Page 7: Table Of Contents
Seagate Technology support services ........ - Page 8 ST1 Series Product Manual, Rev. A...
-
Page 9: List Of Figures
List of Figures Figure 1. ST1 Series CompactFlash+ disc drive ......... . . 1 Figure 2. - Page 10 viii ST1 Series Product Manual, Rev. A...
-
Page 11: Introduction
Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate ® ® Series drives: • ST650211CF and ST625211CF CompactFlash+ Type II disc drives. • ST650211FX and ST625211FX Flex (IDE interface) disc drives. These drives provide the following key features: •... -
Page 12: Disclaimer
Seagate may not be held liable for any direct, indirect, incidental, special, exemplary, or con- sequential damages (including, but not limited to, loss of use, data, or profits; procurement of substitute goods or services;... -
Page 13: Drive Specifications
Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate ST650211CF, ST650211FX, ST625211FX, and ST625211CF model drives. Power, access times and acoustics The specifications listed in this table are for quick reference. - Page 14 Table 1: Specifications ST650211CF ST625211CF Drive specification ST650211FX ST625211FX Average seek, read (msec typical/max) 16.0/17.0 Full-stroke seek (msec typical/max) 26.0/27.0 Seek power (typical 3.3V) 226 mA Read/write power (typical 3.3V) 300/310 mA Performance idle mode (typical 3.3V) 200 mA Low power idle mode (typical 3.3V)
-
Page 15: Formatted Capacity
Formatted capacity Model Formatted capacity Guaranteed sectors Bytes per sector ST650211CF 5 Gbytes 9,767,520 ST650211FX ST625211CF 2.5 Gbytes 4,883,760 ST625211FX Default logical geometry Model Cylinders Read/write heads Sectors per track ST650211CF 9690 ST650211FX ST625211CF 4845 ST625211FX LBA mode When addressing these drives in LBA mode, all blocks (sectors) are consecutively numbered from 0 to n–1, where n is the number of guaranteed sectors as defined above. -
Page 16: Recording And Interface Technology
Width (mm) 42.80 +/-0.101 (inches) 1.685 +/-0.004 Length (mm) 36.40 +/-0.15 (inches) 1.433 +/-0.006 Typical weight (grams) (pounds) 0.041 Interface Connector ST650211CF, ST625211CF CompactFlash Type II Connector (50-pin) ST650211FX, ST625211FX Seagate Flex Connector (45-way) ST1 Series Product Manual, Rev. A... -
Page 17: Seek Time
Seek time Seek measurements are taken with nominal power at 25°C ambient temperature. All times are measured using drive diagnostics. The specifications below are defined as follows: • Track-to-track seek time is an average of all possible single-track seeks in both directions. •... -
Page 18: Power Specifications
Power specifications The drive receives DC power (+3.3V or +5V) through the CompactFlash interface connector for ST650211CF and ST625211CF models, and (+3.3V only) through the Flex interface connector for ST650211FX and ST625211FX models. 2.9.1 Power consumption Power requirements for the drives are listed in the table on page 9. Typical power measurements are based on an average of drives tested, under nominal conditions, using +3.3V and +5.0V input voltage at 25°C ambient... -
Page 19: Figure 3. Typical 3.3V Startup And Operation Current Profile
Table 2: DC power ST1 Power Consumption (W) Average Average Max current the average of the 3.3V 3.3V 5.0V 5.0V peak value in 10ms window Current Spinup Load/Unload current Write Read Seek Performance idle Low power idle Standby/Sleep *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. -
Page 20: Conducted Noise
2.9.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise at up to 20 MHz. -
Page 21: Power-Management Modes
2.9.4 Power-management modes The drive provides programmable power management to provide greater energy efficiency. The drive features the following power-management modes: Table 3: Power management modes Power modes Heads Spindle Buffer Active (operating) Tracking Rotating Enabled Idle, low power Parked Rotating Disabled Standby/Sleep... -
Page 22: Environmental Specifications
2.10 Environmental specifications 2.10.1 Ambient temperature Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Actual drive case temperature should not exceed 70°C (158°F) within the operating ambient conditions. Above 1,000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. Operating 0°... -
Page 23: Shock
2.10.5 Shock All shock measurements in this section are carried out at drive level. For all linear shock test, Operating or Non-Operating, the input shock level shall be measured at the frame of the disk drive at the specific location indicated by the red ellipse in Figure 4 below for the CF and interface drives. -
Page 24: Vibration
2.10.6 Vibration All vibration specifications assume that the drive is mounted securely in a fixture that do not have fixture reso- nances in the frequency test range. The input vibration is applied through the disk drive guide rails of the device under test. - Page 25 2.10.6.4 Operating Random Vibration The test consists of 15 minutes of random vibration using the power spectral density (PSD) levels specified in the table below. The vibration test level is 3.01Gs RMS. The drive will not incur any physical damage when subsequently put into operation.
-
Page 26: Acoustics
2.11 Acoustics Drive acoustics are measured as overall A-weighted acoustic sound power levels (no pure tones). Discrete tone penalties are added to the A-weighted sound power (LW) with the following formula only when determin- ing compliance: LWt(spec) == LW + 0.1Pt + 0.3 < 4.0 (Bels) where LW = A-weighted sound power level pt == Value of discrete tone penalty [==dLt-6.0 (dBA)]... -
Page 27: Reliability
2.13 Reliability Measurement type Specification Nonrecoverable read errors 1 per 10 bits read, max. Mean time between failures 100,000 power-on hours At nominal power, 40°C ambient temperature. Max case temperature: 60°C at the case measurement location shown in Figure 6 and 7. -
Page 28: Agency Certification
Information Technology Equipment (ITE). Emission levels are defined by EN 55022, Class B and the immunity levels are defined by EN 55024. Seagate uses an independent laboratory to confirm compliance with the EC directives specified in the previous paragraph. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives. - Page 29 Seagate Technology LLC has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disc drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. Operation with noncertified assemblies is likely to result in interference to radio and television reception.
- Page 30 ST1 Series Product Manual, Rev. A...
-
Page 31: Configuring And Mounting The Drive
Configuring and mounting the drive This section contains the specifications and instructions for configuring and mounting the drive. Handling and static discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic dis- charge (ESD) hazards. Observe the following standard handling and static-discharge precautions: Caution: •... -
Page 32: Figure 6. Cf Model Mechanical Dimensions-Top, Side And End View
FINGER GRIP Breather Hole Do not cover Dimension Table Inches Millimeters 0.197 5.00 1.433 ± .006 36.40 ± .15 1.685 ± .004 42.80 ± .10 1.015 ± .003 2x 25.78 ± .07 1.152 ± .010 29.25 ± .25 0.299 ± .010 7.61 ±... -
Page 33: Figure 7. Fx Model Mechanical Dimensions-Top, Side And End View
FINGER GRIP Breather Hole Do not cover Dimension Table Inches Millimeters 0.197 5.00 1.433 ± .006 36.40 ± .15 1.685 ± .004 42.80 ± .10 1.015 ± .003 2x 25.78 ± .07 1.152 ± .010 29.25 ± .25 0.299 ± .010 7.61 ±... - Page 34 ST1 Series Product Manual, Rev. A...
-
Page 35: Interface Description
interface description These drives use the industry-standard ATA task file interface that supports 16-bit data transfers. It supports ATA programmed input/output (PIO) modes 0–4; multiword DMA modes 0–2, and Ultra DMA modes 0–2. The drive also supports the use of the IORDY signal to provide reliable high-speed data transfers. For detailed information about the CompactFlash interface, refer to CF+ and CompactFlash Spec Rev 2.0. - Page 36 Table 8: CompactFlash+ interface connector signals PC Card Memory Mode PC Card I/O Mode True IDE Mode -IOIS16 -IOIS16 -CD2 Ground -CD2 Ground -CD2 Ground -CD1 Ground -CD1 Ground -CD1 Ground I1Z, OZ3 I1Z, OZ3 I1Z, OZ3 I1Z, OZ3 I1Z, OZ3 I1Z, OZ3 I1Z, OZ3 I1Z, OZ3...
-
Page 37: Flex Interface Connector Signals
4.1.1 Flex Interface Connector Signals The following table summarizes the signal on the Seagate Flex interface connector. For a detailed description of these signals, refer to ATA-7 Specifications Revision 7.0. Table 9: Flex interface connector signals Signal Description Ground Ground... - Page 38 Table 9: Flex interface connector signals Data bus bit 9 GROUND Ground DD13 Data bus bit 13 CSEL Cable select DD12 Data bus bit 12 Data bus bit 7 Data bus bit 6 Data bus bit 5 Data bus bit 4 Data bus bit 3 Data bus bit 2 GROUND...
-
Page 39: Supported Ata Commands
4.1.2 Supported ATA commands The following table lists ATA-standard commands that the drive supports. For a detailed description of the CF commands, refer to CF+ and CompactFlash Spec Rev 2.0. Table 10: Supported commands Does command cause drive to Command name Command code (in hex) transition to active mode? [1] ATA-standard commands... - Page 40 Table 10: Supported commands Does command cause drive to Command name Command code (in hex) transition to active mode? [1] Write Multiple Write Multiple w/o Erase Write Sectors Write Sector w/o Erase Write Verify ATA-standard power-management commands Check Power Mode or E5 Idle or E3...
-
Page 41: Identify Device Command
Firmware revision x.xx x.xx x.xx padded with blanks to end of string) Drive model number: Drive model number (left (40 ASCII characters, ST650211CF ST650211CF ST650211FX 27–46 justified) big endian byte padded with blanks to end ST625211CF ST625211CF ST625211FX order in word of string) ST1 Series Product Manual, Rev. - Page 42 Word ATA specification CF specification Value Value Value (Bits 7–0) Maximum Maximum number of sectors per interrupt on sectors on Read/Write 8010 8010 8010 Read multiple and Write Multiple command multiple (16) Reserved Reserved 0000 0000 0000 Capabilities Capabilities 0A00 0B00 0B00 Reserved...
- Page 43 4040 ment value ment value 92-127 Reserved 0000 0000 0000 Security status Security status 0000 0000 0000 129–159 Seagate-reserved Seagate-reserved 0000 0000 0000 CFA power mode 1 Power Level Description 814A 814A 814A Reserved for assignment 0000 0000 0000 by the CFA...
- Page 44 See the bit descriptions below for words 63, 88, 93 and 94 of the Identify Drive data: Note. Description (if bit is set to 1) Word 63 Multiword DMA mode 0 is supported. Multiword DMA mode 1 is supported. Multiword DMA mode 2 is supported. Multiword DMA mode 0 is currently active.
-
Page 45: Set Features Command
4.1.4 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an inter- rupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. Power-on default has the read look-ahead feature enabled and write caching feature disabled. - Page 46 4 Bytes of ECC apply on Read/Write Long Command Enable Power On Reset (POR) establishment of defaults at soft reset Seagate Unique; Disable Reassignment Seagate Unique; Enable Reassignment At power-on, or after a hardware or software reset, the default values of the features are as indi- Note.
-
Page 47: Card Information Structure (Cis) Information For Cf
4.1.5 Card Information Structure (CIS) Information for CF CIS information for the CF card is as follows: Data Description of data Address Common Memory Device Information in 5V Operation 000H CISTPL_DEVICE 002H TPL_LINK = 04 bytes CISTPL_DEVICE: Device ID Device type (bit 4...7 = D (DTYPE_FUNCSPEC) 004H WPS (write protect switch) (bit 3) = 1 (non WP) Device Speed (bit 0...2) = 7 (DSPEED_EXT) - Page 48 Manufacturer Identification String 022H CISTPL_MANFID 024H TPL_LINK = 04 bytes 026H TPL_MANF: Manufacturer’s ID code (Low byte) = 11 for SEAGATE 028H TPL_MANF: Manufacturer’s ID code (High byte) = 01 for SEAGATE 02AH TPLMID_CARD: Product code (Low byte) (Manufacturer Info) 02CH...
- Page 49 060H CISTPL_FUNCE: (Function Extension Tuple) 062H TPL_LINK =3 bytes 064H TUPLE_TYPE: (Extension Type) = 02 (Basic PC Card ATA Interface) TPLFE_DATA V : Vpp[2::1] (bit0,1) = 00 (Vpp not required) 066H S : Silicon (bit2) = 0 (Rotating Device) U : Inique (bit3) = 0 (Single Drive) D : Dual Drive (bit4) = 0 (Single Drive) TPLFE_DATA P0 : Sleep (bit0) = 1 (Support Sleep mode)
- Page 50 TPCE_FS: (Feature Selection Byte) Power (bit0,1) = 01 (Vcc Only) Timing (bit2) = 0 I/O (bit3) = 0 080H Interrupt (bit4) = 0 Memory (bit5,6) = 01 Misc (bit7) = 1 TPCE_PD (Power Description Structure) TPCE_PS: Parameter Selection Byte NomV (bit0) =1 082H MinV (bit1) = 1 MaxV (bit2) =1...
- Page 51 TPCE_INDX: (Configuration Table Index Byte) Config Entry Number (bit0..5) = 00 (Memory Mode) 098H Default (bit6) = 0 Interface (bit7) = 0 (Interface Field Exist) TPCE_FS Power (bit0,1) = 01 (Vcc Only) Timing (bit2) = 0 09AH I/O (bit3) = 0 Interrupt (bit4) = 0 Memory (bit5,6) = 00 Misc (bit7) = 0...
- Page 52 TPCE_FS: (Feature Selection Byte) Power (bit0,1) = 01 (Vcc Only) Timing (bit2) = 0 I/O (bit3) = 0 0AEH Interrupt (bit4) = 0 Memory (bit5,6) = 01 Misc (bit7) = 1 TPCE_PD (Power Description Structure) TPCE_PD: Parameter Selection Byte NomV (bit0) =1 0B0H MinV (bit1) = 1 MaxV (bit2) =1...
- Page 53 For PC Card ATA I/O in Contiguous Memory Mode in 3.3V Operation (Default) 0C6H CISTPL_CFTABLE_ENTRY: (16 Bit PCCard Configuration Table Entry Tuple) 0C8H TPCE_LINK = 07h bytes TPCE_INDX :(Configuration Table Index Byte) Config Entry Number (bit0..5) = 01 (I/O and Memory Mode) 0CAH Default (bit6) = 0 Interface (bit7) = 0 (Interface Field Exist)
- Page 54 TPCE_FS: (Feature Selection Byte) Power (bit0,1) = 01 (Vcc Only) Timing (bit2) = 0 I/O (bit3) = 0 0E0H Interrupt (bit4) = 0 Memory (bit5,6) = 01 Misc (bit7) = 1 TPCE_PD (Power Description Structure) TPCE_PD: Parameter Selection Byte NomV (bit0) =1 0E2H MinV (bit1) = 1 MaxV (bit2) =1...
- Page 55 TPCE_IR: (Interrupt Request Description Structure) IRQ Line 0..15 (bit0..3) = E MASK (bit4) = 0 0FEH Level (bit5) = 1 Pulse (bit6) = 1 Share (bit7) = 1 TPCE_MI: (Miscellaneous Features Field ) Max Twin Card (bit0..2) = 0 100H Audio (bit3) Read Only...
- Page 56 TPCE_INDX :( Configuration Table Entry Tuple) Config Entry Number (bit0..5) = 03 (Secondary I/O Mode) 118H Default (bit6) = 1 Interface (bit7) = 1 (Interface Field Exist) TPCE_IF: (Interface Description Field) Interface Type (bit0..3) = 01 (I/O and Memory) BVDS active (bit4) = 0 11AH WP active (bit5) = 0 READY active (bit6) = 1...
- Page 57 130H 132H TPCE_IO: I/O Address Block Length = 8 134H TPCE_IO: I/O Address Range Description Field #2 Address = 376 136H 138H TPCE_IO: I/O Address Block Length = 2 TPCE_IR: (Interrupt Request Description Structure) IRQ Line 0..15 (bit0..3) = E MASK (bit4) = 0 13AH...
- Page 58 14EH TPCE_PD: Extension = 1Eh = +30 --+ 150H CISTPL_NO_LINK 152H TPCE_LINK 154H CISTPL_END ST1 Series Product Manual, Rev. A...
-
Page 59: Seagate Technology Support Services
+1-405-324-4770. Presales, Technical Support and Warranty Service Presales Support Our Presales Support staff can help you determine which Seagate products are best suited for your specific application or computer system. Technical Support If you need help installing your drive, consult your system's documentation or contact the dealer's support ser- vices department for assistance specific to your system. - Page 60 Seagate service center representative for warranty-related issues. Resellers or end users of drive products should contact their place of purchase or one of the Seagate warranty service cen- ters for assistance. Have your drive’s “ST” model number and serial number available.
-
Page 61: Technical Support
Presales Support Call Center Toll-free Direct dial Americas 1-877-271-3285 +1-405-324-4730 +1-405-324-4704 Technical Support Call Center Toll-free Direct dial Americas 1-800-SEAGATE +1-405-324-4700 +1-405-324-4702 Warranty Service Call Center Toll-free Direct dial FAX / Internet USA, Mexico and 1-800-468-3472 +1-405-324-4720 +1-405-324-4722 Latin America... - Page 62 European Support Services For presales and technical support in Europe, dial the toll-free number for your specific location. If your location is not listed here, dial our presales and technical support call center at +1-405-324-4714 from 8:00 . to 11:45 .
- Page 63 Asia/Pacific Support Services For Asia/Pacific presales and technical support, dial the toll-free number for your specific location. The Asia/ Pacific toll-free numbers are available from 6:00 . to 10:45 . and 12:00 . to 6:00 . (Australian East- ern time) Monday through Friday, except as noted. If your location is not listed here, direct dial one of our tech- nical support locations.
- Page 64 ST1 Series Product Manual, Rev. A...
- Page 65 Index Drive Defense 1 drive diagnostics 7 drive self-test 1 Numerics 3D Defense System 1 electrical fast transient 16 electromagnetic compatibility 18 Electromagnetic Compatibility Directive 18 acoustics 16 electromagnetic immunity 16 Active mode 11 EMC compliance 18 agency certification (regulatory) 18 EN 60950 18 altitude 12 enclosures 19...
- Page 66 read/write heads 5 read/write power and current 8 Korean RRL 18 recording and interface technology 6 recording density 6 recording heads 1 recording method 6 LBA mode 5 register 35 length 6 relative humidity 12 Load/Unload 17 reliability 17 Load/Unload curren 9 resistance 10 logical geometry 5 RF 16...
- Page 67 track density 6 track-to-track seek time 7 TUV North America 18 UL 1950 18 voltage 10 voltage dips, interrupts 16 voltage tolerance 10 Warranty 17 warranty 2 weight 6 wet bulb temperature 12 width 6 Write Buffer 29 Write DMA 29 Write Multiple 30 Write Sectors 30 ST1 Series Product Manual, Rev.
- Page 68 ST1 Series Product Manual, Rev. A...
- Page 70 Seagate Technology LLC 920 Disc Drive, Scotts Valley, California 95066-4544, USA Publication Number: 100325578, Rev. A, Printed in USA...
