- Page 1 Control Mount Instruction Manual CM-IW2000 V2...
-
Page 2: Required Tools
® that allows an iOS device to become an integral part of your home control system through wireless applications. Before installing and using the CM-IW2000 V2, please read and follow all of the instructions in this manual carefully. System Capabilities: •... -
Page 3: Installation Preparation
16 AWG *Additional wire not included POWER WIRELESS INTERNET ETHERNET PORT CM-IW100T ® U.S. Patent No. 7,493,142 Additional Patents Pending Designed and Engineered in the USA 33-5203 4-09 To Audio Wall Plate Figure 3: iPort System Connections CM-IW2000 V2 Instruction Manual... - Page 4 • When you notice resistance on the four screws, the Control Mount has been clamped successfully. IMPorTANT: NEVEr over-tighten the roto-Lock screws. Figure 6: Mounting iPad to bezel Note: Please use the provided fit kit for iPad (4th generation), (3rd generation) and iPad 2. CM-IW2000 V2 Instruction Manual...
- Page 5 30 Pin) to (C) using the bracket provided on (C). Note: Apple Connector Cable not included. Use the cable provided with iPad. Phoenix Connector Connect power wire to the Charging Circuit Board via the provided Phoenix Connector. Screw on the Stand Offs (D) as shown. CM-IW2000 V2 Instruction Manual...
-
Page 6: Final Adjustment
A light coat will allow the bezel to maintain 2. Attach the iPort suction cup removal tool (figure 10) to the all proper tolerances and ensure precision fit. Do not roll or UPPER left or right corner of the iPad touch screen. -
Page 7: Specifications
(294.6mm x 241.6mm x 59.9mm) Cut-out Dimensions (W x H): 10.75” x 8.65” (273.1mm x 219.7mm) 6.1mm 0.24in 6.1mm 0.24in 294.6mm 273.1mm 11.60in 10.75in 273.1mm 38mm 10.75in 1.49in 59.9mm 2.36in 273.1mm 38mm 10.75in 1.49in 59.9mm 2.36in CM-IW2000 V2 Instruction Manual... - Page 8 Dealer/Distributor, will be free from defective workmanship and materials in the initial installation for the period stated below. iPort will at its option and expense during the warranty period, either repair the defect or replace the Product with a new or remanufactured Product or a reasonable equivalent at no charge for parts, labor and return shipping.
