STARTER/CHARGER
MODEL NO: BC520P
PART NO: 6261082
OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS
GC01/18 REV 5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BC520P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke BC520P

  • Page 1 STARTER/CHARGER MODEL NO: BC520P PART NO: 6261082 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC01/18 REV 5...
  • Page 2: Environmental Recycling Policy

    Charger will give you long and satisfactory service. GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
  • Page 3: Specifications

    SPECIFICATIONS Model Number BC520P Dimensions (D x W x H) 320 x 490 x 730 Weight 24 kg Open circuit protection 200A Lamellar Fuse IP Rating IP20 Operating Temperature Range 0 to 40°C Input Voltage @50Hz 230 V AC Duty Cycle (Starting)
  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS WARNING: HIGHLY INFLAMMABLE HYDROGEN GAS IS RELEASED IN THE PROCESS OF BATTERY CHARGING. ALWAYS REMEMBER TO SWITCH OFF THE CHARGER/STARTER FIRST TO AVOID SPARKING. PLEASE READ BEFORE USING THIS UNIT 1. Battery acid is very corrosive. If spilled, clean the area immediately and wash with water.
  • Page 5: Electrical Connections

    9. Always consult the vehicle manufacturers instructions for disconnecting / charging the vehicle battery. CAUTION: SOME ELECTRONIC EQUIPMENT CAN BE DAMAGED BY BOOST CHARGING OR USE OF START FACILITY. CHECK YOUR VEHICLE HANDBOOK BEFORE USING YOUR STARTER/CHARGER. IF IN DOUBT CONSULT THE VEHICLE MANUFACTURER.
  • Page 6 OVERVIEW A ON/OFF Switch G RED positive lead with clamp B Boost Start/Charger Switch BLACK negative Lead with clamp C MAX/MIN Switch 12V Output D Ammeter 24V Output E Fuse Cover Power Setting Switch F Mains Lead with Plug M Thermal Overload Indicator The illustration above identifies the various components and controls.
  • Page 7: Procedure For Normal Charging

    ASSEMBLY The handle and wheels need to be assembled before use. Locate the handle at the back of the upper panel and secure with the four self tapping screws provided. Pass the axle into its housings at the bottom of the unit, then slide a wheel on to each end.
  • Page 8 on larger models by also switching the Power Setting switch to the 1 or 2 position as appropriate. i.e. 4 charging rates are possible - MIN-1, MIN-2, MAX-1 and MAX-2. 9. Keep the battery on charge until the Ammeter gauge reads zero (or 0-2 amps) or has stopped moving down.
  • Page 9: Procedure For Engine Starting

    PROCEDURE FOR ENGINE STARTING NOTE: We recommend that before attempting to boost start, you charge the battery for 10-15 minutes. This will improve the chance of a first time start, particularly with bigger engines. When the battery is completely flat, you must charge the battery for 10-15 minutes before attempting to start, otherwise you may cause damage to the vehicle electronic systems.
  • Page 10 MAINTANENCE This charger requires minimal maintenance. As with any appliance or tool, a few common sense rules will prolong the life of the battery charger. WARNING: ALWAYS BE SURE THE CHARGER IS UNPLUGGED FROM THE MAINS AND ANY BATTERY BEFORE PERFORMING ANY MAINTENANCE OR CLEANING.
  • Page 11: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 12: Parts List

    PARTS LIST No Description No Description Cover Panel Front panel Handle Axle L=415 Front Frame Lower Panel Ammeter 50A/Start Wheel Female Dinse Plug Transformer Starter Clamps 120A Black Charge Cable Front Control Panel Fuse 200A Rectifier Small Fuse Cover Thermostat PVC Input cable High/Low Power Switch Cable Clamp...
  • Page 13: Parts Diagram

    PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 14: Circuit Diagram

    CIRCUIT DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 15 NOTES ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
