Kenwood MGR-E8 Instruction Manual

Digital audio recorder
Hide thumbs

Advertisement

Quick Links

MGR-E8
DIGITAL AUDIO RECORDER
INSTRUCTION MANUAL
Declaration of Conformity with regard to the
EMC Directive 2004/108/EC
Manufacturer:
Kenwood Corporation
2967-3 Ishikawa-machi, Hachioji-shi, Tokyo, 192-8525 Japan
EU Representative's:
Kenwood Electronics Europe BV
Amsterdamseweg 37, 1422 AC UITHOORN, The Netherlands
© B60-5825-08/00 (E/X) 1AJ6P1P0109-- (XE0)
