ATCOM Rainbow 2 Features page 2

Display Features
LCD Display:224x128 dot-matrix,
4-level gray scale FSTN LCD
LCD Size:3.2"
LCD Comtrast:Adjustable
LCD Backlight:Adjustable
Install Option
Desk Mount:Yes
Wall Mount:No
Network Features
IP Version:IPv4
IP Assignment:Yes (Static
/ DHCP / PPPoE)
WiFi Connection:Optional
DNS:Yes (Primary and Secondary
DNS supported)
HTTP:Yes
SNTP Client:Yes
VLAN (802.1Q):Yes
QoS (DiffServ):Yes
VPN:Yes (L2TP VPN supported)
NAT Transverse:Yes (STUN mode)
Security:Yes (SRTP / TLS supported)
Others
Power Consumption:
Standby:1.0W, Working:2.2W
Operating Humidity:10 - 90%
Operating Environment:0°C -
45°C (32°F - 113°F)
Dimension (W x D x H):
218 x 176 x 129mm
Weight:1.3Kg
ATCOM TECHNOLOGY CO.,LTD
Add:A2F,Block 3 Huangguan Technology Park,#21 Tairan 9th Rd,Futian,Shenzhen,China
Tel:(86-755)83018618 Email:sales@atcomemail.com
www.atcom.cn
SIP Features
SIP Accounts:4
SIP Compatibility:SIP v1
(RFC2543), v2 (RFC3261),
Asterisk,Broadsoft,
ATCOM IP PBX
Keys Features
Programmable Keys:8
Features Keys:7 (Menu, Hold,
Redial, Mute, Headset, hands-free
speakerphone, Message)
Line LED Keys:4
Volume Control Keys:2
Context Sensitive Soft Keys:4
Navigation Keys:4
Configuration
Plug & Play Configuration:Server
based configuration
Manual Configuration:Internal Web
Configurator, Local (LCD based)
network Configuration
Auto Provision:TFTP / FTP / HTTP
/ PnP
Interface Features
Ethernet Ports:2x 10 / 100 Mbps
RJ45 Expansion Module Port:1 (Up
to 2x LCD Expansion Modules)
PoE (Power over Ethernet):IEEE
802.3af Class 2 standard compliant
Headset Jack:1x RJ9
Handset Jack:1x RJ9
Power adapter Jack:3.5mm,DC 5.0V,
1.0A
Rainbow 2
Audio Features
Handset,Speaker,Headset Volume
Ringtones:10+2 user define
Ringer Volume:8 levels + off
Audio Codec:G.711(A/μ),G.722
(Wideband),L16 PCM (Wideband),
G.726,G.729AB,iLBC
Software Features
Phone Book (Entries):200
Call Log Entries:200 Incoming calls
+ 200 Outgoing Calls +200 Missed
caslls
Conferncing:3 parties
Music On Hold:Supplied by Host
Service (PBX/SIP Server)
Phone Basic Functions:One-Touch,
Speed Dial, Redial,Call Forward,
Call Waiting, Call Transfer, Call
Hold, Call Return, Mute, Auto
answer, DND, Call History: Dialed
/Received/Missed, Direct IP Call
without SIP Proxy ,Hotline ,Dail
Plan,Set Date/Time Manually or
Automatically
Phone Functions with IP PBX:
Anonymous Call, Anonymous Call
Rejection, DND, Forward ,
Synchronization Message Waiting
Indicator (MWI) ,Voice Mail,Call
Park, Call Pickup Intercom, Paging,
Music on Hold, Call Recording
Page 2 of 2
