Status Module
Power Switch: Turns the unit on or off.
System Reset Switch: Forces a manual reset of the DF66.
Alarm Cancel Switch: Cancels the audible hardware fault alarm.
LED Status Indicators: Indicates the status of the power supply, cooling fans,
temperature, and file system activity. Healthy status is indicated with a green light,
faults are indicated with a red light.
USB Ports: Connect a USB storage device to update software (see SP662 DSP Card
Firmware on page 15).
