ECS 756-A User Manual

ECS 756-A User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
iii

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 756-A and is the answer not in the manual?

Questions and answers

Related Manuals for ECS 756-A

Summary of Contents for ECS 756-A

  • Page 3 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0 Disclaimer The information in this document is subject to change without notice.

  • Page 4: Declaration Of Conformity

    Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations.

  • Page 5: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction....................1 Features.......................2 Motherboard Components...............4 Chapter 2 7 7 7 7 7 Installing the Motherboard Safety Precautions..................7 Choosing a Computer Case...............7 Installing the Motherboard in a Case............7...
  • Page 6 Security Settings................37 Chipset Settings................38 Power Settings................42 Exit Settings..................44 Chapter 4 45 45 45 45 Using the Motherboard Software About the Software CD-ROM..............45 Auto-installing under Windows 98/ME/2000/XP........45 Running Setup................46 Manual Installation..................48 Utility Software Reference...............48 49 49 49 49 Chapter 5 SIS965/SiS965L SATA RAID Setup Guide Introduction for SiS965/SiS965L SATA RAID Function.....49 Features......................49 Support Operating Systems..............49...

  • Page 7: Introducing The Motherboard

    Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the 756-A motherboard. This motherboard is a high performance, enhanced function motherboard that supports Socket 939 AMD Athlon 64/Athlon 64 FX CPUs for high-end business or personal desktop markets. The motherboard incorporates the SiS756 Northbridge (NB) and SiS965/SiS965L Southbridge (SB) chipsets.

  • Page 8: Features

    Feature Processor This motherboard uses a 939-pin socket that carries the following features: • Accommodates AMD Athlon 64/Athlon 64 FX processors • Supports up to 2000MT/s HyperTransport (HT) interface speeds HyperTransport Technology is a point-to-point link between two devices, it enables integrated circuits to exchange information at much higher speeds than currently avail- able interconnect technologies.
  • Page 9 Expansion Options The motherboard comes with the following expansion options: • One PCI Express x16 slot • Two PCI Express x1 slots • One AGP Express slot • Two 32-bit PCI slots • Two IDE headers which support four IDE devices •...

  • Page 10: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 11 Table of Motherboard Components LABEL COMPONENT 1 CPU Socket Socket 939 for AMD K8 processor 2 DIMM1~4 184-pin DDR SDRAM slots 3 IDE1 Primary IDE connector 4 IDE2 Secondary IDE connector 5 SATA1~SATA4 Serial ATA connectors 6 SYS_FAN System fan connector 7 CLR_CMOS Clear CMOS jumper 8 SPK1...
  • Page 12 Memo Introducing the Motherboard...

  • Page 13: Installing The Motherboard

    Make sure that your case supports all the features required. Secondly, 756-A supports one or two floppy diskette drives and four enhanced IDE drives. Make sure that your case has sufficient power and space for all drives that you intend to install.

  • Page 14: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 15: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Description Setting (default) Type CLR_CMOS 3-pin CLEAR CMOS 1-2: NORMAL 2-3: Clearing Before clearing CLR_CMOS CMOS, make sure to turn the system off.

  • Page 16: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin con- necting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPU_FAN. Connect the case cooling fan connector to SYS_FAN. Connect the power cooling fan connector to PWR_FAN.
  • Page 17 CPU_FAN/SYS_FAN/PWR_FAN: FAN Power Connectors Function Signal Name System Ground Power +12V +12V Sensor Sense SPK1: Internal speaker Signal Name Ground Signal ATX_POWER1: ATX 24-pin Power Connector Signal Name Signal Name +3.3V +3.3V +3.3V -12V Ground Ground PS_ON Ground Ground Ground Ground Ground PWRGD...

  • Page 18: Front Panel Header

    Front Panel Header The front panel header (PANEL1) provides a standard set of switch and LED headers commonly found on ATX or Micro ATX cases. Refer to the table below for information: Pin Signal Name Function Pin Signal Name Function HD_LED_P Hard disk LED+ FP PWR/SLP...

  • Page 19: Installing Hardware

    Installing Hardware Installing the Processor Caution: When installing a CPU heatsink and cooling fan make sure that you DO NOT scratch the motherboard or any of the surface-mount resistors with the clip of the cooling fan. If the clip of the cooling fan scrapes across the motherboard, you may cause serious damage to the motherboard or its components.

  • Page 20: Installing Memory Modules

    CPU Installation Procedure The following illustration shows CPU installation components. Install your CPU. Pull up the lever away from the socket and lift up to 90-degree angle. Locate the CPU cut edge (the corner with the pin hold noticeably missing). Align and insert the CPU correctly.

  • Page 21: Installation Procedure

    Installation Procedure Refer to the following to install the memory modules. This motherboard supports unbuffered DDR SDRAM only. Push the latches on each side of the DIMM slot down. Align the memory module with the slot. The DIMM slots are keyed with notches and the DIMMs are keyed with cutouts so that they can only be installed correctly.
  • Page 22 Table A: Unbuffered DIMM Support for 939-pin Maximum Chip Selects Data DRAM Speed MEMCS_1L_L* MEMCS_1H_L* MEMCS_2L_L* MEMCS_2H_L* DDR400 DDR400 Single rank DDR400 DDR400 Double rank DDR400 DDR400 Single rank DDR400 DDR400 Double rank DDR333 DDR400 Single rank Single rank bits DDR200 DDR400 Single rank Double rank...

  • Page 23: Installing A Hard Disk Drive/Cd-Rom/Sata Hard Drive

    Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Devices Your motherboard has a primary and secondary IDE channel interface (IDE1 and IDE2). An IDE ribbon cable supporting two IDE devices is bundled with the motherboard.
  • Page 24 About SATA Connectors Your motherboard features four SATA connectors supporting a total of four drives. SATA refers to Serial ATA (Advanced Technology Attachment) is the standard interface for the IDE hard drives which are currently used in most PCs. These connectors are well designed and will only fit in one orientation.

  • Page 25: Installing A Floppy Diskette Drive

    Installing a Floppy Diskette Drive The motherboard has a floppy diskette drive (FDD) interface and ships with a diskette drive ribbon cable that supports one or two floppy diskette drives. You can install a 5.25-inch drive and a 3.5-inch drive with various capacities. The floppy diskette drive cable has one type of connector for a 5.25-inch drive and another type of connector for a 3.5-inch drive.
  • Page 26 AGP graphics cards that have been tested by out company. See the “Supported AGP 8x/4x VGA Cards List” or visit our website at “http:// www.ecs.com.tw” for the updated supported list. PCIE x16 Slot The PCI Express x16 slot is used to install an external PCI Express graphics card that is fully compliant to the PCI Express Base Specifica- tion revision 1.0a.
  • Page 27 ATI Radeon 9700pro 128MB DDR For the latest updates of the supported AGP VGA cards list, please visit Leadtek WinFast A250 LE TD GF4 ECS ELITEGROUP website for details. Ti4200 64MB DDR SDRAM ECS ELITEGROUP website: http://www.ecs.com.tw GeForce FX5200 64M DDR...

  • Page 28: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: SPDIF-O1: SPDIF out header This is an optional header that provides an S/PDIF (Sony/Philips Digital Interface) output to digital multimedia device through optical fiber or coaxial connector. Signal Name Function SPDIF digital output...
  • Page 29 SATA1~SATA4: Serial ATA connectors These connectors are use to support the new Serial ATA devices for the highest date transfer rates (150 MB/s), simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface. But maintains register compatibility and software compatibility with Parallel ATA.

  • Page 30: Connecting I/O Devices

    IR1: Infrared port The motherboard supports an Infrared (IR1) data port. Infrared ports allow the wireless exchange of information between your computer and similarly equipped devices such as printers, laptops, Personal Digital Assistants (PDAs), and other computers. Function Signal Name Signal Name Function Not assigned...

  • Page 31: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest American Megatrends BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configura- tion status and provides you with options to set system parameters.

  • Page 32: Updating The Bios

    BIOS Navigation Keys The BIOS navigation keys are listed below: FUNCTION FUNCTION Select Screen Select Item Enter Go to Sub Screen Change Option/Field PGDN Next Page PGUP Previous Page HOME Go to Top of Screen Go to Bottom of Screen F2/F3 Change Colors Discard Changes...

  • Page 33: Using Bios

    Using BIOS When you start the Setup Utility, the main menu appears. The main menu of the Setup Utility displays a list of the options that are available. A highlight indicates which option is currently selected. Use the cursor arrow keys to move the highlight to other options. When an option is highlighted, execute the option by pressing <Enter>.

  • Page 34: Advanced Settings

    Advanced Settings This option displays basic information about your system. BIOS SETUP UTILITY Boot Main Advanced PCIPnP Security Chipset Power Exit Advanced Settings Options for CPU Warning: Setting wrong values in below sections may cause system to malfunction CPU Configuration IDE Configuration Floppy Configuration SuperIO Configuration...
  • Page 35 IDE Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Advanced IDE Configuration DISABLED: disables the inte- grated IDE Controller. OnBoard PCI IDE Controller [Both] PRIMARY: enables only the OnBoard PCI IDE Mode [Legacy Mode] Primary IDE Controller SECONDARY: enables only...
  • Page 36 Type (Auto) This item enables users to select the type of device connected to the system. LBA/Large Mode (Auto) LBA (Logical Block Addressing) is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137GB. The default setting is Auto. Block (Multi-Sector Transfer) (Auto) Enable this item to enhance hard disk performance by reading or writing more data during each transfer.
  • Page 37 Super IO Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Advanced Configure ITE8705 Super IO Chipset Allows BIOS to Enable or Dis- able Floppy Controller OnBoard Floppy Controller [Enabled] Serial Port1 Address [3F8/IRQ4] Serial Port2 Address [2F8/IRQ3]...
  • Page 38 Hardware Health Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Advanced Hardware Health Function Enables Hardware Health Monitoring Device. H/W Health Configuration [Enabled] Hardware Health Event Monitoring System Temperature : 34°C/93°F CPU Temperature : 49°C/120°F CPU_Fan Speed...
  • Page 39 ACPI Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Advanced ACPI Settings General ACPI Configuration settings General ACPI Configuration ← → Select Screen ↑↓ Select Item + − Change Field Tab Select Field General Help F10 Save and Exit...
  • Page 40 AMD Cool ‘N Quiet Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Advanced AMD Cool “N Quiet Configuration Enabled/Disabled Cool N’Quiet Cool N’Quiet [Enabled] ← → Select Screen ↑↓ Select Item + −...

  • Page 41: Pcipnp Settings

    PCIPnP Settings This option displays basic information about your system. BIOS SETUP UTILITY Boot Main Advanced PCIPnP Security Chipset Exit Power Advanced PCI/PnP Settings Clear NVRAM during System Boot Warning: Setting wrong values in below sections may cause system to malfunction Clear NVRAM [No] Plug &...

  • Page 42: Boot Settings

    Reserved Memory Size (Disabled) This item shows the size of memory block to reserve for legacy ISA devices. Boot Settings This option displays basic information about your system. BIOS SETUP UTILITY Main Advanced PCIPnP Boot Security Chipset Exit Power Boot Settings Configuration Configure Settings during Sys- tem Boot Boot Settings Configuration...

  • Page 43: Security Settings

    Boot Device Priority (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Boot Boot Device Priority Specifies the boot sequence from the available devices. 1st Boot Device [1st FLOPPY DRIVE] A device enclosed in parenthe- sis has been disabled in the corresponding type menu.

  • Page 44: Chipset Settings

    Change Supervisor Password/Change User Password (Press Enter) You can select this option and press <Enter> to access the sub menu. You can use the sub menu to change the supervisor password. Boot Sector Virus Protection (Disabled) If set to Disabled, when anything attempts to access the boot sector or hard disk partition table, there will be no warning message to appear.
  • Page 45 NorthBridge Chipset Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Chipset NorthBridge Chipset Configuration Memory Configuration Memory CLK :200 MHz CAS Latency (Tcl) : 3.0 RAS/CAS Delay (Trcd) : 3 CLK Min Active RAS (Tras) : 8 CLK ←...
  • Page 46 South Bridge SiS965/SiS965L Chipset Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Chipset Options Disabled Enabled OnBoard AC97 Audio DEVICE [Enabled] Onboard Lan: [Enabled] Onboard LAN BOOT ROM: [Disabled] OnBoard AC97 Modem DEVICE [Auto] ←...
  • Page 47 HyperTransport Configuration (Press Enter) Scroll to this item and press <Enter> to view the following screen: BIOS SETUP UTILITY Chipset HyperTransport Configuration Options 8 BIT HT Width [Auto] 16 BIT HT Speed [1000 MHz] Auto ← → Select Screen ↑↓ Select Item + −...

  • Page 48: Power Settings

    Spread Spectrum Control (PLL1/2 Spread Enab) If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic Interference) generated by the system, and it can control PLL1 and PLL2 individually. Select Synchronous PCI Freq (PCI Sync freq) This item allows you to adjust PCI Clock. ZCLK PLL CTRL (PLL2) This item allows users to choose Z clock.
  • Page 49 Resume On PME# (Disabled) The system can be turned off with a software command. If you enable this item, the system can automatically resume if there is an incoming call on the PCI Modem or PCI LAN card. You must use an ATX power supply in order to use this feature. Use this item to do wake-up action if inserting the PCI card.

  • Page 50: Exit Settings

    Exit Settings This option displays basic information about your system. BIOS SETUP UTILITY Exit Power Main Advanced PCIPnP Boot Security Chipset Exit Options Exit system setup after saving the changes Save Changes and Exit Discard Changes and Exit F10 key can be used for Discard Changes thisoperation Load Optimal Defaults...

  • Page 51: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software CD-ROM The support software CD-ROM that is included in the motherboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your motherboard version.

  • Page 52: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support Before installing the software from Windows Explorer, look for a file named README.TXT, INSTALL.TXT or something similar.
  • Page 53 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 54: Manual Installation

    Manual Installation Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your motherboard. Look for the chipset and motherboard model; then browse to the directory and path to begin installing the drivers.

  • Page 55: Sis965/Sis965L Sata Raid Setup Guide

    Chapter 5 SiS965/SiS965L SATA RAID Setup Guide Introduction for SiS965/SiS965L SATA RAID Function The SiS965 S-ATA Host controller supports up to four serial ATA on four independent ports, but the SiS965L S-ATA controller only supports two SATA ports of up to two Serial ATA drives.

  • Page 56: Installing Software Drivers

    RAID 0+1: Also known as “Stripe-Mirror”. At least four hard drives are re- quired. RAID 0+1 is a combination of RAID 0 and RAID 1. Data is striped into two drives then mirrored. It provides high performance and high data protec- tion.

  • Page 57: Bios Utility Operation

    Confirming Windows 98/Me Driver Installation From Windows 98/Me, open the Control Panel from “My Computer” followed by the System icon. Choose the “Device Manager” tab. Click the “+” in front of “IDE ATA/ATAPI Controllers” hardware type. The driver “SiS965 IDE/Raid Controller” should appear. BIOS Utility Operation BIOS Utility supports windows 2000/XP/98/Me.
  • Page 58 Create RAID • SIS965 controller support RAID 0, RAID 1, RAID 0+1 and JBOD. • SIS965L controller support RAID 0, RAID 1 and JBOD. • The selection of RAID 0+1 will appear when 4 single HDD existing Creating a RAID 0 (Stripe) Array for Performance •...
  • Page 59 Use < > < > to select disk, and press <Enter> to select disk, <Q> to exit. ↑ ↓ When you press <Enter> on the disk you wanted, the RAID Type will be changed from Single to RAID 0. An the disk you select first will be the SOURCE disk.
  • Page 60 Press <Q> again to exit this BIOS utility and the red message frame will show. Press <Y> and <Enter> to save changes. Once the array has been created, you will need to FDISK and format the array as if it were a new single hard drive. Creating a RAID 1 (Mirror) Array •...
  • Page 61 Use < > < > to select disk, and press <Enter> to select disk, <Q> to exit. ↑ ↓ When you press <Enter> on the disk you wanted, the RAID Type will be changed from Single to RAID 1. The same as RAID 0, the disk you select first will be the SOURCE disk.
  • Page 62 Press <Q> again to exit this BIOS utility and the red message frame will show as the same as the creation of the RAID 0 array. Press <Y> and <Enter> to save changes. Once the array has been created, you will need to FDISK and format the array as if it were a new single hard drive.
  • Page 63 Once the array has been created, you will need to FDUSK and FORMAT the array as if it were a new single hard drive. Creating a JBOD Array • SiS965 enables users to create a JBOD array with 2, 3, or 4 drives. •...
  • Page 64 Press <Q> again to exit this BIOS utility and the red message frame will show as the same age as the creation of the RAID 0 array. Press <Y> and <Enter> to save changes. Once the array has been created, you will need to FDISK and format the array as if it were a new single hard drive.
