- Page 1 Control Mount Instruction Manual CM-IW200...
-
Page 2: Required Tools
Distance (Feet) 22awg 20awg 18awg iPort Control Mount Box Contents: (1) iPort in-wall mounting system (faceplate and mounting cradle) ( 1) Audio wall plate (1) Regulated power supply (1) Installation cut-out template (1) Instruction manual Required Tools The following tools are required to install the iPort: • #2 Phillips screwdriver • W ire cutters and wire strippers • R J-45 cable crimp tool and modular connectors • S heet rock saw (for retrofitting into an existing wall) CM-IW200 Instruction Manual... -
Page 3: Selecting An Installation Location
Selecting an Installation Location The iPort Control Mount is designed for use in normal interior environments. When selecting an installation location for the Control Mount, please consider the following: • Do not use the Control Mount outside or in a humid or wet environment. It is not waterproof or water-resistant. -
Page 4: Installation Preparation
2. Perform an obstruction survey to ensure there are no studs, conduit, pipes, heating ducts, or air returns that will interfere with the Control Mount. Note: You can mount the CM-IW200 directly next to a wall stud on either side (see Step 8). - Page 5 INTERNET ETHERNET PORT LABEL SIZE: 2” x 0.5” ® U.S. Patent No. 7,493,142 Additional Patents Pending Designed and Engineered in the USA CM-IW200 33-5522 1-11 For local audio and extended power up to 200ft with 18 gauge wire For extended...
- Page 6 IMPORTANT: Do not install the iPort’s wall plate in the same electrical box as AC house wiring, a light switch, or any other high-voltage device or control. The wall plate can share gang boxes with other iPort Control Mount wall plates or...
- Page 7 4 screws. The back plate has a foam pad to hold the iPod touch very securly. See Figure 7 13. Place the conector board into the iPod touch and secure to backplate with 2 screws. See Figure 8. Connect RJ-45 Cable to connector Figure 7: Attach Back Plate Figure 8: Attach Connector Board CM-IW200 Instruction Manual...
- Page 8 Note: To sync your iPod touch with your computer, please follow the steps above in reverse order to remove the iPod touch and sync. Once your synchronization is complete, reinstall the iPod touch follow the steps to reassemble. Figure 9: Attaching Assembly CM-IW200 Instruction Manual...
-
Page 9: Operation
Use the iPod touch screen to choose: the home screen, applications, music, email. A power on/off button is located on the edge of the iPort Control Mount as noted in figure 10. Note: For questions regarding the touch- screen functions of your iPod touch, please visit: www.apple.com... -
Page 10: Specifications
Specifications Power supply: 15V DC, regulated Dimensions (W x H x D): 4 .027” x 5.969” x 2.4” (102.29mm x 151.61mm x 60.9mm) Cut-out Dimensions (W x H): 3.42” x 5 .34” (86.87mm x 135.64mm) 102.29mm 4.027in CM-IW200 Instruction Manual... - Page 11 Dealer/Distributor, will be free from defective workmanship and materials in the initial installation for the period stated below. iPort will at its option and expense during the warranty period, either repair the defect or replace the Product with a new or remanufactured Product or a reasonable equivalent at no charge for parts, labor and return shipping.
- Page 12 . 45 . iPort | www.iportmusic.com ©2011 Dana Innovations. All rights reserved. iPort and Roto-Lock are registered trademarks of Dana Innovations. iPod is a trademark of Apple Inc. “Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple performance standards.
