Model No. WCTL25320
Serial No.
Write the serial number in the
space above for future reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 18h30 EST
(excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
Advertisement
Table of Contents
Related Manuals for Weslo WCTL25320
Summary of Contents for Weslo WCTL25320
- Page 1 Model No. WCTL25320 USER'S MANUAL Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are...
-
Page 2: Table Of Contents
4. Keep the treadmill indoors, away from mois- page 8. To purchase a surge suppressor, see ture and dust. Do not put the treadmill in a your local WESLO dealer or call 1-800-806- garage or covered patio, or near water. 3651 and order part number 146148. - Page 3 16. The treadmill is capable of high speeds. 21. Inspect and properly tighten all parts of the Adjust the speed in small increments to treadmill regularly. avoid sudden jumps in speed. 22. Never drop or insert any object into any 17.
-
Page 4: Before You Begin
The model number of the tread- you’re not exercising, the unique CADENCE C32 can mill is WCTL25320. The serial number can be found be folded up, requiring less than half the floor space of on a decal attached to the treadmill (see the front other treadmills. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. -
Page 6: Connectors
3. With the help of a second person, lift the Frame (79) and attach the Base (46) to the Right Upright (62) with two Upright Bolts (65), two 3/8” Washers (66), and two 3/8” Nuts (61) as shown. Attach the Base (46) to the Left Upright (not shown) in the same way. -
Page 7: Connectors
7. Hold the Console (57) near the Console Base (52). Touch the Right Handrail (59) to discharge any static. Insert the Wire Harness (60) through the hole in the bot- tom of the Console Base (52). Locate the two wires in the Wire Harness (60) that have L-shaped connectors on the ends. -
Page 8: Operation And Adjustment
Adapter drawing 1 at the right). To purchase a surge sup- Surge Suppressor pressor, see your local WESLO dealer or call 1-800-806-3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). - Page 9 DIAGRAM OF THE CONSOLE Speed Control Note: If there is a thin sheet of clear plastic on the face of the console, remove it before operating the console. BATTERY INSTALLATION of your clothes. Next, insert the key fully into the con- sole.
- Page 10 To stop the walking belt, step onto the foot rails To change the incline, first remove the incline pin from and slide the speed control to the RESET position. one of the incline legs as shown below. Adjust the incline leg to the desired height and fully reinsert the Note: During the first few minutes that the treadmill incline pin.
-
Page 11: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) in order to raise, lower or move the treadmill. 1. -
Page 12: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-888-936-4266, Monday through Friday 8h00 until 18h30 Eastern Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 8. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may 7-10 cm become damaged.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES is activity that requires large amounts of oxygen for prolonged periods of time. This increases the demand WARNING: Before beginning on the heart to pump blood to the muscles, and on the this or any exercise program, consult your lungs to oxygenate the blood. -
Page 15: Ordering Replacement Parts
To order replacement parts, call toll-free 1-888-936-4266, Monday through Friday 8h00 until 18h30 Eastern Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCt (WCTL25320) • The NAME OF THE PRODUCT (WESLO ®... -
Page 16: Limited Warranty
Product Design Product Innovation Other Features © 2004 ICON IP, Inc. 8) Did you consider purchasing fitness equipment from another WESLO is a registered trademark of ICON IP, Inc. Part No. 211317 R0804A Printed in Canada © 2004 ICON IP, Inc. -
Page 17: Wheel Bolts
PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Spacer Screw 3/4” Screw (2)–12 3/4” Tek Screw (89)–2 (3)–4 Star Washer (29)–2 Handrail Bolt (42)–4 1/4”... - Page 18 PART LIST—Model No. WCTL25320 R0804A Key No. Qty. Description Key No. Qty. Description Motor Hood Left Endcap 3/4” Screw Ground Wire 3/4” Tek Screw Key/Clip 8” Cable Tie Console Base Cable Tie Left Upright Clamp Screw Battery Cover Cable Tie Clamp...
