Locked LED: Indicates that the DF66 is receiving from and locked to the selected sync
source. This LED must be lit for proper DF66 audio operation.
MADI In Ports: Digital audio signal input. Each port can receive 56 or 64 audio channels
at sample rates up to 48 kHz, or 28 or 31 channels at 96 kHz.
MADI Out Ports: Digital audio signal output. Each port can transmit 56 or 64 channels of
audio at sample rates up to 48 kHz, or 28 or 31 channels at 96 kHz.
VGA (DB-15), Keyboard (PS2), Mouse (PS2): Service connections only.
LAN Port 1 (RJ45): Connect to EuCon Network Switch via RJ45 (provided).
LAN Port 2 (RJ45): Not used.
SNMP LAN Port (RJ45): Connect this port to a network with SNMP monitoring or e-mail
services to enable the hardware monitoring system to report errors.
SNMP Serial Port (DB-15): Service connection only.
Power Connectors (IEC): Accepts two standard IEC power cords (provided). Two auto-
ranging switching supplies accept voltages in the range100–240 VAC, 50–60 Hz.
Network: Connect the left Ethernet port (from the rear) to the console's Ethernet
switch.
Sync: Connect a digital reference signal from a master clock source to one of the sync
inputs. Be sure to select this as the sync source when configuring the DF66 (see General
Settings on page 11).
MADI: MADI ports and DSP cards are numbered from left to right (from the rear).
MADI port A on the first DSP card is always used for the monitor/comms connection.
