Impex SA GEAR MSS-1280 Owner's Manual

Impex SA GEAR MSS-1280 Owner's Manual

Deluxe smith machine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
MSS-1280
Retain This
Manual for
Reference
08-03-09
OWNER'S
MANUAL
DELUXE SMITH MACHINE
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
MSS-1280
®
IMPEX
INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SA GEAR MSS-1280 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Impex SA GEAR MSS-1280

Summary of Contents for Impex SA GEAR MSS-1280

  • Page 1 Safety Notice Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model MSS-1280 Retain This Manual for Reference 08-03-09 OWNER'S MANUAL ® IMPEX INC. 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...

  • Page 2: Table Of Contents

    ORDERING PARTS..................26 BEFORE YOU BEGIN Thank you for selecting the SA GEAR DELUXE SMITH MACHINE MSS- ® 1280 IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS.
  • Page 4 WARNING LABEL PLACEMENT The warning labels shown here have been placed on the back of Rear Support, and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.

  • Page 5: Smith Machine Hardware Pack

    SMITH MACHINE HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 CAGE MACHINE HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

  • Page 7: Smith Machine Assembly Instructions

    SMITH MACHINE ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Note: Do not tighten the Nuts and Bolts until instructed to do so. B.) Connect the two Base Frames (#3) by the Cross Brace (#7).
  • Page 8 STEP 2 (See Diagram 2) A.) Do not tighten Nuts and Bolts until instructed to do so. B.) Attach the Left Upright Beam (#1) to the Left Rear Support (#5) and onto the left Base Frame (#3). C.) Secure it to the Base Frame with two M10 x 4” Allen Bolts (#54), four Ø ¾” Washers (#57), and two M10 Aircraft Nuts (#58).
  • Page 9 DIAGRAM 2...
  • Page 10 STEP 3 (See Diagram 3) A.) Attach two Ø 2 3/8” x 2” Rubber Bumpers (#30) to the holes on the Cross Brace (#7). Insert the two Rear Short Guide Rods (#17) through the two Rubber Bumpers into the holes on Cross Brace.
  • Page 11 DIAGRAM 3...
  • Page 12 CABLE LOOP DIAGRAM...
  • Page 13 STEP 4 (See Diagram 4 & Cable Loop Diagram) A.) Attach the 170” Upper Cable (#25) to the opening on the Front Upper Frame (#14). B.) Attach a Pulley (#33) to the opening. Secure it with one M10 x 4” Allen Bolt (#54), two Ø...
  • Page 14 STEP 5 (See Diagram 5 & Cable Loop Diagram) A.) Attach the 62” Lower Cable (#26) to the open bracket on the Cross Brace (#7). Attach a Pulley (#33) to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#52), two Ø ¾” Washers (#57), one L-shaped Cable Retainer (#24), and one M10 Aircraft Nut (#58).
  • Page 15 STEP 6 (See Diagram 6) A.) Place the Lifting Sleeve (#8) in between the two Safety Stop Frames (#18). Align the holes. Insert the Weight Bar (#13) from outside of one Safety Stop Frame through the Lifting Sleeve to the other Safety Stop Frame on the other side. B.) Turn and attach the two safety catch hooks on the Lifting Sleeve (#8) to the selected slots on the Left and Right Uptight Beams (#1 &...

  • Page 16: Smith Machine Exploded Diagram

    SMITH MACHINE EXPLODED DIAGRAM...

  • Page 17: Smith Machine Parts List

    SMITH MACHINE PART LIST KEY NO. DESCRIPTION Q’ty Left Upright Beam M10 x 1” Allen Bolt Right Upright Beam M10 x 1 ¾” Allen Bolt Base Frame M10 x 4 1/8” Allen Bolt Top Beam M10 x 4” Allen Bolt Left Rear Support M10 x 3 ½”...

  • Page 18: Bench Hardware Pack

    BENCH HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 19 BENCH HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

  • Page 20: Bench Assembly Instructions

    BENCH ASSEMBLY INSTRUCTION STEP 1 (See Diagram 1) A.) Attach the Bench Base Frame (#6) to the Rear Stabilizer (#7). Secure the side-holes with two M10 x 4” Carriage Bolts (#41), two Ø ¾” Washers (#31), and two M10 Aircraft Nuts (#33). Secure the top hole with one M10 x 5/8” Allen Bolt (#36) and one Ø...
  • Page 21 STEP 2 (See Diagram 2) A.) Attach the Main Seat Support (#1) to the Bench Base Frame (#6). Secure it with three M10 x 4” Carriage Bolts (#41), three Ø ¾” Washers (#31), and three M10 Aircraft Nuts (#33). B.) Attach the Front & Rear Seat Bracket (#4 & #5) to Main Seat Support. Secure each Bracket with one M10 x 4”...
  • Page 22 STEP 3 (See Diagram 3) A.) Align the bracket on the Backrest Adjustment Support (#8) in between the two Backrest Supports (#3). Secure it with four M8 x 1 5/8” Allen Bolts (#34), eight Ø 5/8” Washers (#30), and four M8 Aircraft Nuts (#32). Do not tighten the Nuts and Bolts yet. B.) Insert the Backrest Adjustment Support into the opening on the Main Seat Support (#1).
  • Page 23 STEP 4 (See Diagram 4) A.) Attach the Backrest Board (#13) to the Backrest Supports (#3). Secure it with four M8 x 1 5/8” Allen Bolts (#34) and four Ø 5/8” Washers (#30). B.) Attach the Seat Pad (#12) to Front & Rear Seat Bracket (#4 & #5). Secure them with four M8 x 1 5/8”...
  • Page 24 STEP 5 (See Diagram 5) A.) Attach the Leg Developer (#2) to Main Seat Support (#1). Secure it with one M10 x 3 1/8” Allen Bolt (#38), two Ø ¾” Washers (#31), and one M10 Aircraft Nut (#33). B.) Insert two Foam Tubes (#10) halfway through the holes on Leg Developer. Push four Foam Rolls (#16) onto the Tubes from both ends.

  • Page 26: Bench Parts List

    BENCH PARTS LIST KEY NO. DESCRIPTION Q’ty Main Seat Support Leg Developer Backrest Support Front Seat Bracket Rear Seat Bracket Bench Base Frame Rear Stabilizer Backrest Adjustment Support 1 Backrest Adjustment Lever Foam Tube Spring Seat Pad Backrest Board 2 ¾” Grip 2”...

  • Page 27: Warranty

    IMPEX. IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the use or performance of the product or other damages with respect to any economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or whatsoever natures.
