American Standard Laundry Faucet 2086 Parts List

A907390-YYY0A
CARTRIDGE COVER
906068-0070A
CARTRIDGE NUT
M961603-YYY0A
POP-UP ROD
907638-YYY0A
ESCUTCHEON
Replace the "YYY" with
appropriate finish code
CHROME
WHITE
POL. BRASS
SATIN NICKEL
SATIN/POL.BRASS
CHROME/POL.BRASS
M 9 6 8 7 1 2 R E V . 1 . 2
A961618-YYY0A
HANDLE
M961613-YYY0A
BUTTON AND
SCREW KIT
912740-0070A
O-RING
953130-0070A
CARTRIDGE
M961619-0070A
MANIFOLD
A922869-YYY0A
AERATOR
070847-0070A
051049-YYY0A
MOUNTING KIT
002
020
099
295
297
299
LAVATORY FAUCET
066116-YYY0A
DRAIN STOPPER
THUMBSCREW
072574-0070A
EXTENSION ROD
CLIP
066118-0070A
PIVOT ROD
0-RING
For toll-free information and answers to your questions, call:
IN CANADA 1-800-387-0369 (TORONTO 1-905-306-1093)
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A m e r i c a n S t a n d a r d I n c .
© A S A m e r i c a , I n c . 2 0 0 8
TENDENCE
MODEL NUMBER
2086
066117-YYY0A
FLANGE KIT
FLANGE
GASKET
WASHER
LOCKNUT
900864-0070A
DRAIN BODY
TAILPIECE INSERT
070532-0070A
TAILPIECE
HOT LINE FOR HELP
1-800-442-1902
Weekdays 8:00 a.m. to 6:00 p.m. EST
Weekdays 8:00 a.m. to 7:00 p.m. EST
IN MEXICO 01-800-839-12-00
