BenQ MW870UST Limited Warranty

MW870UST
INTERACTIVE
PROJECTOR
Features
Native WXGA (1280 x 800) Resolution
3,000 ANSI Lumens; 2,600:1 Contrast Ratio
0.37 Ultra Short Throw, Mic Input,10 Watt Speakers x 2
LAN Control/Display, USB Reader/Display
Wireless Display (Optional)
PointDraw™ Interactivity Ready (Optional)
Top View

Input and Output Terminals

1 2 3 4 5
1 Audio-Out x1
2
Audio-In & MIC-In, Audio L/R
3
S-Video/Video
4
Monitor Out Output
5
Computer 1 & 2
BenQ America Corp.
15375 Barranca Parkway. Suite A-205. Irvine, CA 92618
BenQ is a registered trademark of BenQ Corp. DLP
Product names, logos, brands, and other trademarks featured or referred to in this materials are the property of their respective trademark holders.
Specifications subject to change without notice.
6
7 8 9
10
6 HDMI x1
7 RS232 x1
8
USB Type B & Mini B
9
USB Type A x2
10 RJ45 x1 (Control & Display)
Tel: (949) 255-9500
® is a registered trademark of Texas Instruments. All rights reserved.
Specifications
Projection System DLP ®
Native Resolution WXGA (1280x800)
Brightness 3,000 ANSI lumens
Contrast Ratio 2,600:1 (Full on/Full off)
Display Color 1.07 Billion Colors
Lens F=2.7, f=5.45mm
Aspect Ratio Native 16:10 (5 aspect ratio selectable)
Throw Ratio 0.37 (87"@0.73m)
Image Size (Diagonal) 60~300"
Zoom Ratio Fixed
Lamp Type 225W
Lamp (Normal/Eco Mode) 2,500/4,000 hrs (Normal/Economic mode)
Keystone Adjustment ID, Vertical ±30 degrees
Projection Offset 125% ±5%
Resolution Support VGA(640 x 480) to UXGA(1600 x 1200)
Horizontal Frequency 31K-102KHz
Vertical Scan Rate 23~120Hz
HDTV Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility NTSC, PAL, SECAM
3D Compatibility PC: 120Hz Frame Sequential 3D for resolutions up to WXGA,
PC: 60Hz Top-bottom 3D for resolutions up to SXGA+
Video: 60Hz Frame Sequential 3D for resolutions up to 480i
Interface
Computer in (D-sub 15pin)
Monitor out (D-sub 15pin)
HDMI
Composite Video in (RCA)
S-Video in (Mini DIN 4pin)
Audio in (Mini Jack)
Audio L/R in (RCA)
Audio out (Mini Jack)
Microphone in (Mini jack)
Speaker
LAN (RJ45)
USB (TypeA)
USB (TypeB)
USB (Mini Type B)
RS232 (DB-9pin)
IR Receiver
Dimensions 12.99" x 6.06" x 10.9"
9.1 lbs (4.1kg)
Weight
Power Supply AC 100 to 240 V, 50/60 Hz
Power Consumption 310W, Standby<1W
Audible Noise 33/31 dBA (Normal/Economical Mode)
Display Languages Bulgarian/ Croatian/ Czech/ Danish/ Dutch/ English/ Finnish/ French/
German/ Hungarian/ Italian/ Japanese/ Korean/ Norwegian/ Polish/
Portuguese/ Romanian/ Russian/ Simplified Chinese/Spanish/
Swedish/ Turkish/ Thai/ Traditional Chinese (24 Languages)
Picture Mode
Dynamic/Presentation/sRGB/Cinema/User 1/User 2
Accessories (Standard)
Remote Control w/ Battery, Power Cord, User Manual CD/Quick Start Guide,
Warranty Card, VGA(D-sub 15pin) Cable
Accessories (Optional) Wireless Dongle WDRL3070
PD03 Pen Kit
PD03 Pen
Spare Lamp Kit
Wall Mount
3D Glass
Carry Bag
Remote
8400460-2824-4 / 9H.J5L77.34A
UPC / Part #
Limited Warranty
3-Years Parts/Labor / 1-Year or 2000 hours of lamp life
*Lamp life results will vary depending on environmental conditions and usage. Actual product's features and
specifications are subject to change without notice.
www.BenQ.us
x 2 (Share with Component video in)
x 1
x 1
x 1
x 1
x 1
x 1
x 1
x 1
10W x 2
x 1
x 2 (wireless display/USB reader/remote desktop)
x 1(work for PD pen/ FW download)
x 1(USB display)
x 1
x 2
P/N: 5J.J0614.A21
P/N: 5J.J8E26.A01
P/N: 5J.J8E26.A11
P/N: 5J.J2V05.001
P/N: 5J.J4R10.001
P/N: 5J.J7K25.001
P/N: 5J.J2V09.011
P/N: 5J.J2V06.001
MW870UST 04-30-13-BQus
