Impex GD-600 Owner's Manual

Rocking hammock
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
GD-600
Retain This
Manual for
Reference
11-24-09
OWNER'S
MANUAL
ROCKING HAMMOCK
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
GD-600
®
IMPEX
INC.

Advertisement

Table of Contents
loading

Related Manuals for Impex GD-600

Summary of Contents for Impex GD-600

  • Page 1 NOTE: Please read all instructions carefully before using this ROCKING HAMMOCK product Table of Contents GD-600 Safety Notice Hardware Pack Assembly Instruction Parts List Warranty Ordering Parts Model GD-600 Retain This Manual for Reference 11-24-09 ® IMPEX INC. OWNER'S 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746...

  • Page 2: Table Of Contents

    ORDERING PARTS..................…. BEFORE YOU BEGIN ® Thank you for selecting the Rocking Hammock GD-600 by IMPEX . For your safety and benefit, read this manual carefully before using the Hammock. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    IMPORTANT SAFETY NOTICE Please read the entire manual before assembling or operating the equipment. In particular, note the following safety precautions to reduce the likelihood of injury. 1. Children must be supervised at all times and never left unattended with the unit. 2.

  • Page 4: Warning Label Placement

    WARNING LABEL PLACEMENT The Warning Label shown here has been placed on the Stabilizer Frame. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.

  • Page 5: Hardware Identifier

    HARDWARE IDENTIFIER Part# Description Identifier Cap Washer (Qty 16) Cover Cap (Qty 16) M8 x 5/8” Allen Bolt (Qty 16) Tools: #5 Allen Wrench (Qty 1)

  • Page 6: Assembly Instructions

    ASSEMBLY INSTRUCTION Tool Required for Assembling the Machine: #5 Allen Wrench NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Do not tighten Bolts until instructed to do so. B.) Attach the two Stabilizer Tubes (#11) to the two Hammock Base Frames (#4).
  • Page 7 Step 2 (See Diagram 2) A.) Do not tighten Bolts until instructed to do so. B.) Insert a Hammock Body Support Tube (#12) through the sleeve next to the pillow on Hammock Body (#15). NOTE: The pillow needs to be on top of the Hammock Body. C.) Insert the Right Long Support (#6) into the right opening on the Hammock Base Frame (#4).
  • Page 8 Step 3 (See Diagram 3) A.) Insert the Right Short Support (#8) into right opening on the Hammock Base Frame (#4). B.) Insert the Hammock Body Support Tube (#12) through the other open sleeve on the Hammock Body. C.) Attach the right end of the Hammock Body Support Tube to the Right Short Support. Attach the other end to the Left Short Support (#7).
  • Page 9 Step 4 (See Diagram 4) A.) Insert the Support Rod (#21) and Sun Shade Rod (#20) through the sleeve on the Sun Shade (#14). B.) Insert each end of the Support Rod into the Left and Right Rod Holder (#18) on Sun Shade Support Frame.
  • Page 10 Step 5 (See Diagram 5) A.) Insert the Sun Shade Support Frame (#13) into the Long Support Cover Caps (#17). DIAGRAM 5...
  • Page 11 Step 6 (See Diagram 6) A.) Cover all M8 x 5/8” Allen Bolts (#24) and Cap Washers (#2) with sixteen Cover Caps (#3). DIAGRAM 6...

  • Page 12: Operation

    OPERATION 1. Place the Rocking Hammock on flat surface. 2. Lay in the middle of the Hammock Body only, and place head on the pillow. 3. Gently sway body and the Hammock will start rocking. 4. To remove the Sun Shade just simply pull out the Support Rod from the Rod holder, and then pull out the Sun Shade Support Frame.

  • Page 13: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 14: Parts List

    Parts list KEY NO. DESCRIPTION Q’ty Spacer Cap Washer Cover Cap Hammock Base Frame Left Long Support Right Long Support Left Short Support Right Short Support Right Bracket Left Bracket Stabilizer Tube Hammock Body Support Tube Sun Shade Support Frame Sun Shade Hammock Body Short Support Cover Cap...

  • Page 15: Warranty

    ® IMPEX INC. LIMITED WARRANTY ® IMPEX INC ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of 2 YEARS from the date of purchase. This warranty extends only to the original purchaser.
