Parts List; Control Unit - Icom IC-208H Service Manual

SECTION 6

[CONTROL UNIT]

REF ORDER
NO. NO.
IC2 1110005780 S.IC
IC5 1180000420 S.IC
IC6 1140011370 S.IC
Q1 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q2 1590001650 S.TRANSISTOR XP4601 (TX)
Q3 1510000690 S.TRANSISTOR 2SA1734 (TE12R)
Q6 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q7 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
D4 1790001000 S.ZENER
D5 1790001170 S.ZENER
X1 6060000610 S.CERAMIC
R1 7210002920 VARIABLE
R2 7030003440 S.RESISTOR
R5 7210002920 VARIABLE
R6 7030003440 S.RESISTOR
R9 7030003640 S.RESISTOR
R11 7030003640 S.RESISTOR
R13 7030003520 S.RESISTOR
R14 7030003640 S.RESISTOR
R21 7030003440 S.RESISTOR
R22 7030003760 S.RESISTOR
R23 7030003560 S.RESISTOR
R24 7030003520 S.RESISTOR
R25 7030003560 S.RESISTOR
R26 7030003520 S.RESISTOR
R28 7030003520 S.RESISTOR
R29 7030003560 S.RESISTOR
R41 7030003800 S.RESISTOR
R42 7030003520 S.RESISTOR
R43 7030003520 S.RESISTOR
R44 7030001120 S.RESISTOR
R58 7030003680 S.RESISTOR
R59 7030003680 S.RESISTOR
R60 7030003680 S.RESISTOR
R61 7030003580 S.RESISTOR
R65 7030000360 S.RESISTOR
R74 7030000360 S.RESISTOR
R75 7030003560 S.RESISTOR
R76 7030003640 S.RESISTOR
R77 7030003570 S.RESISTOR
R79 7030000380 S.RESISTOR
R80 7030000380 S.RESISTOR
R81 7030000360 S.RESISTOR
R82 7030000360 S.RESISTOR
R84 7030003520 S.RESISTOR
C1 4030006880 S.CERAMIC
C3 4030006880 S.CERAMIC
C5 4030007130 S.CERAMIC
C7 4030007130 S.CERAMIC
C8 4030007130 S.CERAMIC
C10 4030007130 S.CERAMIC
C25 4030006860 S.CERAMIC
C26 4030006900 S.CERAMIC
C27 4030006860 S.CERAMIC
C29 4030006860 S.CERAMIC
C30 4030007090 S.CERAMIC
C31 4030007090 S.CERAMIC
C34 4030006900 S.CERAMIC
C35 4030011600 S.CERAMIC
C36 4030011600 S.CERAMIC
C37 4030011600 S.CERAMIC
C46 4510007310 S.ELECTROLYTIC
C49 4030006900 S.CERAMIC
C50 4030006860 S.CERAMIC
C51 4510007310 S.ELECTROLYTIC
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

PARTS LIST

DESCRIPTION
S-80945CLMC-G7F-T2
TA78L05F (TE12R)
HD6433842RD36H (FX2633D)
MA8062-L (TX)
MA8068-M (TX)
EFOS4914E3
EVU-F2AF20B55 (560K)
ERJ3GEYJ 102 V (1 kΩ)
EVU-F2AF20B55 (560K)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
MCR50JZHJ 82 Ω (820)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
MCR10EZHJ 680 Ω (681)
MCR10EZHJ 680 Ω (681)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
MCR10EZHJ 1 kΩ
MCR10EZHJ 1 kΩ
MCR10EZHJ 680 Ω (681)
MCR10EZHJ 680 Ω (681)
ERJ3GEYJ 472 V (4.7 kΩ)
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 101J-T
C1608 CH 1H 101J-T
C1608 CH 1H 101J-T
C1608 CH 1H 101J-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
16 CV 10 BS B
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
16 CV 10 BS B
[CONTROL UNIT]
REF ORDER
M.
NO. NO.
B J3 6510023680 CONNECTOR
B
B
DS1 5030002580 LCD
DS13 5040002930 S.LED
B DS14 5040002930 S.LED
B DS15 5040002930 S.LED
B DS16 5040002930 S.LED
B DS17 5040002930 S.LED
B DS18 5040002930 S.LED
DS20 5040002930 S.LED
DS21 5040002910 S.LED
B DS22 5040002920 LED
B DS23 5040002930 S.LED
B S1 2240000150 SWITCH
S3 2260001890 S.SWITCH
S4 2260001890 S.SWITCH
T S5 2260001890 S.SWITCH
B S6 2260001890 S.SWITCH
T S7 2260001890 S.SWITCH
B S8 2260001890 S.SWITCH
B S9 2260001890 S.SWITCH
B S10 2260001890 S.SWITCH
B S11 2260001890 S.SWITCH
B
B
B W1 7030000010 S.JUMPER
B
B
B EP9 6910015120 S.BEAD
B EP10 6910012350 S.BEAD
B EP11 6910012350 S.BEAD
B EP12 6910015120 S.BEAD
B EP17 6910015120 S.BEAD
B EP18 8930060040 LCD CONTACT SRCN-2633-SP-N-W
B EP19 0910056472 PCB
B
B
B
B
B
B
[VCO UNIT]
B
B
REF ORDER
B
NO. NO.
B
B Q1 1590003290 S.TRANSISTOR UN9213J-(TX)
B Q2 1590003300 S.TRANSISTOR UN921NJ-(TX)
B Q3 1530003580 S.TRANSISTOR 2SC5231C8-TL
B Q4 1530003580 S.TRANSISTOR 2SC5231C8-TL
B Q5 1530003580 S.TRANSISTOR 2SC5231C8-TL
Q50 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q100 1590003290 S.TRANSISTOR UN9213J-(TX)
B Q101 1530003580 S.TRANSISTOR 2SC5231C8-TL
B Q102 1530003580 S.TRANSISTOR 2SC5231C8-TL
B Q103 1530003580 S.TRANSISTOR 2SC5231C8-TL
B Q104 1530003580 S.TRANSISTOR 2SC5231C8-TL
B Q105 1590003290 S.TRANSISTOR UN9213J-(TX)
B
B
B D1 1720000650 S.VARICAP
B D2 1720000730 S.VARICAP
B D3 1720000730 S.VARICAP
B D4 1790001260 S.DIODE
B D5 1790001620 S.DIODE
B D6 1790001260 S.DIODE
B D50 1790001260 S.DIODE
B D51 1790001260 S.DIODE
B D100 1720000650 S.VARICAP
D101 1750000720 S.VARICAP
B D102 1750000720 S.VARICAP
B D103 1790001620 S.DIODE
D104 1790001260 S.DIODE
D105 1790001260 S.DIODE
6 - 1
DESCRIPTION
2633 FRONT CONNECTOR
L2-0736TAY
SML-512MW T86P
SML-512MW T86P
SML-512MW T86P
SML-512MW T86P
SML-512MW T86P
SML-512MW T86P
SML-512MW T86P
SML-020MYT
CV1074
SML-512MW T86P
JRS0000-1401
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
SKQDPA
MCR10EZHJ JPW (000)
MMZ2012D 301BT
MMZ1608Y 102BT
MMZ1608Y 102BT
MMZ2012D 301BT
MMZ2012D 301BT
B 5945B
DESCRIPTION
1SV286 (TPH3)
MA2S30400L
MA2S30400L
MA2S077-(TX)
1SV308 (TPL3)
MA2S077-(TX)
MA2S077-(TX)
MA2S077-(TX)
1SV286 (TPH3)
HVC375BTRF
HVC375BTRF
1SV308 (TPL3)
MA2S077-(TX)
MA2S077-(TX)
S.=Surface mount
