Sharp R-350B Service Manual page 11

PROCEDURE
LETTER
Initial temperature ............................................................................................. T1 = 11 C
Temperature after (42 + 2) = 44 sec. ................................................................ T2 = 21 C
Temperature difference Cold-Warm ..............................................................
Measured output power
The equation is "P = 100 x T" ........................................... P = 100 x 10 C = 1000 Watts
JUDGMENT: The measured output power should be at least
CAUTION: 1 C CORRESPONDS TO 100 WATTS REPEAT MEASUREMENT IF THE POWER IS
B POWER TRANSFORMER TEST
WARNING: High voltages and large currents are present at the secondary winding and filament
CARRY OUT 3D CHECKS.
Disconnect the leads to the primary winding of the power transformer. Disconnect the filament and
secondary winding connections from the rest of the HV circuitry. Using an ohmmeter, set on a low
range, it is possible to check the continuity of all three windings. The following readings should be
obtained:
If the reading obtained are not stated as above, then the power transformer is probably faulty and
should be replaced.
CARRY OUT 4R CHECKS.
C HIGH VOLTAGE RECTIFIER ASSEMBLY TEST
HIGH VOLTAGE RECTIFIER TEST
CARRY OUT 3D CHECKS.
Isolate the high voltage rectifier assembly from the HV circuit. The high voltage rectifier can be tested
using an ohmmeter set to its highest range. Connect the ohmmeter across the terminal B+C of the
high voltage rectifier and note the reading obtained. Reverse the meter leads and note this second
reading. The normal resistance is infinite in one direction and more than 100 k in the other direction.
CARRY OUT 4R CHECKS.
ASYMMETRIC RECTIFIER TEST
CARRY OUT 3D CHECKS.
Isolate the high voltage rectifier assembly from the HV circuit. The asymmetric can be tested using
an ohmmeter set to its highest range across the terminals A+B of the asymmetric rectifier and note
TEST PROCEDURES
INSUFFICIENT.
1000g
1000g
T1˚C
winding of the power transformer. It is very dangerous to work near this part when
the oven is on. NEVER make any voltage measurements of the high-voltage
circuits, including the magnetron filament.
a. Primary winding ....................approx. 1.3
b. Secondary winding ............... approx. 96
c. Filament winding ................... less than 1
COMPONENT TEST
Heat up for 44 sec.
A B
D2 D1
ASYMMETRIC
RECTIFIER
HIGH VOLTAGE RECTIFIER
C
9
T1 = 10 C
15 % of the rated output power.
1000g
T2˚C
