Left view

1 2
# Icon Item
1 Kensington lock slot
2 DC-in jack
3 External display (VGA)
port
4 Ethernet (RJ-45) port
5 USB 2.0 port
3 4
Description
Connects to a Kensington-compatible
computer security lock.
Note: Wrap the computer security lock
cable around an immovable object such as
a table or handle of a locked drawer. Insert
the lock into the notch and turn the key to
secure the lock. Some keyless models are
also available.
Connects to an AC adapter.
Connects to a display device (e.g., external
monitor, LCD projector).
Connects to an Ethernet 10/100/1000-
based network.
Connects to USB 2.0 devices (e.g., USB
mouse, USB camera).
