Stamina BODYTRAC Owner's Manual
  1. Manuals
  2. Brands
  3. Stamina Manuals
  4. Fitness Equipment
  5. BODYTRAC
  6. Owner's manual

Stamina BODYTRAC Owner's Manual

35-1050c
Hide thumbs Also See for BODYTRAC:
Table of Contents

Advertisement

Quick Links

Owner's Manual
CAUTION:
Weight on this product should not exceed 250 lbs.
2013, 06
This Product is Produced Exclusively by
2040 N. Alliance, Springfield, MO 65803
Customer Service
1 (800) 375-7520
www.staminaproducts.com
WARNING
Exercise can present a health
risk. Consult a physician
before beginning any exercise
program with this equipment.
If you feel faint or dizzy,
immediately discontinue use
of this equipment. Serious
bodily injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur if
all instructions are not followed.
Keep others and pets away
from equipment when in use.
Always make sure all bolts and
nuts are securely tightened
prior to each use. Follow all
safety instructions in this
manual.
When calling for parts or
service, please specify the
following number :
Model#: 35-1050C
STAMINA PRODUCTS
MADE IN CHINA
Product May Vary Slightly
From Pictured.
2013 Stamina Products, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BODYTRAC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stamina BODYTRAC

Summary of Contents for Stamina BODYTRAC

  • Page 1 CAUTION: Weight on this product should not exceed 250 lbs. Product May Vary Slightly From Pictured. This Product is Produced Exclusively by 2040 N. Alliance, Springfield, MO 65803 Customer Service 1 (800) 375-7520 www.staminaproducts.com 2013, 06 2013 Stamina Products, Inc.

  • Page 2: Table Of Contents

    Do not position the BODYTRAC on loose rugs or uneven surfaces. Make sure that adequate space is available for access to and around the BODYTRAC Before using, inspect the BODYTRAC for worn or loose components, and securely tighten or replace any worn or loose components prior to use.

  • Page 3: Customer Service

    Monday - Thursday, 7:30 A.M. - 5:00 P.M., Central Time. Friday, 8:00 A.M. - 3:00 P.M., Central Time. TELEPHONE ONLINE MAIL CUSTOMER SERVICE CUSTOMER SERVICE CUSTOMER SERVICE STAMINA PRODUCTS, INC. Tel: 1 (800) 375-7520 Fax: (417) 889-8064 customerservice@staminaproducts.com ATTN: Customer Service www.staminaproducts.com P.O. Box 1071 Springfield, MO. 65801-1071...

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the BODYTRAC . We take Although Stamina constructs its products with the great pride in producing this quality product and hope finest materials and uses the highest standards of it will provide many hours of quality exercise to make manufacturing and quality control, there can you feel better, look better, and enjoy life to its fullest.

  • Page 5: Equipment Warning & Notice Labels

    EQUIPMENT WARNING & NOTICE LABELS This chart is provided to help identify the warning and notice labels on the BODYTRAC . Please take a moment to familiarize yourself with all of the warning and notice labels. Label is larger than actual size...

  • Page 6: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 8 ASSEMBLY INSTRUCTIONS STEP 2 Insert the Bracket on FRONT STABILIZER(28) into the FRONT SUPPORT(26). Attach the METER POST(31) to the FRONT SUPPORT(28), then bolt the METER POST(31), FRONT SUPPORT(26), and FRONT STABILIZER(28) together with BUTTON HEAD BOLTS(M8x1.25x15mm)(51) and WASHERS(M8)(59). Please do not tighten any of these bolts until all six bolts are attached. NOTE: Be careful not to damage the EXTENSION WIRE(38) when assembling the METER POST(32).
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 4 Insert the PEDAL SHAFT(32) through holes located on the METER POST(31). Place a PEDAL SPACER(33) and a PEDAL(34) onto each end of the PEDAL SHAFT(32) and slide them toward the METER POST(31). Then secure the PEDALS(34) with BUTTON HEAD BOLTS(M8x1.25x15mm)(51) and LARGE WASHERS (M8)(36) at both ends of the PEDAL SHAFT(32).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 6 Unfold the HANDLEBARS(17, 18) and the EXTENSION ARMS(14) as shown in the illustration. Attach the EXTENSION ARMS(14) to the PIVOT CONNECTOR(10) with the LOCKING KNOBS(13). STEP 7 Install two AA batteries into the METER(37), two batteries included. See page 12 for detailed battery installation instructions.
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 8 Slide the SEAT ASSEMBLY(42, 43) onto the CENTER BEAM(1). Attach the SEAT STOPPERS(3) to the back end of the CENTER BEAM(1) with BUTTON HEAD BOLTS(M8x1.25x25mm)(53). Also, please verify that the other SEAT STOPPERS(3) at the front end of the CENTER BEAM(1) are assembled at the factory. STEP 9 Press the CENTER BEAM CAP(2) into the back end of the CENTER BEAM(1).

  • Page 12: Operational Instructions

    OPERATIONAL INSTRUCTIONS USING THE FITNESS METER Power on : Seat movement or push the button. Power off : Automatic shut off after 4 minutes of inactivity. Function Button: MODE/RESET : Press and release to select functions. Press and hold for two seconds to reset all functions to zero, except TOTAL COUNT.

  • Page 13: Maintenance

    Clean the roller tracks in the CENTER BEAM(1) with an absorbent cloth. Verify that the WARNING LABEL(67) is in place and easy to read. Call Stamina Products immediately at 1-800-375-7520 for a replacement WARNING LABEL(67) if it is missing or damaged.

  • Page 14: Storage

    STORAGE To store the BODYTRAC simply keep it in a clean dry place. To avoid damage to the electronics meter, remove the batteries before storing the BODYTRAC for one year or more. Grasp the Front and Rear Stabilizer to move the BODYTRAC .

  • Page 15: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 16: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place Stretching Stretching while your muscles are warm after a proper warm-up and again after your strength...

  • Page 17: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. P.O. Box 1071, Springfield Missouri, USA, 65801-1071, or email us at customerservice@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 18: Product Parts Drawing

    PRODUCT PARTS DRAWING FRONT BACK...

  • Page 19: Parts List

    PARTS LIST PART# PART NAME Center Beam Center Beam Cap Seat Stopper Rear Support Stabilizer Cap Stabilizer Pad Threaded Support Plate Handlebar Support Sensor Support Plate Pivot Connector Pivot Bushing Bumper Knob Locking Knob Extension Arm Extension Arm Bushing Large Washer (3/8") Left Handlebar Right Handlebar Securing Cap...
  • Page 20 PARTS LIST PART# PART NAME Screw, Round Head (M3.5 x 15mm) Screw, Round Head (M5 x 0.6 x 12mm) Bolt, Round Head (M6 x 1 x 14mm) Bolt, Button Head (M8 x 1.25 x 15mm) Bolt, Button Head (M8 x 1.25 x 20mm) Bolt, Button Head (M8 x 1.25 x 25mm) Bolt, Button Head (M8 x 1.25 x 55mm) Bolt, Hex Head (M8 x 1.25 x 32mm)

  • Page 21: Notes

    NOTES...

  • Page 22: Fax/Mail Ordering Form

    FAX/MAIL ORDERING FORM Please do not return the product. For your convenience, Stamina's Customer Service Department can be reached by email at customerservice@staminaproducts.com or toll free at 1-800-375-7520 (in the U.S.). Should a part be missing or a defective part found, please call us from 7:30 A.M. to 5:00 P.M. Central Time, Monday through Thursday and 8:00 A.M.
