POPCORN HOUR C-200 User Manual page 17

7
Ethernet (RJ-45) Port
Connect an Ethernet cable (RJ-45) to the
Ethernet port and attach the other end to
a router or hub on your LAN.
(Local Area Network)
8
S-Video Connector
Use this to connect your NMT to your TV
using the S-Video connector. (Video only)
9
CVBS (Composite Video) Connector
Use this connector to connect your NMT to
your TV using the yellow Composite Video
connector. The Composite Video cable usually
comes attached to Composite Audio connectors
(red and white connectors). (Video only)
17
10
Composite Audio Connectors
Use these connectors to connect your
NMT to your TV using the red and white
Composite Audio connectors. These
connectors usually come attached with
the Composite Video connector
(yellow connector). (Audio only)
11
Component Video Connectors
Use these connectors to connect your
NMT to your TV set using component
video connectors. The connectors are
usually green, blue, and red in color.
(Video only)
12
Power Supply Port
Connect the supplied power cord here in
order to power your NMT.
// Popcorn Hour C-200
13
Power ON/OFF Switch
Use this switch to switch your NMT
on or off.
