MW870UST
Digital Projector
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MW870UST and is the answer not in the manual?

Questions and answers

Related Manuals for BenQ MW870UST

Summary of Contents for BenQ MW870UST

  • Page 1 MW870UST Digital Projector User Manual...

  • Page 2: Table Of Contents

    Table of contents Important safety Personalizing the projector menu display............45 instructions ....3 Controlling the projector through a LAN environment..........46 Introduction....7 Displaying image through Q Presenter .. Projector features........7 ..............56 Shipping contents ........8 Using the Web Control Lock....60 Projector exterior view......10 Using the Projection Login Code ..

  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before Always open the lens shutter or...
  • Page 4 Safety Instructions (Continued) The lamp becomes extremely hot Do not place this product on an during operation. Allow the unstable cart, stand, or table. The projector to cool for approximately product may fall, sustaining serious 45 minutes prior to removing the damage.
  • Page 5 Safety Instructions (Continued) Do not place this projector in any of Do not block the ventilation holes. the following environments. - Do not place this projector on a blanket, bedding or any other soft surface. - Space that is poorly ventilated or - Do not cover this projector with a cloth confined.
  • Page 6 BenQ to have the projector serviced. Do not step on the projector or place any objects upon it. Besides probable...

  • Page 7: Introduction

    Introduction Projector features This model is one of the best projectors available in the world. You can enjoy the best video quality across various devices such as PC, laptop, DVD and VCR even document camera to bring all possibility to life. The projector offers the following features.

  • Page 8: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. *The warranty card is only supplied in some specific regions.

  • Page 9: Optional Accessories

    Spare lamp kit PointDraw pen ™ Ceiling mount kit Wall mount kit BenQ wireless dongle Document camera * The PointDraw pen is not sold worldwide. If you would like to purchase it, please ™ contact the regional point of sale.

  • Page 10: Projector Exterior View

    Projector exterior view External control panel superior Parte frontal/ (See "Projector" on page 11 details.) Lamp cover Focus slide lever Projection lens Vent (heated air exhaust) Speakers Front IR remote sensor Quick-release button Audio output jack Audio input jack S-Video input jack RGB signal output jack RGB (PC)/Component video (YPbPr/ YCbCr) signal input jack...

  • Page 11: Controls And Functions

    Controls and functions Projector AUTO Automatically determines the best picture timings for the displayed image. "Auto-adjusting the image" on page for details. Power/POWER indicator light Toggles the projector between standby mode and on.See "Starting up the projector" on page 28 for details.

  • Page 12: Mounting The Projector

    If you intend to mount your projector on the ceiling or wall, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit or wall mount kit and that you ensure it is securely and safely installed.

  • Page 13: Remote Control

    Remote control MODE/ENTER Selects an available picture setup mode. See "Selecting a picture mode" on page 37 for details. Activates the selected On-Screen Display (OSD) menu item. See "Using the menus" on page 31 for details. Left/ Starts the FAQ function. See "Utilizing FAQ function"...
  • Page 14 18. AUTO 23. ASPECT Automatically determines the best picture Selects the display aspect ratio. See timings for the displayed image. See "Selecting the aspect ratio" on page 36 "Auto-adjusting the image" on page 29 for details. details. 24. MIC/VOL Adjusts the microphone’s sound level. Right/ See for details.

  • Page 15: Replacing The Remote Control Battery

    Infra-Red (IR) remote control sensor is located on the front of the projector. The remote control must be held at an angle within 22.5 degrees perpendicular to the projector's IR remote control sensor to function correctly. The distance between the remote control and the sensor should not exceed 8 meters (~ 26 feet).

  • Page 16: Positioning Your Projector

    Rear Ceiling Select this location with the projector suspended upside- down from the ceiling behind the screen. Note that a special rear projection screen and the BenQ Projector Ceiling Mounting Kit are required for this installation location. Set Rear Ceiling in the SYSTEM SETUP: Basic >...

  • Page 17: Obtaining A Preferred Projected Image Size

    BenQ has provided a table of screen sizes to assist you in determining the ideal location for your projector. There are two dimensions to consider, the perpendicular horizontal distance from the center of the screen (projection distance), and the vertical offset height of the projector from the horizontal edge of the screen (offset).
  • Page 18 How to determine the position of the projector for a given screen size Select your screen size. Refer to the table on page and find the closest match to your screen size in the left columns labelled "Screen size". Using this value, look across this row to the right to find the corresponding distance from screen value in the column labelled "Distance from screen (mm)".

  • Page 19: Projection Dimensions

    4039 2561 There is 3% tolerance among these numbers due to optical component variations. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 20: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. • In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...
  • Page 21 Computer system requirements for USB display:: Operation System Minimum Hardware Requirements Requirements Windows XP Supports USB 2.0 Windows Vista CPU: Pentium 1G RAM: 512MB RAM Disk: 20MB hard driver space Computer system requirements for WiFi display:: Operation System Minimum Hardware Requirements Requirements Windows XP WiFi: 54 Mbps...

  • Page 22: Connecting A Computer Or Monitor

    Connecting a computer or monitor Connecting a computer ® ® The projector can connect to both IBM compatibles and Macintosh computers. A Mac adapter is needed if you are connecting legacy version Macintosh computers. To connect the projector to a notebook or desktop computer (using VGA): Take the supplied VGA cable and connect one end to the D-Sub output socket of the computer.

  • Page 23: Connecting A Monitor

    Connect the other end of the cable to the HDMI jack on the projector. • Many notebooks do not turn on their external video ports when connected to a projector. Usually a key combo like FN + F3 or CRT/LCD key turns the external display on/off. Locate a function key labeled CRT/LCD or a function key with a monitor symbol on the notebook.

  • Page 24: Connecting Video Source Devices

    Connecting Video source devices You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of matching terminals on both the projector and the Video source device as described below: Terminal Terminal appearance...

  • Page 25: Connecting An Hdmi Source Device

    Connecting an HDMI source device The projector provides an HDMI input jack that allows you to connect it to an HDMI source device like a DVD player, a DTV tuner, a display or a notebook computer. HDMI (High-Definition Multimedia Interface) supports uncompressed video data transmission between compatible devices like DTV tuners, DVD players and displays over a single cable.

  • Page 26: Connecting A Component Video Source Device

    Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output jacks available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a Component Video source device: Take a Component Video to VGA (D-Sub) adaptor cable and connect the end with 3 RCA type connectors to the Component Video output jacks of the Video source...

  • Page 27: Connecting With Document Camera

    Connecting an S-Video/composite source device Examine your Video source device to determine if it has an unused S-Video/composite output jack available: • If it has both jacks, use the S-Video output jack for connection as the S-Video terminal provides better picture quality than the Video terminal. •...

  • Page 28: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a power outlet. Check that the POWER indicator light on the projector lights orange after power has been applied. • Please use the original accessories (e.g. power cable) only with the device to avoid possible dangers such as electric shock and fire.

  • Page 29: Adjusting The Projected Image

    You can also press SOURCE on the projector or remote control to select your desired input signal. See "Switching input signal" on page 34 for details. If the frequency/resolution of the input signal exceeds the projector's operating range, you will see the message 'Out of Range' displayed on a screen.

  • Page 30: Correcting Keystone

    Fine-tuning the image size and clarity Sharpen the image by using the focus ring/ focus slide lever. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom. It occurs when the projector is not perpendicular to the screen. To correct this, besides adjusting the height of the projector, you will need to manually correct it following one of these steps.

  • Page 31: Using The Menus

    Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjusents and settings. Below is the overview of the OSD menu. Main menu icon Main menu Highlight Status Sub-menu Press MENU/ EXIT to the previous page or to exit.

  • Page 32: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector. See item 22 on page for details.

  • Page 33: Entering The Password Recall Procedure

    Write down the number and turn off your projector. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector.

  • Page 34: Switching Input Signal

    Disabling the password function To disable password protection, go back to the SYSTEM SETUP: Advanced > Security Settings > Change Security Settings > Power on Lock menu after opening the OSD menu system. Select Off by pressing . The message 'INPUT PASSWORD' displays.

  • Page 35: Magnifying And Searching For Details

    In the unlikely event that you connect the projector to a DVD player via the projector's HDMI input and the projected picture displays wrong colors, please change the color space to YUV. Press MENU/EXIT and then press until the SOURCE menu is highlighted. Press to highlight Color Space Conversion and press to select a suitable...

  • Page 36: Selecting The Aspect Ratio

    Selecting the aspect ratio The 'aspect ratio' is the ratio of the image width to the image height. With the advent of digital signal processing, digital display devices like this projector can dynamically stretch and scale the image output to a different aspect than that of the image input signal.

  • Page 37: Optimizing The Image

    16:9: Scales an image so that it is displayed in the center of the screen with a 16:9 aspect ratio. This is most suitable for images which are already in a 16:9 aspect, like high definition TV, as it displays 16:9 picture them without aspect alteration.

  • Page 38: Using Wall Color

    Setting the User 1/User 2 mode There are two user-definable modes if the current available picture modes are not suitable for your need. You can use one of the picture modes (except the User 1/User 2) as a starting point and customize the settings. Press MENU/EXIT to open the On-Screen Display (OSD) menu.

  • Page 39: Adjusting Sharpness

    Adjusting Sharpness The higher the value, the sharper the picture becomes. The lower the value, the softer the picture becomes. Adjusting Brilliant Color This feature utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing truer, more vibrant colors in picture. It enables a greater than 50% brightness increase in mid-tone images, which are common in video and natural scenes, so the projector reproduces images in realistic and true colors.
  • Page 40 Press MODE/ENTER and the 3D Color Management page displays. Highlight Primary Color and press to select a color from among Red, Yellow, Green, Cyan, Blue, or Magenta. Press to highlight Hue and press to select its range. Increase in the range will include colors consisted of more proportions of its two adjacent colors.

  • Page 41: Setting The Presentation Timer

    Setting the presentation timer The presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Go to the SYSTEM SETUP: Basic > Presentation Timer menu and press MODE/ENTER to display the Presentation Timer page.

  • Page 42: Remote Paging Operations

    Remote paging operations Connect the projector to your PC or notebook with a USB cable prior to using the paging function. "Connecting a computer" on page 22 for details. You can operate your display software program (on a connected PC) which responds to page up/down commands (like Microsoft PowerPoint) by pressing PAGE UP/DOWN on the remote control.

  • Page 43: Utilizing Faq Function

    Utilizing FAQ function The INFORMATION menu contains possible solutions to problems encountered by users regarding image quality, installation, special feature operation and service information. To get the FAQ information: Press on the remote control or press MENU/EXIT to open the OSD menu and press to highlight the INFORMATION menu.

  • Page 44: Operating In A High Altitude Environment

    Operating in a high altitude environment We recommend you use the High Altitude Mode when your environment is between 1500 m –3000 m above sea level, and ambient temperature is between 0°C–35°C. Do not use the High Altitude Mode if your altitude is between 0 m and 1500 m and ambient temperature is between 0°C and 35°C.

  • Page 45: Personalizing The Projector Menu Display

    Highlight Power on/off Ring Tone and select Off. The only way to change Power on/off ring tone is setting On or Off here. Setting the sound mute or changing the sound level will not affect the Power on/off ring tone. Adjusting the microphone’s sound level To adjust the sound level, press MIC/VOL +/- on the remote control, or...

  • Page 46: Controlling The Projector Through A Lan Environment

    Press to highlight Apply and press MODE/ENTER. Configuring the Wireless LAN Settings Connect the BenQ wireless dongle (optional) to the USB TYPE-A input jack of the projector. Highlight Wireless LAN in SYSTEM SETUP: Advanced > Network Settings menu and press MODE/ENTER.
  • Page 47 Enter the address of the projector in the address bar of your browser and press Enter. For example: http://10.60.7.31 The BenQ remote network operation page opens. • The web page control supports IE version 7.0 or higher.
  • Page 48 • The illustrations in web page control, Q Presenter and USB Reader sections are for the purpose of explanation and may differ from the actual design of your projector. Click Download to save Q Presenter software on your computer. You can also link to the web page control from Q Presenter > Settings > Advanced Setting > Control projector via web page on page 59.
  • Page 49 i. These buttons function the same as the ones on the remote control. See "Remote control" on page 13 for details. The Display Setting page allows you to operate the projector as if you were using the OSD menus. These functions are some useful menu settings. The Picture Setting page allows you to manage the projector as if you were using the PICTURE menu.
  • Page 50 The Conference Control page allows you to control computer’s display status of all the computers linked to this projector. The Crestron page is only available when you are on a Wired LAN network. It also allows you to control the projector remotely. The Crestron supports RoomView version 6.2.2.9. Operation...
  • Page 51 i. These buttons function the same as the ones on the OSD menus or remote control. See "2. PICTURE" on page 67 "Remote control" on page 13 details. The Menu button can also be used to go back to previous OSD menu, exit and save menu settings.
  • Page 52 i. You can name the projector, keep track of its location and the person in charge of it. ii. You can adjust the Wired LAN settings. iii. Once set, access to the remote network operation on this projector has been password-protected.
  • Page 53 The Basic page allows you to change the password and select connected persons. The number of connected persons may affect the network display performance. Operation...
  • Page 54 The Wired LAN page allows you to adjust the Wired LAN settings. The Wireless LAN page allows you to adjust the Wirless LAN settings. Max. length for SSID string is 16 bytes. Please use a different SSID when more than two projectors are connecting through wireless LAN.
  • Page 55 The Mail page allows you to send alert e-mail to your ITS administrator. You can first try the Mail Test function to check if the Alert Mail works. Operation...

  • Page 56: Displaying Image Through Q Presenter

    Displaying image through Q Presenter The Q Presenter is an application running on the host PC. It connects to an available network display and transfers the desktop contents to the network display via local network connection. Be sure to turn off other virtual network control programs before using Q Presenter. Connect the projector with the RJ45 cable, and make sure your laptop or computer also link to the LAN.
  • Page 57 ii. Projectors linked in the LAN will be found. Then select the projector you want to link. iii. Click “Connect”. Then you should be able to see the image on projector. iv. You can click to disconnect all connected projectors.. The Special Feature page allows you to have some advanced functions to manage the display image on your projector.
  • Page 58 ii. You can select to stop/start displaying desktop contents to connected network display. iii. 4-1 Display (up to 4 computers can shoot to 1 projector at the same time). Click the location you want to display. 4locations can be chosen (1-4) or 2 places (L and R) if it’s 2 computers.
  • Page 59 You can select whether to automatically open the Q Presenter application when the computer is powered on. x. Once set, press Apply to save the changes. xi. You can link to the BenQ remote network operation page on page 47. Operation...

  • Page 60: Using The Web Control Lock

    Using the Web Control Lock This function is designed to prevent unauthorized people from maliciously changing the projector settings through the Projector Network Display System. To enable the function: After your computer is connected to the projector, enter the address of the projector in the address bar of your browser and press Enter.

  • Page 61: Presenting From A Usb Reader

    Presenting From a USB Reader This fature displays a slide show of images stored on a USB flash drive connected to the projector. It can eliminate the need for a computer source. Image File Types USB Reader displays images files in JPEG, GIF, TIFF, PNG and BMP formats. •...
  • Page 62 ii. Selected folder iii. Supported file format iv. Unsupported file format Press open folder Enter scroll through thumbnails four arrow keys return to a previous page Auto exit USB Reader Exit change to a different page go back to the first page of that folder Back start slide show Slideshow when an image is highlighted.
  • Page 63 start/stop slideshow Enter Settings page: i. You can adjust order settings. ii. You can adjust Slideshow settings. iii. Press OK to save the settings. iv. Press Cancel to ignore the change. Operation...

  • Page 64: Remote Desktop Control Through Q Presenter

    Remote Desktop Control through Q Presenter The Q Presenter can proceed the Remote Desktop Control (RDC) the host PC from projector site. Setup the RDC login account (User name and Password ) in Q Presenter. • Name: must be 8 English capital letters A~Z and number 0 ~9. •...
  • Page 65 Open the OSD menu and go to the SYSTEM SETUP: Advanced > Network Settings menu. Press MODE/ENTER. Highlight Remote Desktop and press MODE/ ENTER. Enter the Account and Password the same as step 1. Highlight Connect and press MODE/ENTER to connect the selected PC. Connect USB keyboard or mouse to control the host PC’s desktop through the projector.

  • Page 66: Pointdraw™ Pen

    PointDraw™ Pen The PointDraw™ pen works like a wireless mouse - but one that works in midair, not on your desktop. Just hold the pen in your hand, and point it at the projected image to point, click and drag. Please find latest compatible PointDraw™ pen user guide for more detail. Shutting down the projector Press Power on the projector.

  • Page 67: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Green/ Wall Color Blue/Blackboard Aspect Ratio Auto/Real/4:3/16:9/16:10 Auto Keystone On/Off Keystone Position DISPLAY Phase H. Size Digital Zoom 3D Sync On/Off...
  • Page 68 Disable/5 min/10 min/15 min/20 Settings Blank Timer min/25 min/30 min Disable/30 min/1 hr/2 hr/3 hr/4 hr/ Sleep Timer 8 hr/12 hr Remote Front+Rear/Front/Rear Receiver Panel Key Lock On/Off Yes/No Background BenQ/Black/Blue/Purple Color Splash Screen BenQ/Black/Blue PointDraw™ Single Pen/Dual Pen/Off Operation...

  • Page 69: Advanced Settings

    Quick Cooling On/Off High Altitude Mode On/Off Mute On/Off Volume Microphone Audio Settings Volume Power on/off Ring On/Off Tone Lamp Mode Normal/Economic Lamp Settings Reset lamp timer Equivalent lamp hour Change password Power on Lock Security Change Security Settings Splash Screen On Lock Settings Web Control Lock 2400/4800/9600/14400/19200/...
  • Page 70 FAQ-Image and Installation FAQ-Features and Service Source Picture Mode INFORMA Resolution TION Current System Status Color System Equivalent Lamp Hour Firmware Version Note that the menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible.

  • Page 71: Description Of Each Menu

    Description of each menu • The default values listed in this manual, especially on pages 71-80, are for reference only. They may vary between the projectors due to the continuous improvement to the products. FUNCTION DESCRIPTION Corrects the projected picture’s color when the projection surface is Wall Color not white.
  • Page 72 FUNCTION DESCRIPTION This projector features a 3D function which enables you to enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view the 3D images.
  • Page 73 FUNCTION) DESCRIPTION Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. See "Selecting a picture mode" on page 37 for details. Selects a picture mode that best suits your need for the image quality and further fine-tune the image based on the selections listed on the Reference same page below.
  • Page 74 FUNCTION DESCRIPTION Adjusts white peaking while maintaining correct color presentation. Brilliant "Adjusting Brilliant Color" on page 39 for details. Color This function is only available when User 1/2 is selected. "Selecting a Color Temperature" on page 39 for details. Color Temperature This function is only available when User 1/2 is selected.

  • Page 75: Timer Display

    FUNCTION DESCRIPTION Reminds the presenter to finish the presentation within a certain time frame. See "Setting the presentation timer" on page 41 details. Timer period Sets a preferred length of time for presentation. Timer display Presentation Sets whether to display the timer on screen. Timer Timer position Sets the position where the timer displays on screen.
  • Page 76 Allows you to select which background color will display when no Background signal is input into the projector. Four options are available: BenQ Color logo, Black, Blue, or Purple. Allows you to select which logo screen will display during projector start-up.

  • Page 77: Microphone Volume

    FUNCTION DESCRIPTION Selecting On enables the function and the projector cooling time will be shortened to a few seconds. Quick Cooling If you attempt to restart the projector right after the quick cooling process, it may not be turned on successfully and will rerun its cooling fans.
  • Page 78 FUNCTION DESCRIPTION Selecting On enables the function and the projector displays the grid Test Pattern test pattern. It helps you adjust the image size and focus and check that the projected image is free from distortion. Closed Caption Enable Activates the function by selecting On when the selected input signal carries closed captions.

  • Page 79: Wired Lan

    FUNCTION DESCRIPTION Network Selecting On enables the function, and the projector can be monitored or controlled over a network when it is in standby mode. Microphone Selecting On enables the function, and the microphone can be used even in standby mode Standby Monitor Out Settings...
  • Page 80 FUNCTION DESCRIPTION FAQ-Image Installation Displays possible solutions to problems you may encounter. FAQ- Features and Service Source Shows the current signal source. Picture Mode Shows the selected mode in the PICTURE menu. Lamp Mode Shows the current lamp mode. Current Resolution System Shows the native resolution of the input signal.

  • Page 81: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens and case clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 82: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows: Total (equivalent) lamp hour = 1 (hours used in Economic mode) + 4/3 (hours used in normal mode) "Setting Lamp Mode as Economic"...

  • Page 83: Timing Of Replacing The Lamp

    Timing of replacing the lamp When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode.

  • Page 84: Replacing The Lamp

    • To assure optimal performance from the projector, it is recommended that you purchase a BenQ projector lamp for lamp replacement. Turn the power off and disconnect the projector from the power outlet. If the lamp is hot, avoid burns by waiting for approximately 45 minutes until the lamp has cooled.
  • Page 85 Remove the lamp cover by (a) sliding the cover toward the side of the projector and (b) lifting it off. • Do not turn the power on with the lamp cover removed. • Do not insert your fingers between the lamp and the projector.

  • Page 86: Resetting The Lamp Timer

    Tighten the screws that secure the lamp. • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screws. Ensure the handle is fully laid flat and locked in place. Replace the lamp cover by sliding it into place.
  • Page 87 Indicators Light Status & Description POWER TEMP LAMP Power events Stand-by mode Orange Green Powering up Flashing Normal operation Green Orange Normal power-down cooling Flashing Download mode Orange Flashing Flashing Lamp events First lamp-lit error cooling Flashing Lamp error in normal operation Thermal events Fan 1 error( Lamp Fan) Flashing 1time...

  • Page 88: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the There is no power from the power cable. power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 89: Specifications

    Specifications All specifications are subject to change without notice. Optical Input terminals Resolution Computer input 1280 x 800 WXGA RGB input Display system D-Sub 15-pin (female) x 2 1-CHIP DMD Video signal input Lens F/Number S-VIDEO F = 2.7 Mini DIN 4-pin port x 1 f = 5.45 mm VIDEO Lamp...

  • Page 90: Dimensions

    Dimensions 330 mm (W) x 278 mm (H) x 154 mm (D) 77.5 62.5 Ceiling mount installation Ceiling mount screws: Unit: mm M4 x 8 (Max. L = 8 mm) 75.0 175.0 146.0 221.0 22.0 89.3 62.5 116.1 163.0 164.0 164.0 328.0 Specifications...

  • Page 91: Wall Mount Installation

    Wall mount installation Minimum installation requirements Computer SMART SMART Promethean Promethean Hitachi Diagram StarBoard Resolution: XGA Board Board ActivBoard ActivBoard CkassBiard2 StarBoard Reference FX-77 Image 77.5 FX-63 Resolution: XGA Image Diagonal (inches) Image Height 1037 1050 1050 1073 (mm) Image Width 1379 1659 1379...
  • Page 92 The dimensions are based on the BenQ wall mount (P/N: 5J.J4R10.001). • All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector’s optical characteristics.

  • Page 93: Timing Chart

    Timing chart Supported timing for PC input Horizontal Pixel Vertical Resolution Frequency Frequency Mode Frequency (Hz) (kHz) (MHz) 720 x 400 31.469 70.087 28.322 720 x 400_70 31.469 59.940 25.175 VGA_60 640 x 480 37.500 75.000 31.500 VGA_75 43.269 85.008 36.000 VGA_85 37.879...

  • Page 94: Supported Timing For Hdmi Input

    Supported timing for HDMI input Horizontal Pixel Vertical Resolution Frequency Frequency Mode Frequency (Hz) (kHz) (MHz) 720 x 400 31.469 70.087 28.322 720 x 400_70 31.469 59.940 25.175 VGA_60 37.861 72.809 31.500 VGA_72 640 x 480 37.500 75.000 31.500 VGA_75 43.269 85.008 36.000...
  • Page 95 Supported timing for Component-YP input Signal Format Horizontal Frequency (kHz) Vertical Frequency (Hz) 480i(525i)@60Hz 15.73 59.94 480p(525p)@60Hz 31.47 59.94 576i(625i)@50Hz 15.63 50.00 576p(625p)@50Hz 31.25 50.00 720p(750p)@60Hz 45.00 60.00 720p(750p)@50Hz 37.50 50.00 1080i(1125i)@60Hz 33.75 60.00 1080i(1125i)@50Hz 28.13 50.00 1080p@60Hz 67.5 60.00 1080p@50Hz 56.25 50.00...

  • Page 96: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.
