Summary of Contents for ECS GQ Notebook

  • Page 1 GQ Notebook...
  • Page 3  Copyright 2003  All Rights Reserved. Manual edition, August 2003 The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instruction manual may cause harmful interference to radio communications.
  • Page 5 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Shielded interface cables and a non-shielded AC power cord must be used in order to comply with emission limits. This equipment is to be used with power supply: I/P: 100-240 Vac, 50-60Hz, 1.6A max O/P: 19Vdc, 3.16A...
  • Page 6 For pluggable equipment, that the socket-outlet shall be installed near the equipment and shall be easily accessible. Please keep this equipment from humidity. Lay this equipment on a reliable surface when isntall. A drop or fall could cause injury. Make sure to use the right voltage for the power source when connecting the equipment to the power outlet.
  • Page 7 60°C (140°f), it may damage the equipment. The unit can be operated at an ambient temperature of max. 35°C. The sound pressure level at the operators position according to IEC 704-1: 1982 is equal or less than 70 dB(A). Power Cord Requirements The power cord set used with the AC adaptor must meet the requirements of the country where you use the AC adaptor, whether it is 100-120 or 200-240 Vac.
  • Page 8 followed to reduce the risk of fire, electric shock and injury to persons. These precautions includes the following: Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 9 This Mobile PC system is designed for years of productive and pleasurable computing. Use this section to keep notes about details of your purchase. Update this section when you add new options. Date of Purchase: Dealer’s Name: Phone: Address: E-Mail Address: WWW Site: Serial Number: CPU Type:...
  • Page 11 Chapter 1...
  • Page 12 Your Mobile PC can easily stand temperature extremes but it doesn’t like rapid changes in temperature, like going from the cold outdoors to a warm office. Rapid changes in temperature can cause water droplets to condense inside your case, threatening to damage the electronic parts inside.
  • Page 13 • Purchase a chair with armrests and good back support. Don't slouch when sitting; keep your back straight. • Try to place the LCD panel or external monitor so that there is little glare from the sun on the monitor. •...
  • Page 14 At any time you can tilt the display toward or away from you to a comfortable viewing position. To avoid damage to the display panel: 1. Try not to slam the display upon closing it. 2. Try not to place any object on top when it is closed or open. 3.
  • Page 15: Lcd Screen

    Each of these features is briefly described below. LCD Screen Your Mobile PC computer is equipped with a replaceable color Liquid Crystal Display (LCD) screen that supports up to 14.1” or 15” LCD resolution. A built-in backlight allows you to comfortably view the screen even when ambient lighting is low.
  • Page 16 Indicates when the system LAN is functioning. TouchPad The TouchPad is hardware-compatible with the IBM PS/2 mouse and software-compatible with the Microsoft mouse. TouchPad Buttons The buttons below the TouchPad correspond to the left and right buttons on a standard mouse.
  • Page 17 LCD Cover Release Latch Slide this latch to the right to open the LCD cover. LCD Cover Release Latch USB Port Modem Port Headphone Jack Ventilation Opening LAN Port Microphone Jack 15 -...
  • Page 18: Microphone Jack

    Ventilation Opening Please don’t block this opening during operation of the system. The LAN Port This jack provides a standard RJ-45 connection for integration with an existing network or a high-speed (DSL or cable) connection via a network cable. When using a LAN, please use an EMI Shielding Cable to minimize an inteference when transmitting.
  • Page 19: Headphone Jack

    Headphone Jack You can plug an external speaker, headphone or connect the line out jack to an audio device such as a cassette recorder to record the Mobile PC 's audio output. 17 -...
  • Page 20: Battery Charge

    These three LED indicators are separately program for the following functions: Power On, Power On This indicator will lit when the Mobile PC is powered On. Battery Charge This indicator will lit orange when the battery is in charging status. The indicator will shut down when the battery is fully charged.
  • Page 21 DVD-ROM DC IN Connector DVD-ROM Your Mobile PC comes with a 8X DVD-ROM. DC IN Connector Plug the AC adapter into this connector. 19 -...
  • Page 22: Parallel Port

    Kensington Lock Parallel Port USB Ports Ventilation Opening TV Out Port CRT Port Ventilation Opening Ventilation Opening Please don't block this opening during operation of the system. Kensington Lock Allows you to connect a special computer lock to secure your system. You can purchase a lock at most computer retailers.
  • Page 23: Usb Ports

    External CRT Port This port allows you to easily connect an external VGA/SVGA display monitor into your Mobile PC using the 15-pin female connector. USB Ports Your computer includes two Universal Serial Bus (USB) port. USB is the latest development in Plug and Play technology.
  • Page 24: Battery Release Latch

    Expansion Compartment Battery Release Latch Hard Disk Compartment Battery Compartment Expansion Compartment This compartment will serve as an expansion to upgrade your RAM module. Battery Release Latch Lift up this latch to release the battery from its bay. Hard Disk Drive Your computer includes a 2.5-inch IDE hard disk drive (9.5mm in height).
  • Page 25: Battery Compartment

    Battery Compartment Your Mobile PC comes equipped with a factory-installed battery pack module. After the battery runs down, the module can be removed and replaced with a charged battery. 23 -...
  • Page 26 Chapter 2...
  • Page 27 universal adapter provided to supply your computer with power and also charge the computer’s battery pack. The adapter’s AC input voltage can range anywhere from 100 to 240 volts, covering the standard voltages available in almost every country. power cord adapter requires three-hole...
  • Page 28 Whenever possible, keep the AC adapter plugged into the Mobile PC and an electrical outlet to recharge the battery. Never turn off or reset your Mobile PC while the hard disk is in use and the HDD status icon is lit; doing so can result in loss or destruction of your data.
  • Page 29 The system provides you with a removable battery pack that does not provides the computer with information about its power status. Your computer comes with a rechargeable removable battery pack that lets you operate the computer without an external power source. When the removable battery pack is fully charged, you can operate the computer for approximately 1.5 hours under the following conditions: •...
  • Page 30 The removable battery pack should already be inserted in your Mobile PC when you unpack it. If not inserted, follow these directions: Turn over the Mobile PC with the front of the unit facing you and place it on a solid, flat surface.
  • Page 31 Turn off the Mobile PC , and disconnect the AC adapter. Close the LCD panel and turn it over and place it on a solid, flat surface. Lift the release latch to release the battery from the bay. At this time the battery will now be angled slightly out of the bay.
  • Page 32 The installed removable battery pack charges automatically any time the computer is connected to the AC adapter and an external power source. It is a good idea to occasionally discharge the battery pack fully to preserve its operating performance.
  • Page 33 Chapter 3 31 -...
  • Page 34 The LCD screen display can be adjusted by the following key combinations. KEYS FUNCTIONS [Fn] + [F7] Decreases the brightness level. [Fn] + [F8] Increases the brightness level. [Fn] + [F12] This key combination toggles the display between the LCD, CRT, simultaneous LCD/CRT.
  • Page 35 • TV+ CRT • TV only You can switch between these display configurations by pressing the key combination [Fn] + [F12]. To shift the display screen from your computer to the TV screen, you will have to utilize the VGA utility function by executing the VGA Display function.
  • Page 36 When the numeric keypad is engaged, the NumLock icon will appear in the System Window. The keypad is activated by pressing the [Fn] + [NumLk] key. If an external keyboard is connected, pressing the NumLock key on either the Mobile PC or external keyboard will enable/disable NumLock of both keyboards in unison.
  • Page 37 [Fn] + [F3] Decreases the speaker volume. [Fn] + [F4] Increases the speaker volume. [Fn] + [F7] Decreases the brightness level. [Fn] + [F8] Increases the brightness level. [Fn] + [F12] This key combination toggles the display between the LCD, CRT, simultaneous LCD/CRT.
  • Page 38 The TouchPad is a pressure sensitive device. Please take note of the following precautions. • Make sure the TouchPad does not come into contact with dirt, liquids or grease. • Do not touch the TouchPad if your fingers are dirty. •...
  • Page 39 The system will only enables you to use one tracking device whether it is an internal or external tracking device. Data storage and retrieval are two of the most fundamental tasks you will perform when working with your computer. The Mobile PC is equipped with a hard disk drive (HDD). The HDD is removable allowing for easy upgrades.
  • Page 40 • Do not write or place objects on the surface of the disc. • Store discs in a cool dry place not to damage the disc. • Do not use benzene, thinners, or cleaners with detergent. Only use CD-ROM/DVD- ROM cleaning kits. •...
  • Page 41 Do not insert any foreign objects into the disc tray. If you experience difficulty when ejecting the CD disk tray, stretch a paper clip (or use a pin or a thin metal rod) and insert it into the emergency eject hole located on the right side of the front panel.
  • Page 42 This section contains information on the Mobile PC ’s power system, including the AC Adapter, the battery system, recharging the battery, and tips for conserving battery power. The power system is comprised of two parts, the AC Adapter and the battery system. The AC Adapter converts AC power from a wall outlet to the DC power required by the computer.
  • Page 43 Turn the Mobile PC off. Connect the AC adapter and let the removable battery fully recharge. When the removable battery charge indicator turns off, the battery is fully charged. Turn On the Mobile PC , let the removable battery run down until the battery is in low- low state and you hear a warning beeps.
  • Page 44 In the “Control Panel” double click the “Power Options” icon to display the “Power Options Properties” as shown on the right screen. Power Scheme In setting your power options, click on the “Power Scheme” tab to select the power scheme most appropriate for you in using your computer. Settings for Portable/Laptop power scheme Under this item you are allowed to set the time setting for the system to enter the stand by mode whether you are operating the system by battery or AC power source.
  • Page 45 You should change your battery or switch to outlet power immediately to keep from losing your work. In the “Control Panel” double click the “Power Options” icon to display the “Power Options Properties” as shown on the right screen. Power Scheme In setting your power options, click on the “Power Scheme”...
  • Page 46: Power Scheme

    Current power source: AC power This indicates the Mobile PC Total battery power remaining: is operated with an AC power source. If the battery charge drops below a certain voltage level, a beeping sound will prompt you to save your work and turn off the computer, or connect the AC adapter. The message is : You should change your battery or switch to outlet power immediately to keep from losing your work.
  • Page 47 Under this item you are allowed to set the time setting to turn off the hard disks either operated by battery or AC power source. Power Meter Click on the “Power Meter” tab to display the type pf power source you are using to operate your Mobile PC computer.
  • Page 48 4. Operates automatically in the background.
  • Page 49 Control Panel Interface AMD PowerNow! Technology and Windows®XP To take advantage of AMD’s power management capabilities, Microsoft integrated support for AMD PowerNow! Technology into its new Windows®XP operating system. The power management control panel in Windows®XP, know as “PowerScheme”, is designed to provide the user with easy-to –use interface.
  • Page 50 AMD PowerNow! technolgy and other Windows operating systems ® For some Mobile PC ’s running previous Microsoft Windows operating systems including Windows 98. Wndows Me, and Wndows 2000,AMD PowerNow! Technology drivers will be installed at the factory or as an option during the initial system set-up. If your system supports this and if the AMD PowerNow! technology drivers have been installed, a new tab should appear in the Wndows power options panel, titled "AMD PowerNow! Technology.”...
  • Page 51 Your battery now has 1 ~ 2 minutes of battery charge remaining. You must save your data or connect AC power immediately; otherwise, you may lose your data. Sound Meaning Continuous beeping Battery Low: Indicates that there is 5 to 6 minutes every 1 seconds charge remaining.
  • Page 52 After installing a software application package, you may be prompted to reset the system to load the changed operating environment. To reset the system, or “reboot,” press the [Ctrl] + [Alt] + [Delete] keys simultaneously. This is known as “warm boot.” This key combination acts as “software”...
  • Page 53 Chapter 4 51 -...
  • Page 54 Your Mobile PC is capable of providing you with efficient and productive mobile computing, it also has the speed and capacity to service as a desktop system. This chapter discusses those functions of your Mobile PC that are typical of desktop systems.
  • Page 55 The Mobile PC is equipped with hot-key volume controls: Pressing the [Fn] + [F3] hot-key combination decreases the audio output volume, press the [Fn] + [F4] hot-key combination increases the audio output volume. Your Mobile PC comes equipped with an integrated sound system capable of providing you with quality audio sound through the built-in speakers or through external speakers connected via the system ports.
  • Page 56 To expand your computing capabilities, you can add a variety of external devices to your computer. You may, for example, want to add a mouse, modem, or a printer. Connect peripheral devices to the computer's interface ports as shown below:...
  • Page 57 55 -...
  • Page 58 Chapter 5...
  • Page 59 The BIOS (Basic Input and Output System) Setup program is a menu driven utility that enables you to make changes to the system configuration and tailor your system to reflect installed hardware or alter system performance. When the Mobile PC is turned back on, the system is configured with the values stored in CMOS.
  • Page 60 Set the time and date. Configure disk drives. Configure basic system performance parameters. Configure I/O support for the Mobile PC. To access the menu bar items, press the up or down arrow key on the keyboard until the desired item is highlighted. At the bottom of the Setup screen you will notice a legend bar.
  • Page 61 Note that a right pointer symbol appears to the left of certain fields. This pointer indicates that a submenu can be launched from this field. A submenu contains additional options for a field parameter. To call up a submenu, simply move the cursor to highlight the field and press the [Enter] key.
  • Page 62 When the Setup program is accessed, the following screen appears: The current values for each category are displayed. Enter new values through the keyboard . Select one of these hard disk drive icons to configure the hard disk drive named in the option.
  • Page 63 When the Setup program is accessed, the following screen appears: Set this option to select the CPU/DRAM base frequency for your system. The settings are 100/100MHz or 100/133 MHz Set this option to Enabled to instruct AMI BIOS to boot quickly when the computer is powered on.
  • Page 64 The settings are Disabled or Enabled (default value) This option sets the type of device for the first boot drives that the AMIBIOS attempts to boot from after AMIBIOS POST completes. The settings are Disabled, HDD (default value), CD-ROM and USB FDD. This option sets the type of device for the second boot drives that AMIBIOS attempts to boot from after AMIBIOS POST completes.
  • Page 65 This option enables password checking every time the system boots or when you run AMIBIOS Setup. If Always is chosen, a user password prompt appears every time the computer is turned on. If Setup is chosen, the password prompt appears if AMIBIOS is executed.
  • Page 66 Set this optios to select keyboard language. The settings are Standard (default value) or Brazil-PT This is only a display-only item and cannot be altered. This is only a display-only item and cannot be altered.
  • Page 67 This field allows you to choose the television display option when using the TV out port. The settings are PAL, NTSC (default value). 65 -...
  • Page 68 This field allows you to choose the television PAL system type. This option specifies the base I/O port address of the parallel port on the motherboard. This option specifies the parallel port mode. This option specifies the IRQ used by the parallel port. This is only a display-only item and cannot be altered.
  • Page 69 This field allows you to set the Supervisor password. To set the Supervisor password, highlight this field and press the [Enter] key. The following dialog box appears: Enter new supervisor password: The optimal default settings are best-case values that should optimize system performance.
  • Page 70 Quit without saving [Y/N] ?
  • Page 71 Chapter 6 69 -...
  • Page 72 There are two separate procedures on how to install the driver: AutoRun installation and Manual installation. • Follow the step-by-step procedures on the CD-ROM to execute the “AutoRun” application by selecting the topic of “Driver Installation”. • To re-run the “AutoRun” installation, please refer to the procedures on the “Manual Installation”...
  • Page 73 This driver must be installed into your system to fully utilize the hotkey function of Internet, Email, Mute/Unmute, Volume. Insert the CD-ROM Driver into your CD-ROM drive. Click “Start” and Select “Run”. Type the following: D:\Utility\Hotkey\Win98\Setup.exe (If D is not your CD-ROM drive, substitute D with the correct drive letter).
  • Page 74 Insert the CD-ROM Driver into your CD-ROM drive. Click “Start” and Select “Run”. Type the following: D:\Utility\Touchpad\98 & ME\Setup.exe ( for Win98SE/ME) or D:\Utility\Touchpad\2K &XP\Setup.exe ( for Win2K/XP)(If D is not your CD-ROM drive, substitute D with the correct drive letter).. Click on “Setup”...
  • Page 75 Insert the CD-ROM Driver into your CD-ROM drive. Click “Start” and Select “Run”. Type the following: D:\keyboard\keyboard\Setup.exe (If D is not your CD-ROM drive, substitute D with the correct drive letter).. Click on “Setup” to begin the Installation Wizard. Follow the Wizard’s on-screen instructions to complete the installation. Restart the system.
  • Page 76 To install the driver manually, follow the step-by-step procedures described on each individual section for a more clear installation. To install the USB20 driver you must first remove the currently installed driver. Insert the CD-ROM Driver into your CD-ROM/DVD-ROM drive. Click “Start” and Select “Run”.
  • Page 77 right button to select the "Properties" item. Click on the "Hardware" tab from the "System Properties" dialog window. Click on the "Other Device" (denoted by a yellow mark symbol), select the "Universal Serial Bus (USB) Controller". Click the "Update Driver" tab and select the "Install the software automatically (Recommended)"...
  • Page 78 Utility\WirelessLAN\Usermanual\Usermanual.pdf Please follow these instructions to install the LAN driver: From your screen, click on the "My Computer" icon and use your mouse or touchpad right button to select the "Properties" item. Click on the "Hardware" tab from the "System Properties" window. Click on the “Device Manager”...
  • Page 79 Double click on the "PCI Ethernet Controler (for Win98SE) or "Network Adapter" (for WinME) (denoted by a yellow mark symbol). Click the "Update Driver" tab tab on the “Driver” item and select the “Next”. Select the "Specify the location of the driver (Advanced)" item. Select the “Specify a location”.
  • Page 80 Please follow these instructions to install the Modem driver: From your screen, click on the "My Computer" icon and use your mouse or touchpad right button to select the "Properties" item. Click on the “Device Manager” and select the “PCI Card” item. Use your mouse cursor to double click the “Reinstall Driver”...
  • Page 81 After you have restarted Windows, open the “Control Panel” and double click on the “Display” icon. From the “Display Properties” window, select the “Settings” tab and click on the “Advanced” tab to enter the "SiS 740 Properties" window. You will notice three new entries have been made in the Display Properties window: Display Modes, Video Setting, and 3D Settings.
  • Page 82 This define the two status of Single , Mirror and Multi Monitor (when an external monitor is connected to your Mobile PC ). • When the "Single" is selected, the display can only be seen on the Mobile PC LCD panel or external monitor or TV. •...
  • Page 83 OPTION: Single This function will only show one single display whether it be on your Mobile PC or external monitor. OPTION: Mirror (Simultaneous Display) This function supports two simultaneous display paths with the features of LCD/CRT or CRT/TV). Click on the “Control Panel” and double click on the “Display” icon. Click on the “Settings”...
  • Page 84 on the “Settings” tab to enter the “Display Properties” window. Use the cursor to click on the Monitor “2” screen on the sub-screen of the “Display Properties” window. A message is shown on your screen to ask you whether to enable the monitor that you have chosen.
  • Page 85 From the "Setting", you can also adjust the video of your display to overlay, contrast or brightness. 83 -...
  • Page 86 This setting lets you modify the 3D display performance. Modify the speed and quality of your 3D display. You can adjust the right color for your window screen by moving the “Brightness” adjustment window to increase or decrease the right resolution for your screen display.
  • Page 87 85 -...
  • Page 88 After you have restarted Windows, open the “Control Panel” and double click on the “Display” icon. From the “Display Properties” window, select the “Settings” tab and click on the “Advanced” tab to enter the "SiS 740 Properties" window. You will notice four new entries have been made in the "Utility Manager" window: Gamma Correction, Video Setting, Driver Mode Setting and Product File Information.
  • Page 89 You can adjust the right color for your window screen by moving the “Tint” adjustment window. Adjust the "Brightness" to increase or decrease the right resolution for your screen display. 87 -...
  • Page 90 This dialog box has the following scroll bars and buttons for controlling the color components of the video image. Use this scroll bar to adjust the overall intensity of light emitted by the video display. Use this scroll bar to adjust the contrast level between the bright and dark areas of the video image.
  • Page 91 The SiS's driver allows five simultaneous outputs to LCD, LCD/CRT, CRT/TV, TV and CRT. Before proceeding, be sure the monitor is connected to the Mobile PC computer. 89 -...
  • Page 92 This define the three status of Single , Mirror and Multi Monitor (when an external monitor is connected to your Mobile PC ). • When the "Single" is selected, the display can only be seen on the Mobile PC LCD panel or external monitor or TV. •...
  • Page 93 Use the [Fn] + [F12] hot keys to toggle between the LCD and external monitor display . If you prefer to use only one display in operating your system, press the [Fn] + [F12] hot keys will shut down the LCD display, external monitor display or both at this random order.
  • Page 95 Chapter 7 93 -...
  • Page 96 This chapter describes locating and solving problems that you may encounter while using your computer. Problems with your computer can be caused by something as minor as an unplugged power cord – or as major as a damaged hard disk. The information in this chapter is designed to help you find and solve minor problems.
  • Page 97 If you have been using battery power, connect the Mobile PC to an external power source and make sure that the battery has a charge. If you are using the Mobile PC with the AC adapter, check the power outlet, the power cord, and any power switches that may affect your computer.
  • Page 98 The Power-On Self Test (POST) runs every time you turn on or reset the Mobile PC. The POST checks memory, the main system board, the display, the keyboard, the disk drives, and other installed options. A few seconds after you turn on your computer, a copyright message appears on your display screen.
  • Page 99 A few common hardware problems and suggested solutions are presented in the table below: Problem: Be sure to first remove the current audio device from your system. Solution: Please follow the instruction on the installation of audio driver. Problem: Solution: Make sure that the computer is not in Suspend mode.
  • Page 100 Solution: The problem is beyond the scope of this manual. Contact technical support. Problem: Solution: Reboot the computer and run the BIOS system setup. Confirm the Setup parameters. If the same message is displayed after booting up again, contact technical support for assistance. Problem: Check that a CD is properly inserted in the drive.
  • Page 101 Solution: Try using another diskette or free up some space on the diskette. The disk drive is not operating. Contact your dealer for support. Problem: • Check the cable connection. • Check the mouse with another application to see if there is a software incompatibility problem.
  • Page 102 Chapter 8...
  • Page 103 Refer to the following instructions and illustration for information on upgrading your Mobile PC 's memory. Turn off the computer and disconnect the AC adapter and all peripherals. Turn the Mobile PC over so that the rear ports are facing you and locate the memory module compartment.
  • Page 104 Remove the screws that secure the RAM module compartment cover and set it aside in a safe place. Remove the compartment cover and then angling it up and out. If you need to install a higher capacity module, gently push the edge clips on both sides to release the module.
  • Page 105 You can easily swap the hard drive in your Mobile PC computer for a new one. You should back up your hard drive before swapping the hard drive. Make sure that before you install a new drive, all the files in your system should be backed up.
  • Page 106 The drive is attached to a special bracket that secures it to the Mobile PC computer. There are 4 screws hold the bracket. Remove the screws and set them in a safe place. Push the HDD slightly in the direction of the arrow as shown in the illustration to release it from the pins of the drive.
  • Page 107 To install the new HDD, you will need to align the tabs on the drive bracket with the slots on the bay. Press down gently on the drive bracket until it engages with the system. Do not force the drive into place this can bend the pins on the hard drive.
  • Page 108 Appendix A & &...
  • Page 109 • AMD Mobile Duron 1 GHz CPU. • 462 pin ceramic CPGA package. • With AMD Power Now! technology. • North Bridge SiS 740, South bridge SiS962L • USB 2.0 compatible • 128 MB DDR-RAM memory on board. • One 200 pin SO-DIMM type memory slots •...
  • Page 110 • HDSupport Enhanced IDE (PIO mode 4) and ATA5 (Ultra DMA 33/66/100 mode) 20GB Hard Drive • Easily up-gradable 2.5” 9.5mm HDD • 8x DVD-ROM Drive; 5.25” 12.7mm height • Fast IDE and ATAPI interface DVD-ROM Drive • Synaptics TouchPad •...
  • Page 111 • One parallel port supported EPP/ECP (25-pin female D-connector) • One S-video TV out port for TV • One DC input port for External AC adapter (2-pin DC jack) • One video port for external analog VGA monitor (15-pin female D-connector) •...
  • Page 112 • 4-cell Li-Ion battery pack (32.56Whr/2200mAhr) • 8-cell Li-Ion battery pack (53.28Whr/3600mAhr) • User interchangeable • Removable and rechargeable • 333.3 mm (W)x 274.8 mm (D) x 36.55 mm (H) • 13.14" (W) x 10.78" (D) x 1.33”(H) • 2.7kg (5.9 lbs) with 14.1” panel, 4 cell battery and DVD-ROM Drive installed •...
  • Page 113 • Non-operating: -200 to 30,000 feet above sea level. • Quick Guide • Driver CD • AC adapter • Power cord • Phone cord • Battery pack • System BIOS: AMI BIOS • Supported Operating Systems Optional Windows 98SE Optional Windows XP or above version Optional Windows ME or above version Optional Windows 2000 or above version •...
  • Page 114 Wireless LAN driver USB20 driver If you are still experiencing problems with your computer system, please try our website at: www.fryssupport.net Here, you will find the latest FAQ’s and latest driver downloads/bios updates for your system. If you cannot find the answers to your questions, there is a form that you can email us at on the website.
  • Page 115 EXCEPT AS EXPRESSLY STATED IN THIS LIMITED WARRANTY, GQ MAKES NO OTHER WARRANTIES OR CONDITIONS, EXPRESSED OR IMPLIED INCLUDING LIMITED IMPLIED WARRANTIES OF MERCHANTABILITY AND SUITABILITY FOR ANY PARTICULAR PURPOSE. EXPRESSLY DISCLAIMS WARRANTIES AND CONDITIONS THAT ARE NOT STATED IN THIS LIMITED WARRANTY STATEMENT.
  • Page 116 or software usage. It does not cover ANY software package whether or not it is contained in the product. Proof of purchase in the form of a “Bill of Sale/ Invoice” (which is evidence that the product is within the warranty period) must be presented to obtain warranty service.
  • Page 117 product, (b) improper operation or maintenance of this product, (c) connection to improper voltage supply, (d) attempted repair by any party other than a GQ authorized service center or (e) tampering with the internal components. This limited warranty does not apply when the malfunction results from the use of this product in conjunction with accessories, components, products or ancillary or peripheral equipment where it is determined by GQ that there is no fault with the product itself, but rather the...
