  • Page 3 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.1 Disclaimer The information in this document is subject to change without notice.

  • Page 4: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations.

  • Page 5: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction....................1 Features.......................2 Motherboard Components...............4 7 7 7 7 7 Chapter 2 Installing the Motherboard Safety Precautions..................7 Choosing a Computer Case...............7 Installing the Motherboard in a Case............7...
  • Page 6 Integrated Peripherals..............32 Power Management Setup............36 PNP/PCI Configurations.............39 PC Health Status................40 Frequency/Voltage Control............41 Load Fail-Safe Defaults..............42 Load Optimized Defaults.............42 Set Supervisor/User Password............42 Save & Exit Setup Option.............43 Exit Without Saving..............43 45 45 45 45 Chapter 4 Using the Motherboard Software About the Software CD-ROM..............45 Auto-installing under Windows 98/ME/2000/XP........45 Running Setup................46 Manual Installation..................48...

  • Page 7: Introducing The Motherboard

    Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the 760GX-M motherboard. This motherboard is a high perfor- mance, enhanced function motherboard that supports Socket 754 AMD K8 processors for high-end business or personal desktop markets. The motherboard incorporates the SiS760GX Northbridge (NB) and SiS964 Southbridge (SB) chipsets.

  • Page 8: Features

    Feature Processor This motherboard uses a 754-pin socket that carries the following features: • Accommodates AMD K8 processors • Supports HyperTransport interface for AMD K8 processors HyperTransport Technology is a point-to-point link between two devices, it enables integrated circuits to exchange information at much higher speeds than currently avail- able interconnect technologies.
  • Page 9 Expansion Options The motherboard comes with the following expansion options: • Three 32-bit PCI slots • One AGP slot • Two IDE connectors support up to four IDE devices • One floppy disk drive interface • Two 7-pin SATA connectors This motherboard supports Ultra DMA bus mastering with transfer rates of 133/100/66 MB/s.

  • Page 10: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 11 Table of Motherboard Components LABEL COMPONENT 1 DIMM1~2 184-pin DDR SDRAM slots 2 CPUFAN1 CPU cooling fan connector 3 CPU Socket Socket 754 for AMD K8 processor 4 ATX2 4-pin +12V power connector 5 IDE2 Secondary IDE connector 6 IDE1 Primary IDE connector 7 FDD1 Floppy disk drive connector...
  • Page 12 Memo Introducing the Motherboard...

  • Page 13: Installing The Motherboard

    Chapter 2 Installing the Motherboard Safety Precautions • Follow these safety precautions when installing the motherboard • Wear a grounding strap attached to a grounded device to avoid damage from static electricity • Discharge static electricity by touching the metal case of a safely grounded object before working on the motherboard •...

  • Page 14: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 15: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Setting (default) Type Description 1-2: NORMAL 2-3: CLEAR 3-pin CLEAR CMOS Before clearing the CMOS, make sure to turn the system off.

  • Page 16: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin con- necting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPUFAN1. Connect the case cooling fan connector to CASFAN1. Connect the case switches and indicator LEDs to the PANEL1.

  • Page 17: Front Panel Header

    ATX1: ATX 20-pin Power Connector Signal Name Signal Name +3.3V +3.3V +3.3V -12V Ground Ground PS ON# Ground Ground Ground Ground Ground PWRGD +5VSB +12V ATX12V: ATX 12V Power Connector Signal Name Ground Ground +12V +12V Front Panel Header The front panel header (PANEL1) provides a standard set of switch and LED headers commonly found on ATX or micro-ATX cases.

  • Page 18: Installing Hardware

    Hard Drive Activity LED Connecting pins 1 and 3 to a front panel mounted LED provides visual indication that data is being read from or written to the hard drive. For the LED to function properly, an IDE drive should be connected to the onboard IDE interface. The LED will also show activity for devices connected to the SCSI (hard drive activity LED) connector.

  • Page 19: Cpu Installation Procedure

    Warning: Over-clocking components can adversely affect the reliability of the system and introduce errors into your system. Over-clocking can permanently damage the motherboard by generating excess heat in components that are run beyond the rated limits. This motherboard has a Socket 754 processor socket. When choosing a processor, consider the performance requirements of the system.

  • Page 20: Installing Memory Modules

    Installing Memory Modules This motherboard accommodates two 184-pin 2.5V unbuffered Double Data Rate (DDR) SDRAM (Synchronous Dynamic Random Access Memory) memory modules, and can sup- port DDR400/333/266/200 memory types. Each module can be installed with 1GB of memory, and its total maximum memory size is 4 GB. DDR SDRAM memory module table Memory module Memory Bus...
  • Page 21 Table A: Unbuffered DIMM Support for 754-pin Maximum DRAM 2 2 2 2 2 4.1. Numbers of DIMM 1 DIMM 2 Speed DIMMs single rank empty DDR400 DDR400 empty single rank DDR400 DDR400 double rank empty DDR400 DDR400 empty double rank DDR400 DDR400 single rank single rank...

  • Page 22: Installing A Hard Disk Drive/Cd-Rom/Sata Hard Drive

    Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your motherboard has a primary and secondary IDE channel interface (IDE1 and IDE2). An IDE ribbon cable supporting two IDE devices is bundled with the motherboard.
  • Page 23 About SATA Connectors Your motherboard features two SATA connectors supporting a total of two drives. SATA refers to Serial ATA (Advanced Technology Attachment) is the standard interface for the IDE hard drives which are currently used in most PCs. These connectors are well designed and will only fit in one orientation.

  • Page 24: Installing A Floppy Diskette Drive

    Installing a Floppy Diskette Drive The motherboard has a floppy diskette drive (FDD) interface and ships with a diskette drive ribbon cable that supports one or two floppy diskette drives. You can install a 5.25-inch drive and a 3.5-inch drive with various capacities. The floppy diskette drive cable has one type of connector for a 5.25-inch drive and another type of connector for a 3.5-inch drive.
  • Page 25 The AGP slot is used to install a graphics adapter that supports the 8X/4X AGP Slot AGP specification. It is AGP 3.0 compliant. PCI Slots This motherboard is equipped with three standard PCI slots. PCI stands for Peripheral Component Interconnect and is a bus standard for expansion cards, which for the most part, is a supplement of the older ISA bus standard.

  • Page 26: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: SPDIFO2: SPDIF out header This is an optional header that provides an S/PDIF (Sony/Philips Digital Interface) output to digital multimedia device through optical fiber or coaxial connector. Signal Name Function SPDIF digital output...
  • Page 27 SATA1/SATA2: Serial ATA connectors These connectors are use to support the new Serial ATA devices for the highest date transfer rates (150 MB/s), simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface. But maintains register compatibility and software compatibility with Parallel ATA.

  • Page 28: Connecting I/O Devices

    Connecting I/O Devices The backplane of the motherboard has the following I/O ports: PS2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard. Parallel Port (LPT1) Use LPT1 to connect printers or other parallel communications devices.

  • Page 29: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configura- tion status and provides you with options to set system parameters.

  • Page 30: Bios Navigation Keys

    Press DEL to enter SETUP Pressing the delete key accesses the BIOS Setup Utility: Phoenix-AwardBIOS CMOS Setup Utility: Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations...

  • Page 31: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this motherboard from the manufacturer’s Web site. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows: If your motherboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 32: Standard Cmos Features

    Standard CMOS Features This option displays basic information about your system. Phoenix-AwardBIOS CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy) Wed, Feb 25 2004 Item Help Time (hh:mm:ss) 9 : 33 : 26 Menu Level IDE Channel 0 Master IDE Channel 0 Slave Change the day, month, IDE Channel 1 Master year and century...
  • Page 33 If you are setting up a new hard disk drive that supports LBA mode, more than one line will appear in the parameter box. Choose the line that lists LBA for an LBA drive. IDE Channel 0/1 Master/Slave/Extended IDE Drive(Auto) Leave this item at Auto to enable the system to automatically detect and configure IDE devices on the channel.

  • Page 34: Advanced Bios Features

    Advanced BIOS Features This option defines advanced information about your system. Phoenix-AwardBIOS CMOS Setup Utility Advanced BIOS Features Hard Disk Boot Priority [Press Enter] Item Help CPU Internal Cache [Enabled] External Cache [Enabled] Menu Level Quick Power On Self Test [Enabled] Select Hard Disk First Boot Device...
  • Page 35 First/Second/Third Boot Device (Floppy/Hard Disk/CDROM) Use these three items to select the priority and order of the devices that your system searches for an operating system at start-up time. Boot Other Device (Enabled) When enabled, the system searches all other possible locations for an operating system if it fails to find one in the devices specified under the First, Second, and Third boot devices.

  • Page 36: Advanced Chipset Features

    The disk drive software monitors the internal performance of the motors, media, heads and electronics of the drive. The host software monitors the overall reliability status of the drive. If a device failure is predicted, the host software, through the Client WORKS S.M.A.R.T applet, warns the user of the impending condition and advises appropriate action to protect the data.
  • Page 37 HT_Width<In/Out> (Auto) This item shows HyperTransport ’s bus size of Local Descriptor Table (LDT). The bus size is automatically calculated by the CPU. Therefore, We strongly recommend that you do not change this setting. HT-Speed (800 MHz) This item shows the bus frequency of Local Descriptor Table. Its default is set as 800 MHz.

  • Page 38: Integrated Peripherals

    OnChip VGA Control (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility OnChip VGA Control Item Help VGA Share Memory Size [32MB] Menu Level : Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults...
  • Page 39 SIS OnChip IDE Device (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility SIS OnChip IDE Device Item Help Internal PCI/IDE [Both] IDE Primary Master PIO [Auto] Menu Level IDE Primary Slave PIO [Auto] IDE Secondary Master PIO [Auto]...
  • Page 40 SIS OnChip PCI Device (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility SIS OnChip PCI Device Item Help SIS USB Controller [Enabled] USB 2.0 Support [Enabled] Menu Level USB Legacy Support [Enabled] USB Mouse Support [Enabled]...
  • Page 41 IDE HDD Block Mode (Enabled) Enable this field if your IDE hard drive supports block mode. Block mode enables BIOS to automatically detect the optimal number of block read and writes per sector that the drive can support. It also improves the speed of access to IDE devices. Init Display First (PCI Slot) Use this item to specify whether your graphics adapter is installed in one of the PCI slots or is integrated on the motherboard.

  • Page 42: Power Management Setup

    Power Management Setup This option lets you control system power management. The system has various power- saving modes including powering down the hard disk, turning off the video, suspending to RAM, and software power down that allows the system to be automatically resumed by certain events.
  • Page 43 Power On After Power Fail (Always Off) This item enables your computer to automatically restart or return to its last operating status after power returns from a power failure. PM Wake Up Events (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility PM Wake Up Events IRQ [3-7, 9-15], NMI...
  • Page 44 Power Up by Alarm (Disabled) When set to Enabled, the following three fields become available: Month Alarm, Day of Month Alarm, and Time Alarm Upon arrival of the alarm time, it will instruct the system to wake up. When set to 0 (zero) for the day of the month, the alarm will power on your system every day at the specified time.

  • Page 45: Pnp/Pci Configurations

    PNP/PCI Configurations These options configure how PnP (Plug and Play) and PCI expansion cards operate in your system. Both the the ISA and PCI buses on the motherboard use system IRQs (Interrup ReQuests) and DMAs (Direct Memory Access). You must set up the IRQ and DMA assignments correctly through the PnP/PCI Configurations Setup utility for the motherboard to work properly.

  • Page 46: Pc Health Status

    PC Health Status On motherboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, temperatures and fan speeds. Phoenix-AwardBIOS CMOS Setup Utility PC Health Status Item Help Shutdown Temperature [Disabled] CPU Vcore Voltage Menu Level Memory Voltage CPU Temperature System Temperature...

  • Page 47: Frequency/Voltage Control

    Frequency/Voltage Control This item enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system. Phoenix-AwardBIOS CMOS Setup Utility Frequency/Voltage Control Item Help Auto Detect PCI Clk...

  • Page 48: Load Fail-Safe Defaults

    Load Fail-Safe Defaults This option opens a dialog box that lets you install fail-safe defaults for all appropriate items in the Setup Utility: Press <Y> and the <Enter> to install the defaults. Press <N> and then <Enter> to not install the defaults. The fail-safe defaults place no great demands on the system and are generally stable.

  • Page 49: Save & Exit Setup Option

    Save & Exit Setup Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu. Exit Without Saving Highlight this item and press <Enter>...
  • Page 50 Memo Using BIOS...

  • Page 51: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software CD-ROM The support software CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 52: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support Before installing the software from Windows Explorer, look for a file named README.TXT, INSTALL.TXT or something similar.
  • Page 53 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 54: Manual Installation

    Manual Installation Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your motherboard. Look for the chipset and motherboard model; then browse to the directory and path to begin installing the drivers.

  • Page 55: Sis964 Sata Raid Setup Guide

    Chapter 5 SiS964 SATA RAID Setup Guide Introduction for SiS964 SATA RAID Function The SiS964 S-ATA controller only support two serial ATA on two independent ports. The Serial ATA RAID is designed to provide a cost-effective, high performance RAID solution that adds performance and/or reliability to PC desktops and/or servers using Serial ATA/150 hard disks.

  • Page 56: Installing Software Drivers

    JBOD: (Just a Bunch of Drives). Also known as “Spanning”. Two or more hard drives are required. Several hard disk types configured as a single hard disk. The hard drives are simply hooked up in series. This expands the capacity of your drive and results in a useable total capacity.

  • Page 57: Bios Utility Operation

    Confirming Windows 98/Me Driver Installation From Windows 98/Me, open the Control Panel from “My Computer” followed by the System icon. Choose the “Device Manager” tab. Click the “+” in front of “IDE ATA/ATAPI Controllers” hardware type. The driver “SiS 180 IDE Dual Channel” and “SiS 180 IDE/RAID Controller” should appear.
  • Page 58 Create RAID • SiS964 controller support RAID 0, RAID 1 and JBOD. Creating a RAID 0 (Stripe) Array for Performance • SiS180 enables users to create striped arrays with 2, 3, or 4 drives. • SiS964 only supports 2 SATA drivers to create a stripe array. To create an array for best performance, follow these steps: Press <A>...
  • Page 59 Use < ↑ > < ↓ > to select disk, and press <Enter> to select disk, <Q> to exit. When you press <Enter> on the disk you wanted, the RAID Type will be changed from Single to RAID 0. An the disk you select first will be the SOURCE disk.
  • Page 60 Press <Q> again to exit this BIOS utility and the red message frame will show. Press <Y> and <Enter> to save changes. Once the array has been created, you will need to FDISK and format the array as if it were a new single hard drive. Creating a RAID 1 (Mirror) Array SIS964/180 enables users to create Mirror arrays with 2 drives only.
  • Page 61 Use < ↑ > < ↓ > to select disk, and press <Enter> to select disk, <Q> to exit. When you press <Enter> on the disk you wanted, the RAID Type will be changed from Single to RAID 1. The same as RAID 0, the disk you select first will be the SOURCE disk.
  • Page 62 Press <Q> again to exit this BIOS utility and the red message frame will show as the same as the creation of the RAID 0 array. Press <Y> and <Enter> to save changes. Once the array has been created, you will need to FDISK and format the array as if it were a new single hard drive.
  • Page 63 Press <Q> again to exit this BIOS utility and the red message frame will show as the same age as the creation of the RAID 0 array. Press <Y> and <Enter> to save changes. Once the array has been created, you will need to FDISK and format the array as if it were a new single hard drive.
  • Page 64 Caractéristiques Processeur Cette carte mère utilise un socket de 754 broches ayant les caractéristiques suivantes : • Reçoit des processeurs AMD K8 • Prend en charge l’interface HyperTransport pour les processeurs AMD La Technologie HyperTransport est une liaison point à point entre deux matériels, elle permet à...
  • Page 65 Options d’extension La carte mère est livrée avec les options d’extensions suivantes: • Trois logements PCI 32 bits • Un logement AGP • Deux connecteurs IDE prenant en charge jusqu’à quatre périphériques IDE • Une interface de lecteur de disquette •...
  • Page 66 Feature Prozessor Dieses Motherboard verwendet einen 754-Pin Socket mit den folgenden Eigenschaften: • Nimmt AMD K8-Prozessoren auf • Unterstützt HyperTransport Interface für AMD K8- Prozessoren HyperTransport Technologie ist ein Punkt-zu-Punkt Link zwischen zwei Geräten. Es ermöglicht integrierten Schaltkreisen einen Informationsaustausch mit wesentlich höherer Geschwindigkeit als bei gängigen Interconnect-Technologien.
  • Page 67 Erweiterungsoptionen Das Motherboard bietet die folgenden Erweiterungsoptionen: • Drei 32-Bit PCI-Steckplätze • Ein AGP-Steckplatz • Zwei IDE-Stecker, die bis zu vier IDE-Geräte unterstützen • Ein Steckplatz für ein Diskettenlaufwerk • Zwei 7-Pin SATA-Stecker Dieses Motherboard unterstützt Ultra DMA Bus-Mastering mit Transferraten von 133/100/ 66MB/s.
  • Page 68 Caratteristiche Processore La scheda madre utilizza una presa a 754 pin che offre le seguenti caratteristiche: • Compatibilità con processori AMD K8 • Supporto di interfaccia HyperTransport per processori AMD K8 La tecnologia HyperTransport consente il collegamento point-to-point fra due dispositivi e quindi un trasferimento di informazioni tra circuiti integrati molto più...
  • Page 69 Opzioni di espansione La scheda madre è dotata delle seguenti opzioni di espansione: • Tre slot PCI a 32 bit • Uno slot AGP • Due connettori IDE per il supporto di fino a quattro dispositivi IDE • Un’interfaccia per unità disco floppy •...
  • Page 70 Característica Procesador Esta placa principal usa un zócalo de 754-pin que lleva las sigtes. características: • Acomoda procesadores AMD K8 • Soporta la interfaz HyperTransport para procesadores AMD K8 La Tecnología HyperTransport es un vínculo punto a punto entre dos dispositivos, habilita circuitos integrados para intercambiar la información en velocidades más rápidas que las tecnologías de interconexión disponibles actualmente.
  • Page 71 Opciones de Expansión La placa principal viene con las sigtes. opciones de expansión: • Tres ranuras PCI de 32-bit • Una ranura AGP • Dos conectores IDE que soporta hasta cuatro dispositivos IDE • Una interfaz de la unidad de disco floppy •...
  • Page 72 Características Processador Esta motherboard usa uma ficha de 754 pin que possui as seguintes características: • Acomoda processadores AMD K8 • Suporta interface de HyperTransport para processadores AMD K8 Tecnologia de HyperTransport Té um link ponto-a-ponto entre dois dispositivos, permite circuitos integrados para trocar informação a velocidades muito mais elevadas que as disponíveis actualmente em tecnologias de interconexão.
  • Page 73 Opções de Expansão A motherboard é fornecida com as seguintes opções de expansão: • Três ranhuras PCI de 32 bit • Uma ranhura AGP • Dois conectores IDE que suportam até quatro dispositivos IDE • Um interface com drive de disco flexível •...
  • Page 74 機能 プロセッサ このマザーボードには、次の機能を持った754ピンソケットが一つあります： • AMD K8プロセッサ対応 • AMD K8 プロセッサのHyperTransport インターフェース対応 HyperTransport 技術とは、二つのデバイスを1対1( point-to-point)で接続する技 術であり、従来のインターコネクト技術に比較して、集積回路同士の情報交換を高速化 します。 チップセット SiS760GX Northbridge (NB)とSiS964 Southbridge (SB)チップセットは、実証され た信頼性と性能を持つ革新的で拡張性のあるアーキテクチャに基づいています。 • SiS760GX(NB) SiS MuTIOL でMuTIOL Media IOチップセットであるSiS760GX とSiS964 とを接続 • HyperTransport 技術をサポートで最大1600MT/秒の帯域幅を 提供 • AGP v3.0 で8X/4X と...
  • Page 75 拡張オプション 本マザーボードでは、次の拡張機能が利用できます。 • 32ビットPCIスロット x3 • AGPスロット x1 • IDEヘッダー (4つのIDEデバイスの接続を可能) • フロッピーディスクドライブインターフェイス x1 • 7ピンSATAコネクタ X2 このマザーボードは、133/100/66MB/秒の転送速度でのUltra DMAバスマスタリングを サポートします。 オンボードLAN (オプション) オンボードLANは、次の機能を提供します。 • 10Mb/秒および100Mb/秒N-way自動ネゴシエーション操作をサポート • 半/全二重動作をサポート • Wake-On-LANと遠隔wake-up機能をサポート • 全二重フロー制御(IEEE 802.3x)をサポート 統合の入出力ポート マザーボードには、次のI/Oポートやコネクタを揃えています。 • マウスとキーボード用のPS/2ポート x2 • シリアルポート x1 •...
  • Page 76 특성 프로세서 본 마더보드는 다음과 같은 특성을 지닌 754 핀 소켓을 사용합니다: • AMD K8 프로세서와 부합 • AMD K8 프로세서용 HyperTransport 인터페이스 지원 HyperTransport 기술은 두 장치간의 point-to-point 링크로, 집적 회로가 기존의 상호 연결 기술 보다 더 빠른 속도로 정보를 교환할 수 있다. 칩셋...
  • Page 77 확장 옵션 본 마더보드의 확장 옵션은 다음과 같다: • 32 비트 PCI 슬롯 3 개 • AGP 슬롯 1 개 • 최대 4개의 IDE 장치를 지원하는 IDE 커넥터 2 개 • 플로피 디스크 드라이브 인터페이스 1 개 • 7 핀 SATA 커넥터 2 개 본...
  • Page 78 功能 處理器 本主機板配備具㈲如㆘功能的754針插槽: ‧ 支援AMD K8處理器； ‧ 支援AMD K8 處理器的HyperTransport 介面。 HyperTransport 技術為以點對點方式連接兩台設備的技術，藉此，積體電路間能夠以 後高於現㈲各種內部連接技術(interconnect technology)技術的速度來交換㈾訊。 晶片組 SiS760GX北橋(NB)及SiS964南橋(SB)晶片組在研發設計㆖採用了創新且具擴充性之架構 ，具備㊝良的可靠性及性能。 SiS760GX(NB) ‧ 設置㈲SiS MuTIOL，用以連接SiS760GX 及SiS964 MuTIOL Media IO晶片組； ‧ 支援 HyperTransport 技術，提供高達1600MT/s 的頻寬； ‧ AGP v3.0 相容於8X/4X及快㊢功能； ‧ 支援高達128MB的顯示記憶體(採共享記憶體方式)； ‧ 內建㆒高效能256位元3D繪圖引擎，支援DirectX 8.1。 SiS964(SB) ‧...
  • Page 79 擴充選㊠ 本主機板包括㆘列擴充選㊠： • 3 個 32-bit PCI 插槽； • 1 個 AGP 插槽 ； • 2 個 IDE 接頭，支援 4個 IDE 裝置； • 1 個軟碟機介面； • 2個7針SATA插頭。 本主機板支援傳輸率133/100/66 MB/秒㆘的Ultra DMA 匯流排主控功能。 內建區域網路 (選購) 內建區域網路提供㆘列功能： • 支援 10Mb/s 及 100Mb/s N-way ㉂動㈿調作業； •...
  • Page 80 功能 处理器 主板使用一个 754-pin 插座，此插座具有以下特点： • 支持 AMD K8 处理器 • 支持用于AMD K8 处理器的 HyperTransport 接口 HyperTransport 技术是一种在两台设备间进行点到点连接的技术，它可以让集成电 路使用比当前互连技术更高的速度进行信息交换。 芯片组 SiS760GX 北桥 (NB) 和 SiS964 南桥 (SB) 芯片组是基于一种新型的、可扩展的架构 ，能提供已经证明的可靠性和高性能。 SiS760GX(NB) • SiS MuTIOL 将 SiS760GX 和 SiS964 MuTIOL Media IO 结 合...

  • Page 81: Onboard Lan

    扩展选项 此主板提供如下扩展选项： • 3 个 32 位 PCI 扩展插槽 • 1 个AGP 槽 • 2 个 IDE 接口，可支持 4 个 IDE 设备 • 1 个软驱接口 • 2 个 7-pin SATA 接口 主板支持 Ultra DMA 总线控制，传输速率可达 133/100/66MB/s。 Onboard LAN（可选） 板上集成的 LAN 提供以下功能： •...
  • Page 82 Характеристики Процессор Плата использует сокет 754-pin и обладает следующими характеристиками: • Поддерживает процессоры AMD K8 • Поддерживает интерфейс HyperTransport для процессоров AMD K8 Технология HyperTransport обеспечивает связь двух устройств по протоколу point- to-point, позволяя гораздо более быстрый обмен информацией между интегральными микросхемами, чем...
  • Page 83 AC’97 Аудио CODEC • Совместим со спецификацией AC’97 v2.3 • Высококачественный дифференциальный вход с CD • Поддержка режима двойного сэмплирования (96KHz) при прослушивании аудио-DVD • Совместимость с Direct Sound 3D Возможности расширения Существуют следуюшие опции расширения данной материнской платы: • Три...
  • Page 84 Cechy Procesor Ta płyta główna zaopatrzona jest w podstawkę dla procesorów z 754 nóżkami i charakteryzuje się następującymi cechami: • Pomieszcza procesory AMD K8 • Zabezpiecza interfejs Hiper Transportu dla procesora AMD K8 Technologia HiperTransportu jest protokołem komunikacji między dwoma urządzeniami, który umożliwia układom zcalonym wymieniać...
  • Page 85 AC’97 audio CODEC • Zgodny z AC’97 w wersji 2.3 • Wysokiej jakości różniczkowe wejscie CD • Obsługuje podwójne próbkowanie (96KHz) DVD audio playback • Zgodny z Direct Sound 3D Możliwości rozbudowy Płyta głwna wyposażona jest w następujące gniazda: • Trzy 32-bitowe gniazda PCI •...
  • Page 86 Vlastnosti Procesor Tato základní deska využívá 754kolíkovou patici nabízející následující vlastnosti: • Připojení procesorů AMD K8 • Podpora rozhraní HyperTransport pro procesory AMD K8 Technologie HyperTransport je přímým spojením mezi dvěma zařízeními, umožňující integrovaným obvodům výměnu informací vyššími rychlostmi, než jaké nabízejí současné technologie.
  • Page 87 Možnosti rozšíření Základní deska je dodávána s následujícími možnostmi rozšíření • Tři 32bitové patice PCI • Jedna patice AGP • Dva konektor IDE podporující až čtyři zařízení IDE • Jedno rozraní pro disketovou mechaniku • Dva 7kolíkové konektor SATA Tato základní deska podporuje řízení sběrnice Ultra DMA s přenosovými rychlostmi 133/ 100/66 MB/s.
  • Page 88 Caracteristici Procesorul Această placă de bază utilizează un soclu 754, având următoarele caracteristici: • Este destinată procesoarelor AMD K8 • Suportă interfaţa HyperTransport pentru procesoare AMD K8 Tehnologia HyperTransport este o legătură punct-la-punct între două aparate, care permite viteze mult mai mari de schimb al informaţiilor între circuitele integrate, decât cel asigurat de tehnologiile de interconectare actuale.
  • Page 89 Opţiuni de extindere Placa de bază este dotată următoarele posibilităţi de extindere: • Trei sloturi PCI de 32 biţi • Un slot AGP • Două conectoare IDE care suport cel mult 4 instrumente IDE • O interfaţă pentru unitate floppy •...
  • Page 90 Спецификация Процесор Тази дънна платка използва 754-щифтов цокъл (754-pin socket) със следните параметри: • поддръжка на процесори AMD K8 • поддръжка на интерфейс HyperTransport за процесори AMD K8 Технологията HyperTransport е връзка точка-до-точка (point-to-point) между две устройства, която предоставя възможност интегрираните вериги да обменят информация...
  • Page 91 Възможности за разширяване Дънната платка има следните разширителни възможности: • три 32-bit PCI слота • един AGP слот • два IDE конектора с поддръжка до четири IDE устройства • един конектор за флопидисково устройство • два 7-щифтови SATA конектораs Дънната платка поддържа шина Ultra DMA 133/100/66MB/s. Интегриран...
  • Page 92 Jellemző Processzor Ez az alaplap 754 tűs foglalattal rendelkezik, ennek jellemzői pedig a következők: • AMD K8-as processzornak szánták • támogatja az AMD K8-as processzorok HyperTransport interfészét A HyperTransport technológia egy ponttól pontig való kapcsolat két készülék között, és segítségével az integrált áramkörök közötti információcsere sebessége sokkal nagyobb, mint a jelenleg rendelkezésre álló...
  • Page 93 Bővítési lehetőségek Az alaplap a következő bővítési lehetőségekkel rendelkezik: • Három 32 bites PCI foglalat • Egy AGP foglalat • Két IDE csatlakozó, amely összesen négy IDE eszközt támogat • Egy hajlékonylemez meghajtó interfész • Két 7 tűs SATA csatlakozó Ez az alaplap a 133/100/66MB/s átviteli sebességű...
