Brainboxes PX-335 Quick Manual

Features
• 4 port RS422/485
• pCI Express x1, x4, x8 x16 lane slots socket
size
• 128 Byte tx and 128 Byte Rx FIFos
• Up to 921,600 Baud
• DB9 connector (9 pin Male)
• Drivers for all popular operating systems
• Sample programs, test & terminal software
• Lifetime Support
• Lifetime Warranty (registration required)
options
px-335:
Lp pCIe 4xRS422/485
1MBaud
:
+44(0) 151 220 2500 | sales@brainboxes.com | www.brainboxes.com
PX-335
LP PCIe 4xRS422/485 1MBaud
"SERIAL CARDS EngInEERED to ExCEED ExpECtAtIonS"
Description
Low profile pCI Express Card providing four RS422/485 serial ports..
Data transfer rates up to 921,600 baud rates and the 128 byte deep
transmit and 128 byte and 128 byte receive FIFoS, coupled with 1Mbit/s
line drivers deliver uncompromising performance on your pC. Drivers
for Windows 32 bit and 64 bit operating Systems including Windows
2000, xp, Server 2003, Vista, Server 2008, Windows 7 and Windows 8.
pCI Express is the latest standard in pC connectivity.
With Brainboxes' industry renowned Lifetime Warranty and Lifetime Support!
Software
Microsoft signed drivers (easy installation & robust operation) for:
• Windows 7 32 bit 64 bit Editions
• Windows Server 2008 32 bit 64 bit Editions
• Windows Vista 32 bit 64 bit editions
• Windows Server 2003 32 bit 64 bit Editions
As well as: full product documentation, a thorough troubleshooting
guide and terminal software. Detailed sample source code for many
popular programming languages. Further oS support on next page.
oRDER
Description
Lp pCIe 4xRS422/485 1MBaud
RoHS Compliant
Code
px-335
