- Page 1 Dishwasher JLDWS 1226 User manual...
-
Page 2: Table Of Contents
Contents Important safety information Description of the appliance Control panel Washing programmes When the appliance is first installed The water softener Filling with salt Filling with rinse aid Daily use Loading cutlery and dishes Use of detergent Multi tab function Select and start a washing programme Unloading the appliance Maintenance and cleaning... -
Page 3: Important Safety Information
If you are unsure of the meanings of paragraphs. these warnings contact the John Lewis branch from which you purchased the appliance. Child safety Installation •... -
Page 4: Maintenance And Cleaning
– By clients in hotels, motels and other • The water in your appliance is not for residential type environments drinking. Detergent residue may still be present in the appliance. – Bed and breakfast type environments. • Ensure that the appliance door is always •... -
Page 5: Environmental Information
rinsing phases during the washing programme, depending on the degree of soil on the dishes. This helps to reduce energy and water consumption on lightly soiled loads. Environmental information The packaging materials are environmentally friendly and can be recycled. The plastic components are identified by markings (e.g. -
Page 6: Description Of The Appliance
Description of the appliance Worktop Salt container Upper spray arm Water hardness dial Lower spray arm Rinse aid dispenser Filters Detergent dispenser Rating plate 10. Upper basket Dishwasher user manual... -
Page 7: Control Panel
Control panel A B C D E On/off button • The remaining time of the programme in progress. Display • The activation of the rinse aid dispenser. Indicators • The end of a washing programme (the display Delay start button shows a zero). -
Page 8: Function Buttons
Programme buttons Setting mode To select a washing programme, press one of The appliance must be in setting mode these buttons. The related indicator comes on. for these operations: • To start a washing programme. Indicators • To start a delay start. •... -
Page 9: Washing Programmes
Washing programmes Programme Degree of soil Programme Programme Energy Water Type of load description time (kWh) (litre) (minute) 70° Intensive Heavy soil. Prewash 90 - 100 1.7 - 1.9 21 - 19 Crockery, Wash 70 °C cutlery, pots and Rinses pans. -
Page 10: When The Appliance Is First Installed
When the appliance is first installed The water softener Before using the appliance for the first time The appliance is equipped with a water softener 1. Ensure that the electrical and water designed to remove minerals and salts from the connections comply with the installation water supply, which would have a detrimental instructions... -
Page 11: Filling With Salt
5. To change the level, go on pressing function The water softener must be set in two button (A) until the display shows the ways, manually and electronically. required level. Refer to the water hardness table. Setting manually 6. Switch off the appliance to confirm the operation. -
Page 12: Filling With Rinse Aid
5. Screw on the cap of the salt container by 2. Fill the rinse aid dispenser (1) with rinse aid. turning it clockwise until it stops with a click. The maximum level for filling is indicated by Make sure that there is no trace of salt on 'max'. -
Page 13: Daily Use
Daily use 1. Check if it's necessary to refill with • Soften remnants of burnt food in pans. dishwasher salt or rinse aid. • Dishes and cutlery must not impede the 2. Open the door, slide out the baskets and rotation of the spray arms. -
Page 14: The Lower Basket
The lower basket The lower basket is designed to take pots, pans, lids, dishes, salad bowls and cutlery. Serving dishes and large lids should be arranged around the edge of the basket, ensuring that the spray arms can turn freely. The cutlery basket Warning! Knives with long blades, stored in an upright... -
Page 15: The Upper Basket
Avoid to put plates in the first three sectors in the front part of the basket. Make sure the plates tilt forwards. Mix spoons with other cutlery to prevent them from sticking together. For best results we recommend you use the cutlery grid. - Page 16 Glasses with long stems can be placed upside down in the cup racks. For taller items, the cup racks can be folded upwards. Moving the upper basket to the higher position 1. Pull out the basket until it stops. Caution! Ensure that the spray 2.
-
Page 17: Use Of Detergent
Using no more than the correct amount of detergent contributes to reducing pollution. Fill with detergent Moving back the upper basket to the lower position 1. Pull out the basket until it stops. 2. Carefully lift both sides upwards and then allow the mechanism to drop back down slowly, keeping hold of it. -
Page 18: Multi Tab Function
Multi tab function This appliance is equipped with the Multi tab 2. Adjust the water hardness to the highest function, that allows the use of combi detergent level. tablets. 3. Perform a washing programme without These products are detergents with a combined loading any dishes. -
Page 19: Select And Start A Washing Programme
Select and start a washing programme Starting the washing programme Starting the washing programme without delay start with delay start You can set the washing programme You can set the delay start with the with the appliance door open or appliance door open or closed. -
Page 20: End Of The Washing Programme
When you cancel a delay start, the If you do not switch off the appliance, appliance goes back to setting mode. after three minutes from the end of You have to set the washing the washing programme, all the programme again. indicators go off and the display shows one horizontal status bar. -
Page 21: Unloading The Appliance
Unloading the appliance • Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down before removing from the appliance. • Empty the lower basket first and then the upper one; this will avoid water dripping from the upper basket onto the dishes in the lower one. -
Page 22: Maintenance And Cleaning
Maintenance and cleaning Cleaning the filters The filters must be checked and cleaned from time to time. Dirty filters will degrade the washing result. Warning! Before cleaning the filters ensure that the appliance is switched off. 1. Open the appliance door and remove the lower basket. -
Page 23: Cleaning The Appliance
Spray arms Caution! Never try to remove the spray arms. If residue of soil has clogged the holes in the spray arms, remove the debris with a sharp pointed item (e.g. toothpick, cocktail stick). Cleaning the appliance External cleaning Clean the external surfaces of the appliance and control panel with a damp soft cloth. -
Page 24: Moving The Appliance
Moving the appliance If you have to move the appliance (e.g. moving house): 1. Unplug the appliance. 2. Turn the water tap off. 3. Remove the water inlet and discharge hoses. 4. Pull the appliance out together with the hoses. Avoid over tilting the appliance during transportation. -
Page 25: Something Not Working
Something not working The appliance does not start or it stops during • - The appliance does not drain the water operation. • - The anti-flood device is on. Certain problems are due to the lack of simple maintenance or oversights, which can be solved Warning! Switch off the with the help of the indications described in the appliance before you carry out... - Page 26 Malfunction Possible cause Possible solution The mains plug is not connected in Connect the mains plug. the mains socket. The fuse in the fuse box is Replace the fuse. damaged. The delay start is set. • Cancel the delay start. •...
- Page 27 The washing and drying results are not satisfactory The detergent can be the cause. Use a different brand of detergent. The dishes are wet. The washing programme was Set a programme with the drying without a drying phase. phase. The dishes are wet and matt. The rinse aid dispenser is empty.
-
Page 28: Technical Data
Technical data Dimensions Width 600 mm Height 850 mm Depth 610 mm Water supply pressure Minimum 0.5 bar (0.05 MPa) Maximum 8 bar (0.8 MPa) Electrical connection Information on the electrical connection (voltage, overall power and fuse) is given on the rating plate on the inner edge of the appliance door. Capacity Place settings Power consumption... -
Page 29: Installation
Installation Warning! • It is dangerous to alter the 570-600 mm specifications or attempt to modify the appliance in any way. • This appliance is heavy. Care 820 mm should be taken when moving • Care must be taken to ensure that the appliance does not 600 mm stand on the electrical supply... - Page 30 The plinth on freestanding appliances is not adjustable. Caution! It is necessary to protect the underside of the kitchen worktop from condensation. A plastic top cover can be purchased, contact your local John Lewis branch. Dishwasher user manual...
-
Page 31: Water Connection
Water connection Water inlet connection Water drain connection This appliance must be connected to a cold The end of the drain hose can be connected in water supply. the following ways: For making the connection itself, the coupling • To the sink outlet spigot, securing it to the nut fitted to the appliance inlet hose is designed underside of the work surface. - Page 32 Likewise the internal diameter of the couplings used for connections to the waste outlet must be no smaller than the diameter of the hose provided. Our appliances are supplied with a security device to protect against the return of dirty water back into the appliance.
-
Page 33: Electrical Connection
Electrical connection • If necessary, have the domestic wiring system Warning! The manufacturer socket replaced. In case that the electrical accepts no liability for failure to cable has to be replaced, contact your local observe the following safety repair agent. precautions. -
Page 34: Repairs - After Sales Service
An authorised service engineer should service and information contained within this instruction this product, and only genuine spare parts manual, the next step is to contact John Lewis should be used. Under no circumstances should technical support on: you attempt to repair the appliance yourself. - Page 35 John Lewis, Stratford (Opening 2011) John Lewis, Cribbs Causeway 0117 959 1100 John Lewis at home, Swindon 01793 733180 John Lewis at home, Croydon 020 8662 4730 John Lewis, Trafford 0161 491 4040 John Lewis, Edinburgh 0131 556 9121 John Lewis at home, Turnbridge Wells...
- Page 36 156958722-A-402012 (Subject to change without notice)
