- Page 1 BATTERY BOOSTER/CHARGER MODEL No. BC 700 Par t No.6260025 OPERATING & MAINTENANCE INSTRUCTIONS...
-
Page 2: Table Of Contents
GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended. -
Page 3: Important: Safety Precautions
IMPORTANT: SAFETY PRECAUTIONS PLEASE READ BEFORE USING THIS UNIT WARNING: Some electronic equipment can be damaged by boost charging or use of start facility. Check your vehicle handbook before using your Start ‘N Charge. If in doubt consult the vehicle manufacturer. Nevertheless, you should not operate this equipment unless you are fully conversant with vehicle electrical systems, and battery charging techniques. -
Page 4: Electrical Connections
12. Before charging ensure the battery terminals are clean and that the cells are filled with electrolyte to the correct level by adding distilled water where necessary. 13. Where appropriate we recommend that the vehicles’ positive (+) lead to the battery is disconnected on the prior to charging. -
Page 5: Procedure For Normal Charging Ref. Fig. 1
PROCEDURE FOR NORMAL CHARGING Ref. Fig. 1 Check that the Charging Controller (6) is in the “O” (OFF) position. Connect the appropriate lead to the unearthed battery terminal (on most modern vehicles, this is the positive (+ve) terminal), then connect the other lead to the chassis (or a suitable engine bolt) away from the battery and fuel line. -
Page 6: Procedure For Engine Starting
PROCEDURE FOR ENGINE STARTING NORMAL The BC 700 is provided with a PCB which allows the constant control on the output voltage of the electromechanical battery chargers during the boost start. Through this system it is possible to avoid damages to the electronic devices of the new generation vehicles when the boost start reaches its voltage peak. - Page 7 This battery charger is designed to charge either 12V or 24V lead acid automotive batteries. Do not attempt recharge any other type of battery. Do not use the battery charger as a power source, eg., to run 12V power tools etc. NOTES: If the START ‘N CHARGE is overloaded at any time a thermal cutout will automatically come into operation and render it inoperative.
-
Page 8: Parts List
PARTS LIST Description Part No. Cable Clamp EM21605010 Switch 20A EM22205017 Switch 63A EM22205093 Microswitch EM22200031 Timer EM22215001 Switch 20A EM22205132 Green Pilot-Light EM22610003 Ammeter EM22600021 Green Pilot-Light EM22610008 Voltmeter EM22605004 Contactor EM22225004 Auxiliary Transformer EM44140001 Housing Assembly EM33700711 Red Charging Cable 25mm² 3 m EM43200020 Black Charging Cable 25mm²... -
Page 9: Parts Drawing
PARTS DRAWING - 9 -... -
Page 10: Wiring Diagram
WIRING DIAGRAM - 10 -... -
Page 11: Specifications
Duty Cycle..........30 sec. ON / 60 sec. OFF PARTS AND SERVICE CONTACTS For Spare Parts and Service, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 or e-mail as follows: PARTS: Parts@clarkeinternational.com... - Page 12 COD. 77610686...
