2.5 Hardware Overview

2.5.1 Front Panel

1
2
1
Power Button
Use this button to Standby, Reset or Power
Down your NMT.
Ring light color
White
Amber
Red
OFF (no light)
14
3
2
USB Ports
Connect a USB storage device to this
port to access its media content.
Status
Active
3
Front Panel LCD display
Video OFF
Standby
LCD display with adjustable backlight.
Power OFF
5
ENTER
TV MODE DIM TV MODE DIM
4
4
6
DIM (Front Panel LCD) and TV MODE button
Press DIM to adjust the backlight of the Front Panel LCD
display.
Press TV MODE to switch between preset TV display modes.
