  • Page 1 Control Mount Instruction Manual CM-IW100T...
  • Page 2: Required Tools

    • Sheet rock saw (for retrofitting into an existing wall) Selecting an Installation Location The iPort Control Mount is designed for use in normal interior environments. When selecting an installation location for the Control Mount, please consider the following: • Do not use the Control Mount outside or in a humid or wet environment. It is not waterproof or water-resistant.
  • Page 3 Wiring Cat5/RJ-45 Cable The Cat5 cable and RJ-45 connector used in iPort installations must be wired according to the T568A (“Straight-Through”) Standard with cables wired identically at both ends. To prepare the Cat5 cable and RJ-45 connector for iPort installation: 1.
  • Page 4: Installation Preparation

    2. Perform an obstruction survey to ensure there are no studs, conduit, pipes, heating ducts, or air returns that will interfere with the Control Mount. Note: You can mount the CM-IW100T directly next to a wall stud on either side (see Step 8).
  • Page 5 4. Install the wall plate into an electrical box in the room near the audio system. POWERINTERNETWIRELESS ETHERNET PORT IMPorTaNT: Do not install the iPort’s wall plate in the same electrical box as aC house wiring, a light switch, or any other high-voltage device or control.
  • Page 6 A slight tight fit between the connector board and the slot opening will hold the weight of the iPod touch. The iPod touch will fit snugly in the cradle. Figure 6: Connector Board CM-IW100T Instruction Manual...
  • Page 7 Note: If landscape orientation is prefered, the iPort logo button can be reoriented accordingly, see operation. CM-IW100T Instruction Manual...
  • Page 8: Operation

    To reorient the logo, Remove the retaining screws and bracket from the back of the magnetic face plate, rotate iPort logo to desired position and reinstall retaining bracket and screws. See Figure 10. Note: Do not overtighten the retaining screws.
  • Page 9 106.9mm 4.210in CM-IW100T Instruction Manual SpecificationsPower supply: 12 ~ 15V DC, regulated...
  • Page 10: Limited One (1) Year Warranty

    Product with a new or remanufactured Product or a reasonable equivalent at no charge for parts, labor and return shipping.
  • Page 11 Dealer. If you did not purchase from an iPort dealer, you must contact your authorized seller within the warranty period and obtain instructions for obtaining authorized service.
