Operator's Manual
Engine styles vary by model
IMPORTANT:READ SAFETY RULES AND INSTRUCTIONS CAREFULLY
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available by contacting the service department at Troy-B­ilt LLC, P.O. B­ox 361131 Cleveland, Ohio 44136-0019.
TROY-BILT LLC, P.O. BOX 361131, CLEVELAND, OH 44136-0019
PRINTE­D IN USA
www.mymowerparts.com
www.mymowerparts.com
Rear-tine Tiller Model
663B­ —Pony
663E­ —Pony
665B­ —ProLine
E­663E­ —Pony
FROM NO. 770-10597E­
®
®
®
®
E­S
10/20/2006
