Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 250 lbs.
This Product is Distributed Exclusively by
2040 N. Alliance, Springfield, MO 65803
www.staminaproducts.com
Customer Service
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following number :
Model#: 55-1510
STAMINA PRODUCTS
MADE IN CHINA
©
2011 Stamina Products, Inc.
2011, 08
Advertisement
Table of Contents
Related Manuals for Stamina inLine Inversion System
Summary of Contents for Stamina inLine Inversion System
- Page 1 CAUTION: Weight on this product should not exceed 250 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N. Alliance, Springfield, MO 65803 Customer Service © 2011 Stamina Products, Inc. 1 (800) 375-7520 2011, 08 www.staminaproducts.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety Instructions ........2 Maintenance ..........12 Before You Begin ........4 Warranty ............. 13 Equipment Warning & Notice Labels ..5 Product Parts Drawing ......14 Hardware Identification Chart ....6 Parts List ............ 15 Assembly Instructions ........ 7 Notes ............ -
Page 3: Customer Service
Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. ONLINE TELEPHONE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. customerservice@staminaproducts.com Tel: 1 (800) 375-7520 Fax: (417) 889-8064 ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071... -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for choosing the inLine® Inversion Although Stamina constructs its products with System. We take great pride in producing this the finest materials and uses the highest standards quality product and hope it will provide many hours... -
Page 5: Equipment Warning & Notice Labels
EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the inLine® Inversion System. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels. Labels are larger than actual size WARNING LABEL(50) INVERSION WARNING DECAL(32) -
Page 6: Hardware Identification Chart
HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws. -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed. - Page 8 ASSEMBLY INSTRUCTIONS NOTE: Do not over tighten BUTTON HEAD BOLTS(34, 35) as the FRONT and REAR PIVOT ARMS(4, 5) must be able to pivot freely after BUTTON HEAD BOLTS(34, 35) are tightened. STEP 3 Position the LEG EXTENSION(9) in front of the BUMPER(16). Attach the FRONT PIVOT ARMS(4) to the FRONT FRAME(2) with BUTTON HEAD BOLTS(M12x1.75x85mm)(35) on both sides.
- Page 9 ASSEMBLY INSTRUCTIONS STEP 4 Attach the SEAT(14) to the SEAT FRAME(6) with ROUND HEAD BOLTS(M6x1x15mm)(49). STEP 5 Insert the BACK FRAME(11) into the BACK PIVOT FRAME(8) and secure with BUTTON HEAD BOLTS (M8x1.25x15mm)(39). STEP 6 Attach the BACK CUSHION(15) to the BACK FRAME(11) with ROUND HEAD BOLTS(M6x1x15mm) (49).
- Page 10 ASSEMBLY INSTRUCTIONS STEP 7 Slide a FOAM PAD(21) onto a PAD TUBE(19) and press a SECURING PLUG(22) into the end of the PAD TUBE(19). Then insert the other end of the PAD TUBE(19) through one of the two holes in the LEG EXTENSION(9).
-
Page 11: Operational Instructions
OPERATIONAL INSTRUCTIONS GENERAL PRECAUTIONS 1. Do not use the inLine® Inversion System alone. Always have a helper available in case assistance is needed in recovering from the decline position. 2. Make sure that the FOAM PADS(21) are holding your feet properly. 3. -
Page 12: Storage
2. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts. Tighten loose nuts and bolts. 3. Verify that the WARNING LABEL(50) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement WARNING LABEL(50) if it is missing or damaged. -
Page 13: Warranty
To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520. -
Page 14: Product Parts Drawing
PRODUCT PARTS DRAWING BACK FRONT... -
Page 15: Parts List
PARTS LIST PART# PART NAME Rear Frame Front Frame Shaft Front Pivot Arm Rear Pivot Arm Seat Frame Pad Support Back Pivot Frame Leg Extension Linkage Back Frame Handrail Seat Frame Connecter Seat Back Cushion Bumper Stand Pivot Arm Bushing Pad Tube Seat Frame Bushing Foam Pad... - Page 16 PARTS LIST PART# PART NAME Washer (M12) Bolt, Round Head (M6 x 1 x 15mm) Warning Label Allen Wrench (6mm) w/ Screwdriver Allen Wrench (4mm) Allen Wrench (8mm) Manual...
-
Page 17: Notes
NOTES... -
Page 18: Fax/Mail Ordering Form
ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...
