PART IDENTIFICATION CHART

Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included. If a part is missing, please call 1-888-533-1333.
M8 Locknut M8 Split Washer M8 Washer M8 Curved
(37)––4 (45)––8 (56)––4 Washer (8)––2
M8 x 25mm
M4 x 16mm M4 x 16mm
M8 x 60mm
Screw (44)––6
Screw (40)––6 Round Head Screw (43)––4
Screw (54)––2
M10 x 80mm
Screw (36)––2
5
