  • Page 1 Meijer.com NOTE: Please read all instructions carefully before using this product Table of Contents Safety Notice Magnetic-Resistance Hardware Pack Upright Bike Assembly Instruction NS-1101U Parts List Warranty Ordering Parts Model NS-1101U Retain This Manual for Reference 120315 ASSEMBLY & OWNER'S ®...

  • Page 2: Table Of Contents

    COMPUTER…………………………………………………………………………… 16 EXERCISE GUIDELINES……………………………………………………………. 17 WARRANTY....................…. ORDERING PARTS..................….. BEFORE YOU BEGIN Thank you for selecting the MARCY Magnetic-Resistance Upright Bike NS-1101U by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the bike. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES RESPONSIBILITY PERSONAL INJURY PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

  • Page 4: Warning Label Placement

    The Warning Labels and Caution Label shown here have been placed on the Rear Stabilizer. If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the labels in location shown. © IMPEX INC. www.impex-fitness.com...

  • Page 5: Hardware Pack

    NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size. DESCRIPTION IDENTIFIER Q’TY Spacer M8 x 3” Allen Bolt Ø ¾” Curved Washer Ø ½” Lock Washer M5 x 1” Philips Screw T-shaped Lock knob Allen wrench Crossing wrench © IMPEX INC. www.impex-fitness.com...
  • Page 6 Meijer.com COMPONENTS FOR ASSEMBLY © IMPEX INC. www.impex-fitness.com...

  • Page 7: Assembly Instructions

    Ø ½” Lock Washers (#21), and two Ø ¾” Curved Washers (#16). B.) Attach the Rear Stabilizer (#29) to the Main Frame (#26). Secure it with two M8 x 3” Allen Bolts (#20), two Ø ½” Lock Washers (#21), and two Ø ¾” Curved Washers (#16). © IMPEX INC. www.impex-fitness.com...
  • Page 8 Meijer.com STEP 2 A.) Thread the Left Pedal (#27) counterclockwise into the Crank (#28). B.) Thread the Right Pedal (#25) clockwise into the Crank (#28). © IMPEX INC. www.impex-fitness.com...
  • Page 9 E.) Drop down the Upper Tension Cable so the fitting sits firmly on top of the bracket. F.) Secure the Front Post to the Main Frame with the four M8 x ¾” Allen Bolts (#15) and four Ø ¾” Curved Washers (#16). © IMPEX INC. www.impex-fitness.com...
  • Page 10 B.) Insert the two Pulse Sensor Wires (#3) through the open slot on Front Post and then pull up and out of the Front Post. C.) Clamp the Handle to the Front Post. Secure it with T-shaped Lock Knob (#8), Spacer (#7), and the Clamp Cover (#6). © IMPEX INC. www.impex-fitness.com...
  • Page 11 A.) Connect the Middle Computer Wire (#4) to the computer wire. B.) Connect the two Pulse Sensor Wires (#3) to the sensor wire from Computer (#1). C.) Slide the Computer onto the Front Post (#9). Secure it with one M5 x 1” Philips Screw (#5). © IMPEX INC. www.impex-fitness.com...
  • Page 12 B.) Remove M5 x 5/8” Philips Screw (#10) pre-installed by factory from Front Post (#9). Attach the Water Bottle Rack (#11) to Front Post (#9). Secure it with two the M5 x 5/8” Philips Screws (#10) previously removed from the Rack. © IMPEX INC. www.impex-fitness.com...
  • Page 13 STEP 7 A.) Attach the Seat (#13) onto the Seat Post (#14). Secure the Seat with pre-installed round bracket, bolt, and nuts underneath the Seat. B.) Place the Water Bottle (#12) into the Water Bottle Rack (#11). © IMPEX INC. www.impex-fitness.com...

  • Page 14: Exploded Diagram

    Meijer.com EXPLODED DIAGRAM © IMPEX INC. www.impex-fitness.com...

  • Page 15: Parts List

    Tension Knob w/Upper Tension Cable Front Cover Front Stabilizer Allen Bolt M8 x 3” Lock Washer Ø ½” Lower Computer Wire Lower Tension Cable Quick Release Knob Right Pedal Main Frame Left Pedal Crank Rear Stabilizer © IMPEX INC. www.impex-fitness.com...

  • Page 16: Care, Maintenance And Storage

    4. The seat can be adjusted forward or backward and hold in position by using the Knob under the sliding tube. TRANSPORT The Bike has a pair Roller End Caps on Front Stabilizer. To move, carefully hold and tilt the Handle, and then roll. © IMPEX INC. www.impex-fitness.com...

  • Page 17: Computer

    5. When the batteries are removed, all the functional values will reset to zero. Note: Please note all values on this computer are approximate and they are for comparison purpose only. Do not use these values for any medical or rehabilitation purpose. © IMPEX INC. www.impex-fitness.com...

  • Page 18: Exercise Guidelines

    This stage should last for a minimum of 12 minutes though most people start at about 15-20 minutes © IMPEX INC. www.impex-fitness.com...

  • Page 19: Weight Loss

    The important factor here is the amount of effort you put in. The harder and longer you work the more calories you will burn. Effectively this is the same as if you were training to improve your fitness, the difference is the goal. © IMPEX INC. www.impex-fitness.com...

  • Page 20: Warranty

    IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
