T
ECHNICAL
Standards
Protocol
Data Transfer
Rate
Topology
Network
Cables
Number of
Ports
Uplink Port
S
PECIFICATIONS
General
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
ANSI/IEEE 802.3 NWay Auto-negotiation
IEEE 802.3x Full duplex Flow Control
CSMA/CD
Ethernet: 10Mbps (half duplex)
20Mbps (full-duplex)
Fast Ethernet: 100Mbps (half duplex)
200Mbps (full- duplex)
Star
10BASET: 2-pair UTP Cat. 3,4,5, EIA/TIA- 568
100-ohm STP
100BASE-TX: 2-pair UTP Cat. 5, EIA/TIA-568
100-ohm STP
5 x 10/100Mbps MDI-X ports
MDI-II RJ-45 * 1, share with port 1
6
