Lavatory faucet with selectronic technology

Advertisement

Quick Links

Moments Lavatory Faucet
with SELECTRONIC™ Technology
2506.1XX
Certified to comply with ASME A112.18.1M
© 2007 American Standard
M968506
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Faucets visit our website at: www.us.amstd.com or U.S.
customer's e-mail us at: faucetsupport@amstd.com
For Parts, Service, Warranty or other Assistance,
1-800-442-1902 (In Canada: 1-800-387-0369)
please call
Product No.'s & Options
Specifications
How to Install
Electrical Hook-up
Maintenance
FAQ,s
Replacement Parts
(In Toronto Area only: 1-905-3061093)
(In Toronto Area only: 1-905-3061093)
1
2
2-3
4-6
7-8
9
10

Advertisement

loading
Need help?

Need help?

Do you have a question about the Moments Lavatory Faucet 256.1XX and is the answer not in the manual?

Questions and answers

Summary of Contents for American Standard Moments Lavatory Faucet 256.1XX

  • Page 1 © 2007 American Standard M968506 NOTE TO INSTALLER: Please give this manual to the customer after installation. To learn more about American Standard Faucets visit our website at: www.us.amstd.com or U.S. customer's e-mail us at: faucetsupport@amstd.com For Parts, Service, Warranty or other Assistance,...
  • Page 2 605XTMV Thermostatic mixing valve, flex hoses 3/8" compression 20" hose length. All American Standard Faucets Are Water Tested At Our Factory. Some Residual Water May Remain In The Faucet During Shipping. 5b. AC Power Supply (for 2506.165/162 series) 5c. 10 ft. Extension Wire (for 2506.175/172 series) 6.
  • Page 3: Installation

    Fig. 1 159mm 154mm (6-1/4) (6-1/16) 55.5mm (2-3/16) 49mm 81mm (3-3/16) 114mm (4-1/2) 381mm (15) 500mm (20) 3/8" COMP. TOOLS REQUIRED; Fig. 2 1 Channel Locks 2 Adjustable Wrench 3 Plumbers' Putty or Caulking 4 Phillips Screwdriver 5 Flat Blade Screwdriver 6 Electric Drill &...
  • Page 4 MOUNT ENCLOSURE; Fig. 2 1. Determine location of ENCLOSURE (1). It must be located with-in the 14" (356mm) by 21" (533mm) shaded area shown in Figure 2 in order for electrical connections from the spout assembly to be made. NOTE: ENCLOSURE SUPPLY HOSE is 20". Distance between wall supply and ENCLOSURE (1) must be taken into consideration.
  • Page 9: Solenoid Valve

    Before opening ENCLOSURE CAUTION disconnect AC power supply. 1. Remove ENCLOSURE COVER. 2. Close SUPPLY STOP (5) with 4mm Hex wrench. Note: Keep water flowing out of faucet while shutting off. 3. Pull off Red (1) and Black (2) CONNECTORS from SOLENOID VALVE (3).
  • Page 10 FAQ'S Q: How will I know if battery needs to be replaced? A: Valve does not open and sensor blinks 2 times interrupted by pause for up to 7 days. Q: Why has the flow rate of the faucet reduced significantly? A: Check and clean aerator and strainer.
  • Page 11: Product Numbers

    A923672-0070A FAUCET SUPPLY HOSE A950223-007L0A SENSOR M962411-0070A MOUNTING KIT M962387-0070A MOUNTING SCREW KIT A913202-0070A WASHER A924162-0070A SUPPLY HOSE A922265-0070A 10 ft. MULTI EXTENSION WIRE (for 6057 series only) Replace the "YYY" with appropriate finish code CHROME HOT LINE FOR HELP For toll-free information and answers to your questions, call: 1 (800) 442-1902 Weekdays 8:00 a.m.
  • Page 12 M 9 6 8 5 0 6...
