- Page 1 SUB-TS7 (HKTS 7 SUBWOOFER) SUB-TS8 (HKTS 8 SUBWOOFER) SERVICE MANUAL harman/kardon, Inc. 250 Crossways Park Dr. Woodbury, New York 11797 Rev1 10/2006...
-
Page 2: Specifications
SUB-TS7/TS8 harman/kardon CONTENTS BASIC SPECIFICATIONS ... . ……………………………………..1 DETAILED SPECIFICATIONS ... . . …..………………….. 2 CONTROLS &... - Page 3 SUB-TS7/TS8 harman/kardon SUB-TS7 100W Powered Sub/ Plate Amp SUB-TS8 100W Powered Sub/ Plate Amp LINE VOLTAGE Yes/No Hi/Lo Line Nom. Unit Notes US 120vac/60Hz 108-132 Vrms Normal Operation Nonimal QA Test Parameter Unit Conditions Notes Specification Limits Amp Section Type (Class AB, D, other)
- Page 4 SUB-TS7/TS8 harman/kardon Nonimal QA Test Parameter Unit Conditions Notes Specification Limits Turn-off Transient mV-peak @ Speaker Outputs AC Line cycled from ON to OFF Efficiency Maximum allowable input power under nominal input voltage and frequency, in stand-by mode (HOT Stand-by Input Power Watts @ nom.
-
Page 5: Controls And Connections
SUB-TS7/TS8 harman/kardon SUBWOOFER AMPLIFIER PANEL CONTROLS AND CONNECTIONS SUBWOOFER LEVEL ¡ FILTER ™ C A U TIO N C A U TIO N £ R ISK OF ELEC TR IC SH O C K R ISK OF ELEC TR IC SH O C K... - Page 6 SUB-TS7/TS8 harman/kardon SUBWOOFER AMPLIFIER PANEL CONTROLS AND CONNECTIONS and is turned on, and the LED is lit amber to § Line-Level Full-Range Inputs: Connect ª Master Power Switch: Place this indicate that no signal is being received and the line-level subwoofer output or preamp out- switch in the “•”...
-
Page 7: Speaker Connections
SUB-TS7/TS8 harman/kardon SPEAKER CONNECTIONS Dolby* Digital or DTS ® (or Other Center Front Front Digital Surround Mode) Connection Left Right USE THIS INSTALLATION METHOD FOR DOLBY DIGITAL, DTS OR OTHER DIGITAL SURROUND PROCESSORS: Subwoofer Use the line-level input jack marked SUB LINE LEVEL IN ∞... - Page 8 SUB-TS7/TS8 harman/kardon SPEAKER CONNECTIONS Dolby Pro Logic* Center (Non-Digital) – Line Level Front Front USE THIS INSTALLATION METHOD FOR Left Right DOLBY PRO LOGIC APPLICATIONS (NOT DOLBY DIGITAL, DTS OR OTHER DIGITAL PROCESSING), WHERE THE RECEIVER/ Subwoofer PROCESSOR IS EQUIPPED WITH A SUB-...
- Page 9 SUB-TS7/TS8 harman/kardon SPEAKER CONNECTIONS Dolby Pro Logic Center Front Front (Non-Digital) – Speaker Level Left Right USE THIS INSTALLATION METHOD FOR DOLBY PRO LOGIC APPLICATIONS (NOT DOLBY DIGITAL, DTS OR OTHER DIGITAL PROCESSING), WHERE THE RECEIVER/ PROCESSOR DOES NOT HAVE A SUB-...
- Page 10 SUB-TS7/TS8 harman/kardon OPERATION Volume Additional Bass Adjustments Move the Master Power Switch ª (marked Power) to the “ • ” (On) position. Volume can be adjusted using the In addition to the volume adjustments The Subwfr subwoofer will automatically described above, the Subwfr subwoofer Subwoofer-Level Control ¡, as...
-
Page 11: Troubleshooting
SUB-TS7/TS8 harman/kardon TROUBLESHOOTING SYMPTOM SOLUTION If there is no sound from • Check that receiver/amplifier is on and a source is playing. • Check that the powered subwoofer is plugged in and its Master Power Switch ª is switched on to the “ • ” position. -
Page 12: Parts List & View
SUB-TS7/TS8 harman/kardon Ref# Description Part Number Amplifier screw 352-AM04020D210 SUB-TS7/TS8 Amplifier Not for Sale Port Tube Not for Sale Not for Sale SUB-TS7/TS8 Cabinet Logo 316-AG-00557 Not for Sale Grille Not for Sale Logo 316-AL-00553 10" woofer 25PF12DZB-DW01 Woofer screw... - Page 13 SUB-TS7/TS8 harman/kardon (See Mechanical Parts List on Pages 21-22)
- Page 14 SUB-TS7/TS8 harman/kardon Test Set Up and Procedure Equipment needed: Function/signal generator/sweep generator • Integrated Amplifier • Multimeter • Speaker cables • Initial Control Settings: Power Switch OFF; Filter OFF • Level MIN (Full CCW) • Phase, Auto/On switches do not matter •...
-
Page 15: Tech Tips
SUB-TS7/TS8 harman/kardon TECH TIPS harman/kardon Troubleshooting tips and solutions to common service problems For models: HKTS7 SUB (SUB-TS7) TIP# HKTT2004-04 Subject: Improved filter performance Instructions: Change four 1/6W ±5% CF Resistors in the PREAMP PCB of the HKTS 7 subwoofer amplifier. It is recommended this procedure be followed for every unit that has to be serviced, for any reason. - Page 16 SUB-TS7/TS8 harman/kardon...
- Page 17 SUB-TS7/TS8 harman/kardon...
- Page 18 SUB-TS7/TS8 harman/kardon...
- Page 19 SUB-TS7/TS8 harman/kardon...
- Page 20 SUB-TS7/TS8 harman/kardon...
- Page 21 SUB-TS7/TS8 harman/kardon SUB-TS7/TS8 120V Electrical parts list Part number Description Reference Designator LIMITER PCB Resistors 110-16103j26 Resistor 10K 1/6W ±5% CF 26mm R301,R303,R304,R308,R309,R314, 110-16153j26 Resistor 15K 1/6W ±5% CF 26mm R302, 110-16223j26 Resistor 22K 1/6W ±5% CF 26mm R310,R312, 110-16333j26 Resistor 33K 1/6W ±5% CF 26mm...
- Page 22 SUB-TS7/TS8 harman/kardon Part number Description Reference Designator PREAMP PCB 132-183j503 Mylar capacitor 0.018uF 50V ±5% C223, 132-223ja03 Mylar capacitor 0.022uF 100V ±5% C215, 132-473j503 Mylar capacitor 0.047U 50V ±5% C224, 132-563j503 Mylar capacitor 0.056U 50V ±5% C216, 132-823j503 Mylar capacitor 0.082U 50V ±5%...
- Page 23 SUB-TS7/TS8 harman/kardon Part number Description Reference Designator MAIN PCB Semiconductors 192-027c1815gr Transistor 2SC1815GR NPN Q102,Q111,Q112,Q113,Q118 192-028a1015gr Transistor 2SA1015GR PNP Q114,Q116, 192-1672n5551 Transistor 2N5551 NPN Q103,Q109, 192-1682n5401 Transistor 2N5401 AI-PNP 350V Q104,Q110, 197-131n4148 Diode 1N4148 26mm D101,D103,D105,D108, 199-15000335 ZENER diode 3.3V 1/2W 52mm...
- Page 24 SUB-TS7/TS8 harman/kardon Part number Description Reference Designator MISCELLANEOUS/MECHANICAL 306-ABS-00004 REAR CABINET 268*213*102 A.B.S UL 311-ABS-00028 knob 46077-W P.V.C. 320-RUB-00033 Rubber pad 25*21*4t 323-AL-00019 HEAT SINK 117.5*60*25 333-EVA-00096 EVA (Gasket) 213*15*2.0mm 333-EVA-00097 EVA (Gasket) 213*15*1.0t 333-EVA-00132 EVA (Gasket) 238*15*2.0mm 333-EVA-00133 EVA (Gasket) 238*15*1.0t...
-
Page 25: Integrated Circuit Diagrams
SUB-TS7/TS8 harman/kardon... - Page 26 SUB-TS7/TS8 harman/kardon...
- Page 27 SUB-TS7/TS8 harman/kardon HKTS7...
- Page 28 SUB-TS7/TS8 harman/kardon HKTS7...
- Page 29 SUB-TS7/TS8 harman/kardon HKTS8...
- Page 30 SUB-TS7/TS8 harman/kardon HKTS8...
- Page 31 SUB-TS7/TS8 harman/kardon HKTS8...
- Page 32 SUB-TS7/TS8 harman/kardon HKTS7...
- Page 33 SUB-TS7/TS8 harman/kardon HKTS 8 ® Packaging OWNER’S MANUAL 406-000-05108 SATELLITES (5) WARRANTY CARD HKTS 8 SAT-1 405-000-00333 COLOR CODE FOAM PACKING 413-000-05097 431-00005153 FOAM PACKING 431-00005154 CENTER CHANNEL WIRES: HKTS 8 CEN-1 GREEN 20FT CENTER 370-000-05002 MOUNTING BRACKETS (5) 326-ABS-00108...
