war Feuchtigkeit ausgesetzt. Wenn das Gerät nicht der Bedienungsanleitung entsprechend funktioniert oder Sie mit Hilfe dieser Anleitung keine Verbesserung erzielen.
  • Page 12 Die Minimalanforderungen für das Kabel sind .75m  ㎡ Leiter. (2) Type VCTF oder VCTFK, und (3) 2- conductor. Der Kabelsatz muss mindestens für eine  Stromstärke von 7A geeignet sein. Der Wandstecker muss ein zweipoliger geerdeter  Steckertyp gemäß dem Japanese Industrial Standard C8303 (15A, 125 VAC) sein.

  • Page 13: Let Your Computer Acclimate Itself

    melden, falls es sich in der Nähe des Lecks befindet.  Verwenden Sie nur die in diesem Benutzerhandbuch angegebenen Stromkabel und Batterien. Werfen Sie die Batterien nicht ins Feuer, sie könnten explodieren. Informieren Sie sich über die örtlichen Bestimmungen bezüglich der Entsorgung. Benutzen Sie das Netzteil nicht in unmittelbarer Nähe zu Wasser oder anderen Flüssigkeiten.

  • Page 14: Suitable Place To Work

    Try to avoid the computer components from being destroyed if it is over heated, so try to allow plenty of room for air to circulate around the case. Do not block the ventilation opening. Do not place your computer in direct sunlight. Suitable place to work Your computer will run well wherever you’re comfortable but extremes of temperature and humidity can be challenging to your...

  • Page 16: Introduction

    Install the battery pack Connecting the AC adapter Opening the display panel...

  • Page 17: Front View

    Turning on your computer With the LCD screen open, you will see several features important for operating your notebook computer. Front View Camera (Optional)
  • Page 18 LCD Display Keyboard Microphone LED Status Indicator System & Power Status Indicators LED Graphic Indication Symbol Blue light indicates the system is ON. Blinking Blue light indicates the notebook is in suspend mode. Blue light indicates the WLAN is active. Battery status Charging –...

  • Page 19: Left Views

    Blue light indicates the hard drive and/or optical drive is being accessed. 4 in 1 CardReader (SDHC/MS/MMC/MS pro Memory Card) Wireless Button Power/Suspend Button  Press for 1~1.5 seconds to turn on the system. Press and hold for at least 4 seconds to turn off the ...

  • Page 20: Right View

    CRT Port HDMI Port Enhanced USB 2.0 Port Microphone/Audio Line-in Jack Stereo Headphone Jack DC In Right View USB 2.0 Port Optical Drive Modem Port (Optional)
  • Page 21 Ethernet / LAN Port Kensington Lock Battery Lock Battery Compartment Battery Release Latch...

  • Page 23: Getting Started

    Connecting the AC Adapter A universal AC adapter is provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. To connect the computer to an external power source:...
  • Page 24 Whenever possible, keep the AC adapter plugged into the notebook and an electrical outlet to recharge the battery. ’ ’ Hold the button down for a second or two and release. The Power- On Self Test (POST) runs automatically. After the POST is completed, the computer reads the operating system from the hard disk drive into computer memory (this is commonly referred to as “booting”...

  • Page 26: To Install The Battery Pack

    ’ ’ To Install the Battery Pack: To Remove the Battery Pack:...
  • Page 27 The installed battery pack charges automatically any time the computer is connected to the AC adapter and an external power source. It is a good idea to occasionally discharge the battery pack fully to preserve its operating performance.

  • Page 29: Using The Notebook Computer

    The LCD screen display can be adjusted by the following key combinations. Fn + F4 Changes Display Mode: LCD-only, CRT-only and LCD&CRT. Fn + F7 Decrease the brightness level. Fn + F8 Increase the brightness level. LCD Care LCD screens are delicate devices that need careful handling. Please pay attention to the following precautions: When you are not using the computer, keep the LCD screen closed to protect it from dust.
  • Page 30 You can switch between these display configurations by pressing the key combination [Fn] + [F4]. ’ ’ Action System Control Fn + Esc Enable/Disable Bluetooth Fn + F1 Enters Suspend Mode. Fn + F2 Enters the Silent Mode. Fn + F3 Mute/Unmute Audio/ PC beep to Output Fn + F4 Changes Display Mode: LCD-only, CRT-only and...
  • Page 31 Num Locks On/Off Scroll Locks On/Off WLAN On/Off Fn + F10 BlueTooth On/Off 3G On/Off Fn + F12 Brightness Fn + F7/F8 Mute On/Off Fn + F3 Volume Fn + F5/F6 OSD-Bar Icon Caps Locks On Num Locks On Scroll Locks On Silent Mode ON Touchpad Off WLAN On...
  • Page 32 Vertically - Right or Left Horizontally Top or Bottom Live Power is a saving scheme technique that provides saving your battery consumption by disabling some devices thus extending the battery life. Click on the Live Power icon from the lower right bar of your screen to open up the Live Power Display.

  • Page 33: Power Saving Mode

    Power off Available Available Available Available Available LAN/WLAN/ HDMI/ Bluetooth Enable Available Available Available advance available available power engine Available Available Available Available Turbo mode available This Live Power application provides a super saving options if the following items are selected: Power Off LCD panel Enable advance power saving engine Power Saving Mode...

  • Page 34: Normal Mode

    Normal Mode LCD Brightness: Level 5 HDD Off: Idle after 30 minutes CPU Speed: Maximum level Sleep: Idle after 1 hour LCD Off: Idle after 15 minutes Hibernate: Idle after 2 hours High Performance Mode LCD Brightness: Level 5 HDD Off: Never CPU Speed: Maximum level Sleep: Never LCD Off: Never...

  • Page 35: Dvd Play Mode

    DVD Play Mode LCD Brightness: Level 5 HDD Off: Idle after 4 hours CPU Speed: Maximum level Sleep: Idle after 1 hour LCD Off: Idle 4 hours Hibernate: 2 hours Dynamic Switch Mode...
  • Page 36 CPU Loading Battery High Middle plus Middle life% 50% up 30% up 4%up <4% level High Performance High Performance High Performance Normal mode mode mode mode level High Performance High Performance Normal Normal mode mode mode mode level High Performance Power Normal mode Normal mode...

  • Page 37: Touchpad Precautions

    TouchPad Precautions The TouchPad is a pressure sensitive device. Please take note of the following precautions. Make sure the TouchPad does not come into contact with dirt, liquids or grease. Do not touch the TouchPad if your fingers are dirty. Do not rest heavy objects on the TouchPad or the TouchPad buttons.

  • Page 38: The Battery Power System

    The power system is comprised of two parts, the AC Adapter and the battery system. The AC Adapter converts AC power from a wall outlet to the DC power required by the computer. The Battery Power System Before using the computer on battery power for the first time, check the battery status icon on the Windows Toolbar to make sure the battery is fully charged.

  • Page 39: Automatic Battery Pack Charging Function

    notebook. If the battery is completely without power go to the next step. Otherwise, let the battery run down until the battery low-low warning beeps are heard. The system will automatically enter Suspend mode. Turn the notebook off. Connect the AC adapter and let the battery fully recharge.

  • Page 40: Battery Low Warning

    Battery Low Warning When the pack initially reaches the “Battery Low” state approximately 7 ~ 10 minutes of the usable battery life is left. You will hear an audible beep signal every 15 seconds alerting you to the “Battery Low” status. When the battery power reaches the “Battery Low Low”...
  • Page 41 If this key combination does not shut down the notebook, you can reset the notebook by using the notebook’s power button. Should the notebook lock up for some reason, pressing this button powers the notebook off. To adjust the brightness on the LCD screen, press and hold down the [Fn] key in the lower left hand corner of the keyboard and press the [F8] key to increase the brightness or [F7] to decrease the brightness.

  • Page 42: Help Windows

    Help Windows For Windows 7 help, click Start Help and Support icon will open the dialog box. Desktop Desktop may vary differently on the software installed in your notebook with different or additional shortcuts.

  • Page 43: Recycle Bin

    Recycle Bin Used for storing deleted files in case you want to recover and save it in your system. The files will only be deleted from the Recycle Bin permanently only if you empty it by right clicking your mouse and select the “Empty Recycle Bin”.
  • Page 44 The Start menu allows you to adapt and show the programs used most frequently. If you wish to keep an item, right click the item and click Pin to Start menu. Log Off will enable the current user to log off and allows a new user to log on.
  • Page 45 From an empty spot on the Taskbar, right click your mouse and select the Properties, remove the checked mark on the Auto-hide the taskbar. It is in this area that you can change how Windows looks and works. Click Start  Control Panel dialog box. There are two interfaces –...
  • Page 49 “ ” “ ”...

  • Page 52: Running Bios Setup

    The Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/Output System). It runs and maintains a variety of hardware functions. It is menu-driven software, which allows you to easily configure and change the settings. The BIOS contains manufacture’s default settings for the computer’s standard operations.

  • Page 53: Info Setup

    Function Key Command Description Leaves a sub-menu to return to the Exit previous menu OR exits the BIOS setup while saving changes. Enter Go to Sub Screen Shows the Sub Menu General Help Shows the Help Screen Default Set to default Saves changes and reboots the Save and Exit computer.

  • Page 54: Main Setup

    Main Setup Under this menu, you may change time/date and view basic processor and system memory information.

  • Page 55: Advanced

    Advanced...

  • Page 56: Security

    Security Boot Setup...

  • Page 57: Exit Setup

    Exit Setup...

  • Page 59: Vga Utilities

    You can click the touchpad or mouse right button and select the “Personalize” item.

  • Page 60: Adjust Resolution

    Adjust Resolution...

  • Page 61: Calibrate Color

    Calibrate Color Adjust Display Setting...

  • Page 62: Connect To A Projector

    Connect to a Projector Adjust Clear Type Text...

  • Page 64: Connection

    3G is the third generation of mobile phone standards and technology. 3G enable users a wide range of more advanced service while achieving greater network capacity through improved spectral efficiency. Press Fn + F12 to run the 3G application. Procedures in installing...
  • Page 65 the application Insert the SIM card into the SIM slot. Execute the application by pressing the Mobile Partner icon From the Mobile Partner display window, click on the “Tools” item Select the “Options”.
  • Page 66 Double click on the “Profile Management” and click on the “New” tab Click on the “OK” tab.
  • Page 67 On the next window, click on the “Connect” tab. The HSPA is successfully connected...

  • Page 69: Troubleshooting

    Your computer has been fully tested and complies with the system specifications before shipping. However, incorrect operations and/or mishandling may cause problems. This chapter provides a reference for identifying and correcting common hardware and software problems that you may encounter. When you encounter a problem, you should first try to go through the recommendations in this chapter.

  • Page 70: No Speaker Output

    Be sure all the device drivers are installed properly. For example, without the audio driver properly installed, the speakers and microphone will not work. If external devices such as USB camera, scanner, printer do not function correctly when connected to the system, it is usually the device’s own problem.

  • Page 71: The Hard Disk Drive Does Not Work Or Is Not Recognizable

    Go to [Start > Settings > Control Panel] and double-click the Multimedia icon (or Sounds and Audio Devices icon). In the Volume or Audio page, make sure that the audio codec mentioned in the spec is the default recording device. The hard disk drive does not work or is not recognizable If you had just performed a hard disk upgrade, make sure the...

  • Page 72: The Hard Disk Takes Longer To Read A File

    Many browsers store files in the hard drive as a cache to speed up the performance. Check the program’s Online Help for instructions on decreasing the cache size or on removing temporary Internet files. Empty the Recycle Bin to create more disk space. When you delete files, Windows saves them to the Recycle Bin.

  • Page 73: The Built-In Touch Pad Performs Erratically

    down or powering up. The built-in touch pad performs erratically Make sure there is no excess perspiration or humidity on your hand when using the touch pad. Keep the surface of the touch pad clean and dry. Do not rest your palm or wrist on the surface of the touchpad while typing or using the touch pad.

  • Page 74: The Post Does Not Show An Increased Memory Capacity When You Have Already Installed Additional Memory

    The POST does not show an increased memory capacity when you have already installed additional memory Certain brands of memory module may not be compatible with your system. You should ask your vendor for a list of compatible DIMM. The memory module may be defective. The O/S issues an insufficient memory error message during operation This is often a software or Windows-related problem.

  • Page 75: Windows Crashes Or Freezes When You Remove The Pc Card

    Windows crashes or freezes when you remove the PC card Make sure you have <Stop> the PC card before removing it. Double-click the Safely Remove Hardware icon at the lower right corner of the task bar and select the card you wish to stop.

  • Page 76: The Usb Device Does Not Work

    The USB device does not work Check the settings in the Windows Control Panel. Make sure you have installed the necessary device drivers. Contact the device vendor for additional support. Unable to use the External USB Device Detach the external device; insert it into the Enhanced USB port.

  • Page 78: Specification

    O.S. Supports Windows 7 Home Premium Intel Arrandale MCP Processor support, Dual core ,32nm, 3 MB L3 Cache,1066MHz, TDP: 35 W Memory DDRIII 800/1066/1333 MHz support RAM socket * 2 System DDRIII up to 4 GB total, depends on module availability Core Logic Intel Calpella Arrandale + Ibex Peak(HM55)
  • Page 79 LAN Controller Supports 10/100 Mb/Sec (8103EL-VB) or 10/100/1000Mb/Sec (8111DL). PCI-E interface Wireless LAN PCI-E interface Half-Card size IEEE 802.11 B/G w/Single antenna IEEE 802.11n compatible (WO WiFi logo) Camera CCD (Optional) Support 1.3M / 1.3M HD / 2.0M Camera Keyboard 339.7mm length skirt type KB US / UK 100 Keys KB support Pointing Device...
  • Page 80 8 cells, 14.6V/4400mAh/ATL(4S2P)  Getac I58-4S4400-M1A2 AC-Adapter Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, LV5-19V / LV4-20V , 65 Watts., 2 pin / 3pin Lite-On Technology Corporation PA-1650-65 (65W, 2pin) Delta Electronic, Inc. ADP-65JH AB (65W, 2pin) ADP-65JH BB (65W, 3pin) ADP-65HB AD (65W, 2pin) Li Shin international Enterprise Corporation..
  • Page 81 CE, R&TTE report/document Safety CB/CCC...
