Page 10 AXIS Q8108-R User's Guide

Mounting Hard Disk

AXIS Q8108-R supports the use of up to 2 separate hard disk. Follow these instructions and consult
manufacturer's recommendations to mount or change hard disk.
1. Remove the back cover.
2. Power off the AXIS Q8108-R, see Start up and shut down, on page 11 and LED indicators, on
page 7.
3. Insert hard disks into adapter kit. It's possible to use one 3.5" or up to two 2.5" hard disks.
4. Insert adapter kit with hard disks into the bracket in the lid.
5. Attach the SATA connectors.
6. Power on the device.
7. Replace back cover and tighten screws
1
2
3
