Optional
2x1 Digital Audio Switcher
Accessories
Switch Between Two Digital Audio Sources and One Digital Audio
Receiver or Amplifier
This simple to use Digital Audio Switcher allows you to connect two digital audio sources to a digital
audio receiver or amplifier with one input, making it a worthy addition to home theater, hi-fi system
with multiple audio sources.
Both digital audio sources remain live all the time and you can switch between the two at will.
RMT IR Extender
Access is controlled with the unit's IR remote control or the manual selection button on the front
panel. Downtime is nonexistent--the switch occurs instantaneously.
How It Works
Simply connect both sources to the Digital Audio Switcher's inputs, then connect the Digital Audio
Switcher output to the receiver's output. Apply power by connecting the power supply and you're
ready to switch.
RMT-2
Features:
Connects two digital audio sources to a receiver using one input
Supports two formats: S/PDIF and optical
Eliminates the need to unplug and replug devices
Front panel switching
Discrete IR remote (included)
Parallel remote port (RMT-2 not included)
Easy to operate: sources are selected remotely or manually
Specifications:
Input/Output: S/PDIF (Digital Coax), Optical TOSlink
S/PDIF (Digital Coax): 96 kHz Performance
Power Supply 5V DC
Power Consumption: 5 watts (max)
Dimensions: 4" W x 1.25" H x 3.25" D
Shipping Weight: 2 lbs.
Package Includes:
Digital Audio Extender
RMT-2IR Remote Control
5VDC Power Supply
Two TOSLINK fiber optic cables
User Manual
Dystrybucja i sprzedaż: Meditronik Sp. z o.o.
02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46
http://www.meditronik.com.pl
e-mail: office@meditronik.com.pl
EXT-DIGAUD-241
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Gefen EXT-DIGAUD-241
Summary of Contents for Gefen EXT-DIGAUD-241
-
Page 1: Specifications
Digital Audio Extender RMT-2IR Remote Control 5VDC Power Supply Two TOSLINK fiber optic cables User Manual EXT-DIGAUD-241 Dystrybucja i sprzedaż: Meditronik Sp. z o.o. 02-952 Warszawa, ul. Wiertnicza 129, tel. (+48 22) 651-72-42, fax (+48 22) 651-72-46 http://www.meditronik.com.pl e-mail: office@meditronik.com.pl... - Page 2 2x1 Digital Audio Switcher U S E R M A N U A L www.gefen.com...
- Page 3 Notice Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. 2x1 Digital Audio Switcher is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Introduction Features Panel Descriptions Connecting and Operating the 2x1 Digital Audio Switcher RMT2-IR Installation IR Extender Installation Specifi cations Warranty... -
Page 5: Introduction
Our Commitment Gefen will always offer the fi nest quality product at the best possible price. Included in that price is a lifetime of support from a team of outstanding engineers. The ex•tend•it 2x1 Digital Audio Switcher allows two SPDIF or OPTICAL devices to be switched easily in to one Digital Audio reciever. -
Page 6: Features
FEATURES Features • Switches easily between any two Digital Audio sources • Optional RMT-2 remote control • TOSLINK cables are used to connect the TOSLINK inputs and 2x1 TOSLINK Digital Audio Switcher output • SPDIF cables are used to connect the SPDIF inputs and 2x1 SPDIF Digital Audio Switcher output •... -
Page 7: Panel Descriptions
PANEL DESCRIPTIONS PANEL DESCRIPTIONS Connects to IR Indicates if port 1 or Selects port 1 extender port 2 is selected or port 2 IR eye SPDIF 1 SPDIF 2 OPT 1 OPT 2 Connects to SPDIF Out Optical Out 5VDC power supply... -
Page 8: Connecting And Operating The 2X1 Digital Audio Switcher
Connecting and Operating the 2x1 Digital Audio Switcher How to Connect the 2x1 Digital Audio Switcher to your devices 1 Connect the digital audio cables from your devices into the 2x1 Digital Audio Switcher inputs. 2 Connect your digital audio receiver to the 2x1 Digital Audio Switcher output. 3 Input 1 and 2 can either be S/PDIF or TOSlink, not both. -
Page 9: Rmt2-Ir Installation
RMT2-IR Installation 1. Remove battery cover from the back of the RMT2-IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. - Page 10 IR Extender Instructions How to Connect the IR Extender to the 2x1 Digital Audio Switcher 1 Open the unit so the circuit board below is accessible. 2 Add a jumper to close the contact between the pins in the white circle 3 Move the jumper in the black circle from the local to the remote pins 4 Plug the IR Extender into the remote jack on the front of the unit...
-
Page 11: Specifi Cations
SPECIFICATIONS Input/Output Connector Type .............S/PDIF and TOSlink S/PDIF (Digital coax) performance .................96 kHz Power Consumption ................15 Watts (max.) Power Supply ......................5VDC Dimensions ................... 4”D x 3.25”W x 1.25”H Shipping Weight ....................... 2 Lbs... -
Page 12: Warranty
If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
